- Page 1 LUNA 118 top Ref. Nr. 118 0 702/752 LUNA 119 top Ref. Nr. 119 0 702 Bedienungsanleitung Operating instructions Mode d’emploi Gebruiksaanwijzing Istruzioni d’uso Instrucciones de manejo Manual de instruções LU 110 LU 112 LU 113 LU 126star LU129star-time SEL 173 DCF TR 612 top...
- Page 2 Contents 1.0 Features Features • Combination of a twilight switch and integrated timer for automatically switching the lighting ON / OFF. Description Installation • Timer with weekly and holiday program Electrical Connection • Preselection control and permanent control Adjusting the Twilight Switch •...
- Page 3 2. Description LU 118top / LU 119top Switch status indicator (LED) Timer with display Twilight switch (non-delayed) Time of the day / switching time Display of switch status / commands Fine adjustment potentiometer ON/ OFF (in the Lux-channel ON and Twilight switch Active) Range selector...
-
Page 4: Installation
3.0 Installation 4.0 Electrical Connection Electrical devices may only be installed and Note: In spite of an internal safety measures, mounted by a qualified electrician. extraordinarily strong magnetic fields can cause Manipulation and modification of the switch will interference in the microprocessor-controlled result in loss of warranty. -
Page 5: Light Sensor
Light Sensor Connection Diagrams + Lux Installing the surface- mount light Luna 118top sensor max. o 4 mm (9070008) Installing the fittable light Luna 119top sensor (9070011) Observe the connection diagrams above and notes to deviating spe- cial voltages on the type label. - Page 6 The contact will connect only if ACTIVE is shown 4.0 Adjusting the Twilight Switch on the timer display and the red switching status Select the setting range via the rotary switch LED is permanently lit for more than 80 s. •...
-
Page 7: Adjusting The Timer
5.0 Adjusting the Timer Daily overview of the programmed Manual ON/OFF switching times Permanent ON/OFF 12 15 18 21 24 Holiday program active Auto Channel status ACTIVE and OFF are displayed in the lux-channel only Current day of the week 1 = Monday, 2 = Tuesday Service voltage OK 1 2 3 4 5 6 7... - Page 8 Store the individual selections by pressing the key. 5.1 Taking the Switch into Operation You can now start programming. Press the key to call Menu The timer is delivered in what is referred to a "sleep mode". the programming and query routines. Text displays prompt you Activation without service voltage.
-
Page 9: Program Review
Displaying the switching times Forming groups In the Abfragen (query) menu, press the key several When the prompt Kopieren (Copy) is displayed, press times. to copy the switching time to another day of the week. When programming an identical time for activation and In emergency situations only deactivation, e.g. - Page 10 Select channel C1 or C2 by pressing (only with – 5.3 Permanent ON/OFF, Holiday Program LU 119top). Confirm your selection by pressing Always read the text display first! – Select ON or OFF by pressing . Confirm your In the Man menu select the Manual , Permanent or selection by pressing .
-
Page 11: Holiday Program
Permanent ON or OFF 5.4 Setting Correcting the Date and Time – Press the two keys simultaneously for approx. Automatic summer/winter time correction 2 s. Permanent ON or OFF Depending on the version, the timer may be preprogram- (for LU 119top use med ex-works with the summer/winter time rule. -
Page 12: Technical Data
Power reserve 3 yearsat20° C 6.0 Technical Data Permissible ambient control unit: - 10° C ... + 50° C Operating voltage: 230 V~, ± 10 % temperature: light sensor: - 40° C ... + 70 ° C Mains frequency: 50 Hz Class of protection control unit: II if properly mounted Own consumption:... - Page 13 TEMPOLEC International s.a., Route de Biesme 49, 6530 Thuin, Fax. 02 08/4 52 51 43 Tél. 071.59.00.39 (10 lignes), Fax. 071.59.01.61 THEBEN S.R.L., via Ciro Menotti 11, 20129 Milano THEBEN (Schweiz) AG, Schwettistraße 152, 5704 Egliswil, Tel. 02/7 38 61 41/2/3/4, Fax. 02/7 38 61 44 Tel.
