Summary of Contents for Migatronic PI 200 DC
- Page 1 PI 200/250 DC HP Brugsanvisning Instruction manual Betriebsanleitung Manuel d’instruction Manuale d’istruzione Bruksanvisning Käyttöohje Manual de instrucciones Gebruikershandleiding Manual de instruções Podręcznik obsługi Valid from 2012 week 09 50113201 R...
- Page 2 EC DECLARATION OF CONFORMITY MIGATRONIC A/S Aggersundvej 33 9690 Fjerritslev Denmark hereby declare that our machine as stated below Type: PI 200 (250) DC HP As of Week 44 2005 conforms to directives 2006/95/EC and 2004/108/EC European Standards: EN/IEC60974-1 EN/IEC60974-2...
- Page 3 ENGLISH WARNING Arc welding and cutting can be dangerous to the user, people working nearby, and the surroundings if the equipment is handled or used incorrectly. Therefore, the equipment must only be used under the strict observance of all relevant safety instructions. In particular, your attention is drawn to the following: Electricity - The welding equipment must be installed according to safety regulations and by a properly trained and qualified person.
-
Page 4: Machine Programme
INITIAL OPERATION PI 200/250 DC Mains connection PI 200 DC is single-phased and PI 250 DC is a three- The machine must be connected to a mains supply phased welding machine for MMA and TIG welding. and protection earthing. After the mains plug (1) has... - Page 5 Connection of foot control Foot control is connected to the 7-poled plug (7) or through the 8-poled plug (15) (depending on the foot control type). Connection of remote control PI machines equipped with 8-pole control interface (15) can be controlled via a remote control or a welding robot.
-
Page 6: Control Unit
CONTROL UNIT Control knob Welding current All parameters are set by the use of only The key pad can be used to display the one control knob. These parameters include welding current. Adjustable from 5A to 200A or current, pulse time, slope-up time, etc. 250A depending on the machine model. - Page 7 TIG welding Final Amp [A%] The slope-down stage is completed when the current level has fallen to the value stated in the Final Amp parameter. In 4-times it is possible to continue in Final Amp mode until the trigger is released. Final Amp is stated as a percentage of the required welding current and is variable between 1 - 90% of the welding current.
- Page 8 Fast pulse Is used for selection of fast pulse. The pulse current is equal to the set current. It is possible to adjust: Additional current supply from the arc Pulse frequency power function Set welding Variable 25 - 523 Hz. short- current time...
- Page 9 Trigger mode USER MENU Selection of trigger mode. Four-times trigger This menu is intended to permit advanced mode is active when the LED is illuminated, settings and controls of machine. and two-times trigger mode is active when the LED is To access the user menu, press the knob for 3 turned off.
- Page 10 The following diagram display all parameters and options of menu. Exit from the USER menu 4-times option for torch trigger Permit to define 4 different ways to Open/Close the gas valve in order to purge control the torch trigger when the machine is the torch, check the gas bottle and pressure set as 4Times stroke (Lift or HF).
-
Page 11: Technical Data
TECHNICAL DATA MAINTENANCE The machine requires periodical maintenance and Power source: PI 200 DC PI 250 DC cleaning order avoid malfunction Mains voltage (50Hz-60Hz) 1 x 230 V ±15% 3x400 V ±15% Fuse 10 A cancellation of the guarantee. Fuse with PFC... -
Page 12: Warranty Conditions
All forms of transport in connection with a warranty claim fall outside the scope of Migatronic’s warranty and will take place for buyer’s own account and risk. We refer to Migatronic’s warranty conditions at...
