What This Kit Includes
Tools That You Need
What You Need to Do
®
PowerFlex
DC Drive - Frame C Bimetal
Thermostat
ATTENTION: Only qualified personnel familiar with DC
!
drives and associated machinery should plan or implement the
installation, start-up and subsequent maintenance of the system.
Failure to comply may result in personal injury and/or equipment
damage.
ATTENTION: To avoid an electric shock hazard, ensure that
!
all power to the drive has been removed before performing the
following.
ATTENTION: This drive contains ESD (Electrostatic
!
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference A-B publication 8000-4.5.2,
"Guarding Against Electrostatic Damage" or any other
applicable ESD protection handbook.
• Bimetal Thermostat
• Wire leads with connector
• Thermal grease
• Static strap
• Phillips
®
screwdriver
• Flathead screwdriver
• Nut driver or wrench
• Torque wrench
®
Phillips
is a registered trademark of Phillips Screw Company.
The Bimetal Thermostats are located on the drive heatsink. To install the
Bimetal Thermostats:
Step 1: Remove power from the drive
Step 2: Remove the protective covers
Step 3: Remove the existing Bimetal Thermostat
Step 4: Install the new Bimetal Thermostat
Step 5: Replace the protective covers and document the change
Installation Instructions
