Summary of Contents for Gorenje HPWW7

Page 1 Heat Pump WATER-TO-WATER Instructions for Installation and Start-up...
Page 2 Water-to-water Heat Pump 1. INDEX...
Page 3 Water-to-water Heat Pump Introduction These Instructions explain the procedure for installation of the water-to-water heat pump. They include a description of the start-up procedure that should be carried out by a competent expert authorised by the manufacturer. Use the following Contents to find the relevant Chapters for the correct mounting and installation of the pump.
Page 4: Safety Warnings
In order to prevent oxidation in the central heating system and heat pump condenser, add an anti-corrosive agent to the water. Any repairs and adjustments to the pump must be made by a Gorenje authorised servicing technician only. Before any repair, disconnect the pump from the power supply source.
Page 5: Statutory Requirements
Water-to-water Heat Pump Statutory Requirements This heat pump was made in compliance with the applicable standards and complies with the related requirements. The heat pump may be connected to a heat source, heating system or electric power supply, in compliance with applicable regulations. Electric connection must be fixed, via a circuit breaker switch that cuts off supply to all conductors.
Page 6: Purpose Of Use
Water-to-water Heat Pump 3. Use Purpose of Use The water-to-water heat pump is designed for installation in residential buildings (e.g., when renovating the boiler room or as a heating source in newly constructed buildings). Underground water of adequate quality and temperature is used as a heat source. Operating Principles Underground water of adequate quality and temperature (17 to 13°C) is claimed by means of immersion pump from a well, at adequate depth.
Page 7 Water-to-water Heat Pump 4. Tehnical caracteristic The construction of the heat pump unit allows installation indoors; the unit housing is made of sheet metal, incorporating an operating panel used for adjustment of the required parameters by the user. The control unit, located under the upper part of the unit, is used for connection to the electricity supply and for connection of the circulating pump, temperature probes and mixing valves.
Page 8 Water-to-water Heat Pump Legend 1 – Measuring point – riser - heating 2 – Heat exchanger (condenser) 3 - Measuring point – return line - heating 4 – Heat exchanger 5 – Pressure switch – low pressure 6 – Compressor 7 - Compressor power supply terminal 8 –...
Page 9 Water-to-water Heat Pump Legend 1 – Servicing connection (refrigerant pressure at compressor outlet) 2 – Servicing connection (refrigerant pressure at compressor inlet) 3 – Mechanical expansion valve 4 – Servicing connection (refrigerant pressure at evaporator inlet) 5 – Heat exchanger (evaporator) 6 –...
Page 10 Water-to-water Heat Pump Volumes and material – CONDENSER and EVAPORATOR HPWW7 HPWW9 HPWW12 HPWW14 HPWW18 CONDENSER Pure copperr Pure copper Pure copper Pure copper Pure copper Material AISI316 AISI316 AISI316 AISI316 AISI316 1,13 1,24 1,80 2,36 3,15 Refrigerant volume 1,24...
Page 11 Water-to-water Heat Pump 5. Tehnical caracteristic UNIT MODEL HPWW7 HPWW 9 HPWW12 HPWW14 HPWW18 Version Placing Indoor Indoor Indoor Indoor Indoor Capacity Limit operating temperature St.C. Heated water flow +10 °C do +55 °C W ater (heat source) +7 °C do +25 °C...
Page 12 Water-to-water Heat Pump Length Depth Height W eight Dimensions and weight of packaged heat pump Length Depth Height 1030 1030 1030 1030 1030 W eight Connection to power supply Rated voltage/circuit (±10%) 400/10 400/10 400/10 400/16 400/16 breaker ( a l l o we d d e v i a t i o n ) Rated electric power W 10/W 35 1,21...
Page 13: Delivery And Installation
Water-to-water Heat Pump 6. Delivery and Installation Storage and Transport Transport the heat pump in an upright position; when absolutely necessary, the pump may be tilted to a maximum of 45 . Be careful during transport to avoid damage to the housing or to vital parts of the unit.
Page 14 Water-to-water Heat Pump Make sure there is min. 1 m free space above the unit. Distance from the wall depends on the position of the connection pipes and electricity supply cables and may be larger if necessary. Do not put object on cover!
Page 15: Hydraulic Connection
Water-to-water Heat Pump 7. Hydraulic Connection Water-to-water heat pump connections DIMENSIONS FOR CONNECTION (mm) All connections: 5/4˘ Outer threads Cable entr y for electricity supply conduits Heat source – inlet to heat pump Heat source – outlet from heat pump Heating water outlet Return line for heating water Connection to Heating Circuit...
Page 16 Water-to-water Heat Pump increase up to max. 2.5 bar. The increased volume will be absorbed by the expansion vessel, whose dimensions must correlate with the capacity of the heating system (not all heating circuits have a related expansion vessel). The safety valve should be triggered when the pressure reaches 3 bar.
Page 17 Water-to-water Heat Pump Borehole fo Pumping the Water (Well) Water from the underground that is needed for the operation of the water-to-water heat pump is pumped from the well (borehole) The quantity of the groundwater must correspond to the heat pump flow rate.
Page 18 Water-to-water Heat Pump Borehole for Returning the Water (secondary borehole) Water that is sligthly cooled (2 to 3 C) is dishcarged from the water pump and returned to the underground water source. The borehole shall be made on a distance 10 – 15 m along the water flow direction in order to avoid mixing the warm source (inlet water) and the cold source (outlet water).
Page 19: Hydraulic Diagrams
Water-to-water Heat Pump 8. Hydraulic Diagrams Various applications (for various heat sources and extra features) are presented in the form of basic hydraulic drawings. The heat source for each hydraulic diagram can be selected with the adjustment of parameters. In order to include extra features (solar cells, swimming pool, etc.) the parameters need to be adjusted accordingly.
Page 20 Water-to-water Heat Pump Diagram 1: Ground/water heat pump with direct heating circuit. Multifunction inlets/outlets: RVS61 Diagram 2: Ground/water heat pump with direct heating circuit, sanitary water tank and Q3 pump. Multifunctional inlets/outlets: RVS61...
Page 21 Water-to-water Heat Pump Diagram 3: Ground/water heat pump with direct heating circuit, sanitary water tank and Q3 reversing valve. Multifunctional inlets/outlets: RVS61 Diagram 4: Ground/water heat pump with heat water tank, mixing valve or direct heating circuit. Multifunctional inlets/outlets: RVS61 BX1-B4 BX2-B41...
Page 22 Water-to-water Heat Pump Diagram 5: Ground/water heat pump with heat water tank, sanitary water tank, Q3 pump, and mixing or direct heating circuit. Multifunctional inlets/outlets: RVS61 BX1-B4 BX2-B41 Diagram 6: Ground/water heat pump with heat water tank, sanitary water tank, Q3 reversing valve, and mixing or Q2 direct heating circuit.
Page 23 Water-to-water Heat Pump Diagram 7: Ground/water heat pump with combined water tank, Q3 pump for sanitary water, and mixing or direct heating circuit. Multifunctional inlets/outlets: RVS61 BX1-B4 BX2-B41 Diagram 8: Ground/water heat pump with combined water tank, Q3 reversing valve for sanitary water, and mixing or direct heating circuit.
Page 24 Water-to-water Heat Pump Diagram 9: Ground/water heat pump with combined water tank, Q3 reversing valve for sanitary water, solar collector and mixing or direct heating circuit. Multifunctional inlets/outlets: RVS61 QX5-Q5 QX6-K8 BX1-B4 BX2-B41 BX3-B42 BX4-B31 BX5-B6...
Page 25 Water-to-water Heat Pump Diagram 10: Ground/water heat pump with sanitary water tank, Q3 reversing valve, direct heating circuit and mixing cooling circuit for passive cooling Multifunctional inlets/outlets: RVS61 QX3-Y21...
Page 26 Water-to-water Heat Pump Diagram 11:TČ Ground/water heat pump with sanitary water tank, Q3 pump, hot water tank, mixing or direct heating circuit and mixing cooling circuit for passive cooling. Multifunctional inlets/outlets: RVS61 QX2-Y28 QX3-Y21 BX1-B4 BX2-B41 Diagam 23: Ground/water heat pump with combined water tank, with Q3 reversing valve, mixing or direct heating circuit and mixing cooling circuit for passive cooling.
Page 27 Water-to-water Heat Pump You can start by selecting a wiring diagram that does not comply with your heat pump and change the heat source for this diagram (example: the ground/water heat pump that you want to include in the heating system, as shown in diagram 5). Select diagram 5 (menu: Configuration, parameter 5700=5) and set heat source to 'Water' (menu: Configuration, parameter 5800=Water).
Page 28: Connection To Power Supply
Water-to-water Heat Pump 9. Connection to Power Supply The heat pump must be connected to the power supply grid. Connection to the grid must be made by an expert in compliance with applicable legislation and local regulations. The heat pump has a separate power supply line and controls supply line.
Page 29 Water-to-water Heat Pump Dovod črpalka izvor (črpalke voda/voda) Electric protection of the water-to-water (well water supplied) heat pump power supply line must be provided by the end-user or by the installation technician. Use installation circuit breaker, with characteristics corresponding the well pump. Electric connection shall be made with cable cord with adequate cross section diameter.
Page 30 Water-to-water Heat Pump Connecting Terminal Pins for Heat Pump Controller When connecting the heat pump to the power supply, the temperature sensors, circulating pumps and other elements also need to be installed. All elements are connected via inputs/outputs on the heat pump controller.
Page 31 Water-to-water Heat Pump Terminal Description Terminal Description Servicing tool LPB Temperature sensor heat pump riser line Servicing tool BSB Ground RF module AVS71.390 Temperature sensor riser line heating circuit 1 Expansions module Ground AVS75.390 Operating unit (HMI) Temperature sensor heat pump riser line LPB communication Ground data...
Page 32 Water-to-water Heat Pump...
Page 33: Electric Wiring Diagrams
Water-to-water Heat Pump 10. Electric Wiring Diagrams Dashed lines in the wiring diagram can be connected by the installation technician on site, if necessary. Wiring diagram ground/water...
Page 34 Water-to-water Heat Pump Wiring diagram water/water 17...
Page 35 Water-to-water Heat Pump Wiring diagram ground/water...
Page 36 Water-to-water Heat Pump Wiring diagram ground/water...
Page 37 Water-to-water Heat Pump Wiring diagram ground/water...
Page 38 Water-to-water Heat Pump Wiring diagram ground/water...
Page 39 Water-to-water Heat Pump Wiring diagram ground/water...
Page 40 Water-to-water Heat Pump Wiring diagram ground/water...
Page 41 Water-to-water Heat Pump 11. Operating of Heat Pump...
Page 42 Water-to-water Heat Pump Display Symbols are displayed on the display screen of the operating unit. The symbols are displayed according to the selected mode of operation and set parameters. Displayed symbols Xxxxxxxxxxxxxxxxxxxxxxxxxxx Xxxxxxxxxxxxxxxxxxxxxxxxxxx Xxxxxxxxxxxxxxxxxxxxxxxxxxx...
Page 43 Water-to-water Heat Pump Additional accessories (purchased separately) Additional accessories can be purchased separately to provide comfort and easy operation of the heat pump: a) ADVANCED ROOM OPERATING UNIT – used for setting the same adjustments as on the indoor unit, b) BASIC ROOM OPERATING UNIT –...
Page 44 Water-to-water Heat Pump Switching On When switching on the heat pump for the first time, the display turns on and the MAIN MENU is displayed. By pressing individual keys and turning the +/- (E) main navigation knob you can set various modes of operation of the heat pump and change parameters.
Page 45: Selection Of Language
Water-to-water Heat Pump Selection of Language English is set as the default language by the manufacturer. You can change the language selection of the messages shown on the display at any time. Press the OK (D) key and Time of Day and Date will appear on the display.
Page 46 Water-to-water Heat Pump Setting Time of Day and Date Press the OK (D) key and Time of Day and Date will appear on the display. Confirm the selection by pressing OK (D). The adjusted value of Time of Day (HOUR) flashes on the display. Turn the +/- (E) main navigation knob to the selected value.
Page 47: Timer Operation
Water-to-water Heat Pump Timer Operation This program is used for setting DAY and NIGHT operation modes. Confirm every selected setting by pressing the OK (D) key. Press the OK (D) key and Time of Day and Date will appear on the display. Turn the +/- (E) main navigation knob to Timer Operation –...
Page 48: Automatic Operation
Water-to-water Heat Pump operation flashes. Turn the +/- (E) main navigation knob and set the required time for end of operation (for example 22:00) and confirm the selection. Press the ESC (C) key several times to return to the MAIN MENU. If the unit is connected to more than one heating circuit, the Timer settings can be adjusted for each heating circuit individually (Timer Operation for Heating Circuit 1,...
Page 49 Water-to-water Heat Pump Continuous Operation Mode – Day and Night Operation Continuous Operation mode for maintaining the room temperature at the selected level. The heating operation is carried out according to the adjustment of the temperature for day and night operation mode (See Section: Setting Room Temperature).
Page 50 Water-to-water Heat Pump Heating Switch Off Characteristics of the Heating Switch Off: Heating is switched off (automatic operation and continuous operation mode in day and night operation); the temperature of operation complies with freeze protection operation mode (factory set temperature is 10°C), automatic change to Daylight Saving Time.
Page 51: Setting Of Room Temperature
Water-to-water Heat Pump several times to return to the MAIN MENU. Setting of Room Temperature a) Quick setting of day temperature (Day Operation Mode) Turn the +/- (E) main navigation knob. The currently selected room temperature flashes on the display. Confirm the selection.
Page 52 Water-to-water Heat Pump Switching Between Day and Night Operation Modes (only with Advanced Room Operating Unit) If the room will not be used for a shorter or longer period of time, press the (F) key to change to Night Operation Mode.
Page 53 Water-to-water Heat Pump (for example 4 – April), confirm the selection. The currently selected DAY of month flashes. Turn the +/- (E) main navigation knob to the selected day of the month (for example 26) and confirm the selection (the date of your return from holidays). Turn the +/- (E) main navigation knob one increment to the RIGHT.
Page 54 Water-to-water Heat Pump Operating the Heat Pump – Setting Feature “End-user” The case below indicates that some user levels do not support all settings (highlighted in the example below, while on the unit they can not be seen) Setting the Feature ‘Heating Engineer’...
Page 55 Water-to-water Heat Pump...
Page 56: Adjusting The Heating Curve
Water-to-water Heat Pump 12. Adjusting the Heating Curve The heating curve must be adapted to the geographic area and the design of the building in which it is installed so that the room temperature is maintained on a stable level, regardless of the changes in the outside temperature.
Page 57 Water-to-water Heat Pump Temperatura ogrevalnega voda 0,80 Temperatura okolice Example: with an outside air temperature of -8° C and a preset heating curve of 0.80, the heating line temperature demand is 42° C.
Page 58 13. Switching on Additional Heat Sources Switching on Additional Heat Source K27 Using the controller incorporated in the Gorenje heat pump, you can control the switching on (or off) of the additional heat source (gas furnace, oil heater) depending on the outside temperature.
Page 59 Water-to-water Heat Pump Switching on the Electric Heater in the K16 Hot Water Tank The electric heater in the K16 hot water tank switches on when water in the hot water tank needs to be heated, but the heat pump failure (Limit Source Temp. Min. Brine (too low of a temperature of the source)) prevents it.
Page 60 Water-to-water Heat Pump 14. Malfunctions MALFUNCTION POSSIBLE CAUSE WHAT TO DO? Heat pump fails to operate No supply voltage Provide power supply Operating unit reports Incorrect sequence of Change the phase error: phases on the three-phase sequence on the three- power input phase power input 3 phase current...
Page 61: Maintenance
Water-to-water Heat Pump 15. Maintenance In order to prevent damages to the heat pump, do not use the pump as a storage surface. Clean the outer surface of the pump with a damp cloth. To avoid causing damage to the surface, never use cleaning agents containing coarse particles, sodium carbonate, acids or chlorines.
Page 62 Water-to-water Heat Pump Use acid very carefully and take into account safety regulations and protection measures. When in doubt about how to use the chemicals, consult the manufacturer or the vendor. Heat Source System The water-to-water heat pump must be protected against impurities. Instal a filter at the heat inlet side on the heat pump.
Page 63 Water-to-water Heat Pump VALUATION OD CONCENTRATION IN COPPER LEAD>13° C CHARACTERISTICS THE AMBIENT (mg/l) Generated substances (organic) Ammonia < 2 2 to 20 > 20 Chloride < 300 > 300 < 10 µ S/cm Electric conductivity 10 to 500 µ S/cm >500 µ...
Page 64 Water-to-water Heat Pump...
