- EN -
7

Maintenance and cleaning

Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plugs of all the units in the water prior to reaching into the
water and commencing work.
The cleaning intervals depend on the water quality. Clean filter and screen of the Jumping Jet Rainbow
Star as soon as the quality of the water jet diminishes.
Cleaning filter and screen (Fig. Q – X)
1. Remove the locking screw (41) using an Allan key (18).
2. Turn the hood (40) counter-clockwise against the stop and lift off.
3. Lift the cover (42) and remove the O ring (43).
4. Turn the cover (42) upside down and suspend it on a pin at the container (44).
Important: Do not pull on the cables, otherwise they will be damaged.
5. Take the filter (4) including screen (45) out of the container.
6. Pull the filter (4) out of the screen (45) and carefully wash both.
7. If necessary, remove and clean the diffusor plate (46).
8. Reassemble filter (4) and screen (45) in the reverse order and reinsert into the container (44).
9. Place the O ring (43) on the rim of the cover (42) (Fig. V), then press the cover (42) uniformly onto the
container (44).
The O ring (43) is a roll ring that only adopts its final position when the cover (42) is put into place.
10. Remove the lugs of the two connection cables (47). To this effect, push the connection cables (47)
back into the cable duct at the container (44).
11. Place the hood (40) onto the container (44). Ensure that the contour of the cover (40) and that of the
container (44) are offset in relation to each other. Subsequently, turn the hood (40) clockwise up to
the stop.
8

Storage/Over-wintering

Put the Jumping Jet Rainbow Star out of operation at temperatures below zero. Thoroughly clean and
check the units for damage. Dry the Jumping Jet Rainbow Star and store it in a frost-free place.
24
