Installation of the 12V Master control box (Fig. F)
1. Push the ground stake (10) fully into the soil at the desired position, then slide the control box (5) onto
the ground stake (10).
2. As an alternative, the control box (5) can be screwed on using 4 screws (25) (not part of the scope of
delivery) inserted through the screw slots provided for this purpose in the housing of the control box (5).
Connection of the Jumping Jet Rainbow Star to the 12V Master control box (Fig. G, I)
The receiver integrated in the 12V Master control box is factory-connected to the transformer by the 12V
plug.
1. Insert the 5-pole plug (28) of the Jumping Jet Rainbow Star in the top socket (29) of the receiver and
secure with the two 4.8 mm self-tapping screws (11) (part of our delivery).
2. Insert the 2pole plug (26) of the Jumping Jet Rainbow Star in the left socket (27) of the transformer
and secure with the two M5 screws (12) (part of our delivery).
3. Place the protection hood (6) over the 12V Master control box (5). Ensure that the receiving aerial (34)
is unobstructed.
The IP X4 protection is only guaranteed when the protection hood is in place!
Connect the Jumping Jet Rainbow Star of the Add-On set to the 12V Master control box (Fig. H, I)
1. If necessary, remove the protection hood (6) from the 12V Master control box (5).
2. Remove the two screws from the cover (32) of the receiver, remove cover (32), insert the 5-pole
plug (28) of the Jumping Jet Rainbow Star in the socket (33) and secure with the two 4.8 mm self-
tapping screws (11).
3. Remove the two screws from the cover (30) of the transformer, remove cover (30), insert the 2-pole
plug (26) of the Jumping Jet Rainbow Star in the socket (31) of the transformer and secure with the
two M5 screws (12).
4. Place the protection hood (6) over the 12V Master control box (5). Ensure that the receiving aerial (34)
is unobstructed.
The IP X4 protection is only guaranteed when the protection hood is in place!
5

Start-up

Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plug (Figure J, 35) prior to reaching into the water and
commencing work.
Follow the safety information!
Pump and 12V Master control box switch on automatically once the power connection is established.
Switching on (Fig. J): Plug the power plug (35) into the socket.
Switching off (Fig. J): Disconnect the power plug (35).
