ASSEMBLY, MAINTENANCE, &
USER MANUAL
MODEL #SSGD100
WARNING
Read the assembly, installation, care, maintenance, and use
instructions in this manual prior to assembling and using this
equipment. Save this manual for future reference.
Ages: 4-8
Maximum occupancy: 3 users
Maximum weight: 81lbs each, Total weight limit 243 lbs.
Skywalker Holdings LLC
P.O. Box 574, Brigham City, UT 84302
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Skywalker Skywalker Sports Geo Dome
Summary of Contents for Skywalker Skywalker Sports Geo Dome
- Page 1 Save this manual for future reference. Ages: 4-8 Skywalker Holdings LLC Maximum occupancy: 3 users P.O. Box 574, Brigham City, UT 84302 Maximum weight: 81lbs each, Total weight limit 243 lbs.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Part List....................................3 Part Identification...............................4-5 Parts Location Drawing............................6 Assembly..................................7-12 Installation..................................13 Maintenance & Care Information.........................14 Geo Dome Safety information........................15 Instructions for Use...............................16 Warning Label Placement..........................17 Playground Surfacing Materials Information..................18 Limited Warranty..............................19 STOP EVERYTHING YOU'RE DOING AND REGISTER YOUR GEO DOME Find our warranty registration online by typing in: www.skywalkertrampolines.com/registration/ You'll need to have the following information handy: •... -
Page 3: Part List
BEFORE YOU BEGIN Thanks for choosing Skywalker Sports! We’re just as excited as you are to help your family live an active (but most importantly FUN) lifestyle. This model is one of our favorites, and we’re confident you’ll love it too. To make things easier for you, we’ve listed important information that you (and your little outdoor adventurers) need to know. -
Page 4: Part Identification
PART IDENTIFICATION Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares to the left (key numbers) will help you identify the parts during assembly. Blue tube (long) (x12) Yellow tube (x54) Green tube (long) - Page 5 Plate with 10 holes M8x12mm Bolt M8x10mm Bolt (x2) (x228) (x10) S5 Wrench (x1) M8 Washer (x238)
-
Page 6: Parts Location Drawing
PARTS LOCATION DRAWING (5) (2) Connection of Tube and Plate Plate (8) Plate (7) Plate (9) Tube Tube (10) (10) (10) (10) Tube (10) (10) ASSEMBLY STEP 1 Register your Geo Dome! For info on warranty registration, see page 2. - Page 7 STEP 2 Connect the tubes (1) to the bottom holes of the plates (7). Continue attaching until you have completed the bottom ring of the geo dome. Plate with 4 M8x12mm M8 Washer Blue tube long (x12) holes (x12) Bolt (x24) (x24) STEP 3 Connect the yellow tubes (2) to the top holes of the...
-
Page 8: Assembly
ASSEMBLY STEP 4 Connect the plates (8) at the two bottom holes to the tubes (2) from step 2. Continue attaching until you have attached all the plates to the tubes. Note: The poles for the next few steps do lean in towards the ground, you will need to pull them up towards you as you attach additional pieces. - Page 9 STEP 6 Plate with Plate with Plate with Yellow tube Green tube M8x12mm M8x10mm M8 Washer 10 holes 6 holes 5 holes (x12) Bolt (x48) Bolt (x10) (x58) (short) (x12) (x2) (x6) (x4) Using the parts to the above, connect two yellow tubes (2) to the top holes of two plates (8) that are side by side on the second ring of the geo dome.
- Page 10 ASSEMBLY STEP 7 Using the parts to the left, connect the Red tubes (5) at the side holes of the plates (8)&(9) from step 5. Continue attaching until you have attached all the tubes to the plates completing the third ring of the geo dome. NOTE: We found as you continue adding rings to the geo dome, you may have to shift the assembled bars around slightly in Red tube...
- Page 11 STEP 9 Connect the Yellow tubes (2) at the side holes of the plates (8) from step 7. Continue attaching until you have attached all the tubes to the plates completing the fourth ring of the geo dome. Yellow tube M8x12mm M8 Washer (x6)
- Page 12 ASSEMBLY STEP 11 Last step, you will attach the top of the Geo Dome. We have found this step can be a little easier if you have two people. Two people: Attach the blue tubes (6) to the one 6 hole plate (8). Now, one person will need to hold up the top piece while the other attaches each tube (6) to the top holes of the plates (8) on the geo dome.
-
Page 13: Installation
INSTALLATION WARNING! To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on the Geo Dome before assembly and use of this product. It is the responsibility of the owner and supervisors of this geo dome and its accessories to make sure all users obey the safety instructions printed in this material. -
Page 14: Maintenance & Care Information
MAINTENANCE & CARE INFORMATION Congratulations and high five on successfully assembling your new Skywalker Sports Geo Dome! Now, the best way to keep your new Geo Dome in tip-top shape, is to follow this checklist periodically: At the beginning of each play season: •... -
Page 15: Geo Dome Safety Information
GEO DOME SAFETY INFORMATION A Geo Dome is a recreational product. The information on this manual identify important safety precautions. The precautions are not all-inclusive, because a geo dome can be used in ways that this manual cannot cover completely. USING THE GEO DOME SAFELY Adult Supervision of Children Children using the geo dome must be supervised by adults at all times. -
Page 16: Instructions For Use
INSTRUCTIONS FOR USE To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use this equipment. Warnings and instructions for care, maintenance, and use of this teeter totter are included to promote safe enjoyable use of this equipment. -
Page 17: Warning Label Placement
Geo Dome Made in China • On-site adult supervision at all times. Skywalker Holdings, LLC • THIS PRODUCT IS INTENDED FOR USE BY CHILDREN P.O. Box 547 Brigham City, UT 84302 FROM AGES 4 TO 8, maximum weight of 81lbs each. -
Page 18: Playground Surfacing Materials Information
PLAYGROUND SURFACING MATERIALS The following information is from Section 4 of the United States Consumer Product Safety Commission’s (USCPSC) Outdoor Home Playground Safety Handbook for playground surfacing material. X3. SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK X3.1 Select Protective Surfacing —... -
Page 19: Limited Warranty
LIMITED WARRANTY Skywalker Holdings, LLC warrants its products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for three (3) years after the date of purchase. All other parts are warranted for one (1) year after the date of purchase. Warranty coverage extends only to the original retail purchaser from the date of original purchase. - Page 20 NOTE: Skywalker Holdings, LLC is not responsible or liable for indirect, special or consequential damaages arising out of or in connection with the use or performance of the product or other damages with respect to any econmic loss, loss of property, loss of revenue or profits, loss of enjoyment or use, cost of removal, installation or other consequential damages.
