Attach The Rear Wheels - HOMCOM CHILDREN’S ELECTRIC RIDE-ON A Owner's Manual

1WD
HINT: If your vehicle is Two Wheels Driving Type, see the next page please.
Rear driving wheel
11
5
1,2. Slide the gear box onto the rear axle (Left Side). Plug the connector on
motor into the connecotr on the vehicle body.
3. Slide the rear driving wheel onto the rear axle. And keep the driving wheel
match up with the gear box.
4. Slide the Ø12 washer onto the rear axle.
5. Tighten a locknut to the end of the rear axle with a spanner.
Tools required: Spanner
x2
6. Slide the washer onto the axle from the right side.
7. Slide the location bushing onto the rear axle.
8. Slide the rear normal wheel onto the rear axle.
9. Slide the Ø12 washer onto the rear axle.
10. Tight a locknut to the end of the rear axle with a spanner. HINT: An extra
spanner has been provided to hold the locknut on the other side of the
rear alxe while tightening the locknut on the other side.
11. Fit the hubcaps to the wheels on both sides.
Attach the Rear Wheels │ 9
Rear wheels are more bigger
than front wheels
4
3
2
6
1
7
2
Rear normal wheel
9
10
8
Rear axle
11
