340792RevB_Eng:NEW
TROUBLESHOOTING
To test the time switch:
The pilot light behind the ON/OFF button and time delay indicator light should
be ON when the switch is OFF. Press the ON/OFF button. The connected light or
fan comes ON. The pilot light behind the ON/OFF button turns OFF.
The connected light or fan should turn OFF in the number of minutes indicated
by the time selection indicator light. You can turn it OFF sooner by pressing the
ON/OFF button again.
Light or fan will not turn ON (pilot light is visible):
Press ON/OFF button. The connected light or fan should turn ON. If not:
• Check the light bulb and/or motor switch on the fan mechanism.
• Turn OFF power to the circuit then check wire connections.
Light or fan will not turn ON (no pilot light or indicator is visible):
• Shade the switch from external light to make sure that none of the indicator
lights on the switch are ON.
• Check the light bulb and/or motor switch on the fan mechanism.
• Make certain that the circuit breaker is ON and functioning.
• Turn OFF power to the circuit then check wire connections.
• Call 1.800.223.4185 for technical support.
Light or fan will not turn OFF:
• Press the ON/OFF button. If connected light or fan does not turn OFF, turn
OFF power to the circuit then check wire connections.
Visit our website at: www.passandseymour.com
10/23/08
10:54 AM
Page 2
