DB2002 and DB2004 bases for 2000 Series detectors
Terminal connections are as follows:
• Terminal 1 – Remote indicator (positive)
• Terminal 2 – Remote indicator (negative)
• Terminal 5 – Line in / out (positive)
• Terminal 6 – Line in / out (negative)
DB2003 base for IU2016 Loop Isolator
Terminal connections are as follows:
• Terminal 1 – Line in (positive)
• Terminal 2 – Line out (positive)
• Terminal 3 – Line in / out (negative)
DB2016 Isolating Base for 2000 Series detectors
Terminal connections are as follows:
• Terminal 1 – Remote indicator (positive)
• Terminal 2 – Remote indicator (negative)
• Terminal 5 – Line in / out (positive)
• Terminal 6 – Not used
• Terminal 7 – Line in (negative)
• Terminal 8 – Line out (negative)

Maintenance

Basic maintenance consists of a yearly inspection. Do not
modify internal wiring or circuitry.
Testing the isolator
To test the isolator, provoke a short circuit in the loop and
check that the corresponding LED is activated.

Specifications

DB2002, DB2003, and DB2004
Number of terminals:
DB2002, DB2004
DB2003
Earth contact
Remote indicator option
IP Rating
Operating temperature
Storage temperature
Relative humidity
Colour
Dimensions
DB2002, DB2003
DB2004
Weight:
DB2002, DB2003
DB2004
2 / 16
4
3
Yes
Yes (DB2002, DB2004 only)
IP30
−10 to +50ºC
−10 to +70ºC
10 to 95% noncondensing
White
Ø 100 × 9 mm
Ø 100 × 17 mm
38 g
41 g
DB2016
Operating voltage
Current consumption:
Standby
Isolated
Passing
Line resistance
Number of terminals
Earth contact
Remote indicator option
IP rating
Operating temperature
Storage temperature
Relative humidity
Colour
Dimensions
Weight

Regulatory information

This section provides a summary on the declared performance
according to the Construction Products Regulation (EU)
305/2011 and Delegated Regulations (EU) 157/2014 and (EU)
574/2014.
For detailed information, see the product Declaration of
Performance (available at www.utcfssecurityproducts.eu).
EU compliance
Certification body 0786
Manufacturer
Thunderous Sounders Electronics Co. Ltd.,
No, 21, Kai Fe 3rd, Pao En Industrial Area,
Ren De Village, Tainan, Taiwan, R.O.C.
Authorized EU manufacturing representative:
UTC Fire & Security B.V., Kelvinstraat 7, 6003
DH Weert, Netherlands
Year of first CE 09
marking
Declaration of 360-4227-0699
performance number
Product identification DB2016
Intended use See the product Declaration of Performance
See the product Declaration of Performance
Declared
performance
EN 54 EN 54-17:2005 + AC:2007

Contact information

For contact information, visit www.utcfssecurityproducts.eu.
P/N 10-4227-501-DB20-05 • ISS 05DEC16
17 to 34 VDC
(28 VDC nominal)
< 30 µA
< 1.6 mA
Max. 800 mA
0.1Ω
5
Yes
Yes
IP30
−10 to +50ºC
−10 to +70ºC
10 to 95% noncondensing
White
Ø 100 × 13 mm
49 g
