- Page 1 3950 NW 120 Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760 CHRY MULTI-CAM Dodge/Jeep uConnect (RA4) Interface with 6 video inputs NTV-KIT764 10/04/18 NTV-DOC266...
-
Page 2: Kit Content
(KIT764): Same functionality as the standard system, but includes a data-controlled SVS-6 switcher capable of adding 6 additional video inputs all while retaining any existing OEM cameras. NOTE: The CHRY MULTI-CAM kit is required for RAMs that have an OEM Cargo Camera or to emulate the Cargo Camera menu. - Page 3 10/04/18 NTV-DOC266 CHRY MULTI-CAM pin out PIN # Description Color 12v (+) Constant Yellow INPUT 1: VIM Activation* --NOT USED-- Blue INPUT 3: Front CAM/Cargo Cam Pink OUTPUTs 2 & 3 (selectable) send 12v (+) with (RX) INPUT (UART control from SVS-6 TX)
- Page 4 10/04/18 NTV-DOC266 Dash Disassembly (basic RAM) 1. Remove the Torx t20 screw at the right rear of the pocket on the right side of the dash. 2. Remove (2x) Torx t20 at the top of the dash. They are hidden beneath a rubber mat. 3.
- Page 5 10/04/18 NTV-DOC266 CHRY MULTI-CAM Module Installation 1. After removing the factory radio, grab the provided Plug & Play T-harness and connect the female side to the factory 44-pin plug. Make certain the lock connects together securely. 2. Install all cameras and run signal/power leads into the front dash opening. Note: 12v ACC is provided from output 1 (PIN 11, white/red).
- Page 6 10/04/18 NTV-DOC266 This page is ONLY used for 2013-2015 RAM vehicles, when the user wants both OEM cameras (cargo & tailgate) to display on the 8.4” screen (Cargo normally shows on mirror). For 2016 RAM, continue to next page instead. •...
- Page 7 10/04/18 NTV-DOC266 This page is ONLY used for 2016 RAM vehicles, when the user wants to add an aftermarket Cargo Camera and be able to select (view) it exactly like factory (touch icons while in reverse or from Cargo Cam Menu). For ‘13-‘15 RAM, see previous page (6) instead.
- Page 8 10/04/18 NTV-DOC266 CHRY MULTI-CAM Install Diagram SVS-6 for UART control must be in this configuration Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of its product.
- Page 9 10/04/18 NTV-DOC266 CHRY MULTI-CAM with AUX AV Install Diagram SVS-6 for UART control must be in this configuration SVS-6 Module Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of its product.
- Page 10 10/04/18 NTV-DOC266 CHRY MULTI-CAM Programming Programming the CHRY MULTI-CAM is performed in the vehicle, through the factory dash MUTE button, TUNING KNOB, and CLUSTER LCD for feedback (true LCD cluster-equipped vehicles only) While in NAV-TV Press and HOLD settings mode only:...
- Page 11 RELAY: Uses RCA inputs on the UCTv2 module itself (UCTv2) RELAY / AVSW / SWITCH AVSW: Select when using AVSW board (UCTv2+) SVS-6 SVS-6: Select when using SVS-6 switcher (CHRY MULTI-CAM) OEM / OEM: Vehicle has a manufacturer-installed reverse camera. AFTERMARKET / AFTERMARKET: Any aftermarket reverse camera.
- Page 12 10/04/18 NTV-DOC266 Programming for 2016+ Vehicles equipped with Panasonic Radios (CarPlay/Android Auto) • For 2016+ vehicles equipped with the new Panasonic radio, if adding a rear camera, the method for activating rear-camera has changed and requires additional (startup/shut down) steps. Follow the procedure below after programming desired options in the NAV-TV cluster menu in these vehicles: 1.
- Page 13 10/04/18 NTV-DOC266 CHRY MULTI-CAM Force Buttons Force front camera: Press AUX: Hold both ‘SCREEN Force rear camera: & hold (2 sec) to activate OFF’ & ‘BACK’ (2 sec) Press & hold (2 sec) CIM*: Hold (3 sec) to activate (not supported...
- Page 14 10/04/18 NTV-DOC266 CHRY MULTI-CAM Operation Information Rear Camera Operation: Placing the vehicle in to reverse will automatically display any connected camera. This image will take precedence over all other images. Force Rear Camera: To force rear camera, press and hold radio ‘BACK’ button for 2 seconds.
- Page 15 10/04/18 NTV-DOC266 CHRY MULTI-CAM Operation Information (continued) Turn Signal Cameras: To display TSCs, simply use the turn signals as you would normally and the connected image will display either all the time (while in drive), or only after 25, 30 or 35 mph respectively, depending on what was set in MULTI- CAM programming.
- Page 16 10/04/18 NTV-DOC266 FAQs Q1. I can’t get into programming mode. A1. Turn off the vehicle and remove the key. Close all points of entry and use the remote to lock the vehicle. Wait approx. 5 minutes without opening or disturbing the vehicle. Unlock and cycle the ignition to the ‘RUN’ position. Make certain that the cluster is in FM radio mode before you begin programming;...
- Page 17 10/04/18 NTV-DOC266 Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is intended for off-road use and passenger entertainment only.
