Monitor Group: Menu Mon - Vacon 20 CP/X Applications Manual

vacon • 13
2.2

Monitor group: menu MON

®
VACON 20 CP/X AC drive provides you with a possibility to monitor the actual values of pa-
rameters and signals as well as statuses and measurements. Some of the values to be moni-
tored are adjusted. See Table 3 in which the basic monitoring values are presented.
Code Monitoring value
V1.1 Output frequency
V1.2 Frequency reference
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor shaft power
V1.7 Motor voltage
V1.8 Motor temperature
V1.9 DC link voltage
V1.10 Unit temperature
V1.11 Board temperature
V1.12 Analogue input 1
V1.13 Analogue input 2
V1.14 Exp. Analogue input
V1.15 Analogue output
V1.16 Exp. Analogue out 1
V1.17 Exp. Analogue out 2
V1.18 DI1, DI2, DI3
V1.19 DI4, DI5, DI6
V1.20 DI7, DI8, DI9
V1.21 DI10, DI11, DI12
V1.22 RO1, RO2, DO
V1.23 EO1, EO2, EO3
V1.24 Process variable
V1.25 PID setpoint
V1.26 PID error value
V1.27 PID feedback
V1.28 PID output
V1.29 Temperature sensor 1 °C or °K
V1.30 Temperature sensor 2 °C or °K
V1.31 Temperature sensor 3 °C or °K
Values V1.25-28 are hidden when PID output is not used as frequency reference.
Values V1.14, V1.17 are hidden when OPTB4 expansion board is not installed. Value V1.16 is hidden
when OPTB4-BF expansion board is not installed. Value V1.20, V1.21 are hidden hidden when no
NOTE!
expansion board with available inputs is installed. Value V1.23 is hidden when no expansion board
with available outputs is installed. Values V1.29, V1.30, V1.31 are hidden when OPTBH expansion
board is not installed.
2
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Unit ID
Hz 1
Hz 25
rpm 2
A 3
% 4
% 5
V 6
% 9
V 7
°C 8
°C 1825
% 13
% 14
% 1837
% 26
% 1838
% 1839
15
16
1835
1836
17
1852
29
% 20
% 22
% 21
% 23
1860
1861
1862
Table 3. Monitoring menu items.
Description of Groups
Description
Output frequency to motor
Frequency reference to motor control
Motor speed in rpm
Calculated shaft torque
Total power consumption of AC drive
Calculated motor temperature
Heatsink temperature
Power board temperature
Analogue input AI1
Analogue input AI2
Analogue input on OPTB4
Analogue output
Analogue output 1 on OPTB4-BF
Analogue output 2 on OPTB4
Digital inputs status
Digital inputs status
Digital inputs on OPTB1 status
Digital inputs on OPTB1 status
Digital outputs status
Expansion board digital outputs status
Scaled process variable
See parameter P7.10
PID controller setpoint
PID controller error
PID controller actual value
PID controller output
OPTBH sensor 1
OPTBH sensor 1
OPTBH sensor 1
