Expansion PSTN Box CPN10
Quick Start Guide
PSTN box CPN10 is used to connect CP860/CP920
conference phones or video conferencing systems to
the PSTN (Public Switched Telephone Network). It is
a cost-effective solution for PSTN office. Up to 2
cascaded PSTN Boxes can be installed to
CP860/CP920 conference phones or video confer-
encing systems, which allows you to experience the
local three-way conference conveniently in excellent
speech quality with PSTN. You can also record the
calls with a USB flash drive when using the PSTN box.
Package Contents
PSTN Box
3m PSTN
Double-side
Quick Start Guide
CPN10
Cable
Tape
1
Advertisement
Related Manuals for Yealink CPN10
Summary of Contents for Yealink CPN10
- Page 1 Expansion PSTN Box CPN10 Quick Start Guide PSTN box CPN10 is used to connect CP860/CP920 conference phones or video conferencing systems to the PSTN (Public Switched Telephone Network). It is a cost-effective solution for PSTN office. Up to 2 cascaded PSTN Boxes can be installed to...
-
Page 2: Hardware Component Instructions
Hardware Component Instructions USB Plug PSTN Port USB Port Installing the Expansion PSTN Box PSTN Port Optional USB device USB port on your phone Note: USB flash drive should be purchased separately. Installing two PSTN boxes for three-way local conference, as shown below: USB port on your phone You can fix the two cascaded PSTN boxes by the double-side tape. -
Page 3: Configuring The Pstn Account
Configuring the PSTN Account When PSTN box is connected successfully, your screen prompts you go to the PSTN account screen. Configuring the PSTN account: 1. Press OK key to enter the PSTN account screen. 2. Select the desired PSTN account. 3. - Page 4 Viewing the PSTN Account Status If you are using CP860/CP920 conference phone, do one of the following: Press OK key when the phone is idle, and then press More->Accounts. Navigate to Menu->Status->More->Accounts. If you are using video conferencing system, do the following: 1.
- Page 5 PSTN转接盒CPN10快速入门指南 PSTN转接盒CPN10实现了CP860/CP920会议话机或 会议电视终端与PSTN（公共交换电话网络）网络的自 由连接，为只有PSTN接口的中小型会议室，提供高效 便捷的解决方法。一台CP860/CP920会议话机或会议 电视终端最多支持2个转接盒级联，你可以使用这种级 联方式在PSTN网络中进行三方会议通话。PSTN转接 盒带有USB接口，你可以在通话中连接U盘进行录音。 包装清单 PSTN转接盒 3米 PSTN 线 双面胶 快速入门指南 CPN10...
- Page 6 硬件介绍 USB 插头 USB 接口 PSTN 接口 连接转接盒 PSTN 接口 可选的USB设备 话机上的USB端口 说明：USB设备需要另外购买。 PSTN转接盒级联（实现PSTN三方会议），如下所示： 话机上的USB端口 你可以使用附带的双面胶固定两个转接盒。...
- Page 7 设置模拟电话线路账号 PSTN转接盒连接成功后，液晶界面提示你进入模拟 电话线路设置界面。 设置模拟电话线路： 1. 选择确定进入模拟电话线路设置界面。 。 2. （可选）选择相应的模拟电话线路 3. 选择启用或禁用模拟电话线路。 4.（可选）输入模拟电话线路的标签。 5. 保存操作。 模拟电话线路也可以通过以下路径设置: 对于CP860/CP920会议电话：导航至菜单->设置-> 高级设置（默认密码：admin）->账号。 对于会议电视终端：导航至更多->设置->高级设置 （默认密码：0000）->模拟电话线路。 设置默认账号（只适用于CP860/CP920会议电话）： 1. 按菜单->设置->高级设置(默认密码：admin)-> 账号。 2. 选择相应的模拟电话线路。 3. 按默认软键。...
- Page 8 查看模拟电话线路状态 对于CP860/CP920会议电话执行以下任一操作： 在待机界面按OK键，然后按更多->账号。 导航至菜单->状态->更多->账号。 对于会议电视终端执行以下操作： 1. 导航至更多->状态->账号。...
