EMG 57-TW Installation Information

INSTALLATION INFORMATION
EMG MODELS: 57-TW/66-TW SET
SPECIFICATIONS:
Logo Color
Magnet Type*
Resonant Frequency (KHz)
Output Voltage (String)
Output Voltage (Strum)
Output Noise (60 Hz)
Output Impedance (Kohm)
Current @9V (Microamps)
Battery Life (Hours)
Maximum Supply (Volts DC)
*Note: Magnet Type: A (Alnico) A/S (Alnico/Steel) C (Ceramic) C/S (Ceramic/Steel)
**Note: Logo Colors are not distinguished on the Metalworks Sets
Installation notes:
All EMG Pickups are compatible with each other. EMG accessories, the VLPF, EXG, SPC or RPC Controls can be added to any EMG Pickup System
without requiring an extra battery. DO NOT reconnect the bridge ground wire, EMG Pickups do not require string grounding. Use the 25K Ohm
controls that are included for best results. If your output jack is a long panel style you will need a stereo jack, use a SwitchCraft 152B , soldering
will be required (see the bottom of page 2). Adjust the pickup level to the strings, and at a distance that works for you, experiment. Alternate
wiring diagrams are available at; emgpickups.com.
Included IN THE SYSTEM:
2 TONE CONTROLS (25K)
.235 (6)
.390
.310 (8)
(10)
BATTERY
ADJUSTMENT
BUSS
SCREWS & SPRINGS (2 pr)
Warranty
All EMG Pickups and accessories are warranted for a period of two years. This warranty does not cover failure due to improper installation, abuse or damage. If
upon examination the pickup is determined to be defective, a replacement will be made. Warranty replacement products are covered by this same warranty. This
warranty covers only those pickups and accessories sold by authorized EMG Dealers. This warranty is not transferable.
© 2019 Copyright EMG INC. All Rights Reserved.
1.087*
*
The TW is taller than the typical EMG Pickup,
Be sure to it will fit in your guitar before you start the installation.
L1 L2
L3
In Dual-coil mode, coils L1 and L2 are active.
The 57-TW in Single-coil mode, coils L2 and L3 are active.
The 66-TW in Single-coil mode, coils L1 and L3 are active..
MODEL:
57-TW Single-Coil
Copper
A/S
3.47
2.00
3.00
-107
10
160
1500
27
2 TW P/P SWITCH
W/POT (25K)
2 PICKUP IN/ OUT
BATTERY BUSS
STEREO OUTPUT
JACK
.900 (22.8)*
EMG 66-TW
L1 L2
L3
EMG 57-TW
Dual-Coil 66-TW
Copper
A/C
1.77
3.00
4.50
-107
10
TW PICKUP CABLE 16" (40.64cm)
TW PICKUP CABLE 11" (27.94cm)
B245
4 CONNECT CABLES 5.5" (14cm)
OUTPUT CABLE 6" (15cm)
BATTERY CABLE 7" (18cm)
- 9V +
2.75
(69.8)
1.50
(38.1)
3.09
(78.5)
2.75
(69.8)
1.50
(38.1)
3.09
(78.5)
3/48 MOUNTING HOLES
Single-Coil Dual-Coil
3.47 1.77
2.00 3.00
3.00 4.50
-107 -107
10 10
