Item #:1003369084
Model #:TRS43GA
USE AND CARE GUIDE
South Grove Firepit Set
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this repit set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY TRS43GA
Summary of Contents for HAMPTON BAY TRS43GA
- Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............5 Safety Information ............2 Planning Assembly ..............5 Hardware Included ..............5 Product Caution ..............2 South Grove Firepit Set Package Contents........ 6 Safety Warnings ..............2 Warranty ................ -
Page 3: Important Safety Instructions
Important Safety Instructions (continued) WARNING: For Outdoor Use Only Installation and service must be performed by a qualified installer, service agency, or the gas supplier. Warning: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. •... - Page 4 Important Safety Instructions (continued) WARNING WARNING If the appliance is not in use, the gas must be turned off at the supply cylinder. Keep the appliance area clear and free from Storage of an appliance indoors is permissible only combustible materials, gasoline, and other if the cylinder is disconnected and removed from the flammable vapors and liquids.
-
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 6: South Grove Firepit Set Package Contents
Pre-Assembly (continued) RIVER CROSSING 5PC CUSHION FIREPIT SET PACKAGE CONTENTS Part Description Quantity REAR FRAME FRAME A FRAME B FRONT DOOR CROSS BRACE TANK SUPPORT ASSEMBLY TANK FASTENER TABLE TOP LAZY SUSAN GLASS... -
Page 7: Assembly
Assembly Connecting the frame A and the frame B to the rear frame Fasten the frame A (B) and the frame B (C) to the rear frame (A) by using M6x15 bolts (AA). Keep the bolts loose. NOTE: Loosely tighten all the bolts using the hex wrenches (FF and GG). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. - Page 8 Assembly(continued) Connecting the cross brace to frames Place both ends of the cross brace (E) on top of the bottom tabs on the frames (B and C). Fasten them together by using bolts (AA). Completely tighten all of the bolts. NOTE: Loosely tighten all the bolts using the hex wrenches (FF and GG).
- Page 9 Assembly (continued) Connecting the tank support assembly to the front door Fasten the wheels (KK) to the tank support assembly (F) by using nut wrench (HH). Fasten the tank support assembly (F) to the front door (D) by using bolts (AA). Insert the tank fastener (G) into the tabs on the front door (D) and fasten them together by using washers (CC) and nuts (DD).
- Page 10 l (continued) Assembly Connecting the lower connector into the holes in the frame B Fasten the lower connector (II) to the corner of the bottom rim on the frame B (C) by using bolt (AA). Then, insert the front door (E) into the connector tab on the lower connector (II).
- Page 11 Assembly(continued) Connecting the upper connector into the front door Insert the upper connector (JJ) into the top holes in the front door (D). Fasten the upperconnector (JJ) to the frame B(C) by using bolt (AA). NOTE: Loosely tighten all the bolts using the hex wrenches (FF and GG). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 12 Assembly(continued) Fixing the table top into the frame assembly Place the table top (H) on to the frame assembly. Fasten them together by using bolts (BB), washers (CC), and plastic nuts (EE). Make sure that all of the bolts have been tightened completely. NOTE: Loosely tighten all the bolts using the hex wrenches (FF and GG).
- Page 13 Assembly(continued) Placing the tank into the tank support assembly HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 14 Assembly(continued) Attaching the tank to the table top connector Attach the table top (H) to the tank by rotating clockwise to its connector. Caution: The Tank must face this way. Rotate Clockwise...
- Page 15 Assembly (continued) Placing the glass Place the glass (J) into the steel cover. Fire shield Note: As shown in the Figure: The glass cannot be Please remove the glass beans exposed over top of the from the fire shield and make the fire shield be exposed steel cover surface.
- Page 16 Assembly (continued) Placing the lazy susan on the table top Place the lazy susan (I) on to the table top (H) to cover the glass set.
- Page 17 INSTRUCTIONS FOR REMOVING THE TANK Removing the tank from the table top connector To remove the fuel supply hose from the tank, rotate counter-clockwise. Close the valve tightly before removing the tank. NOTE: Counter-Clockwise FOR YOUR SAFETY: Surfaces of fire pit can remain extremely hot for a period after use.
- Page 18 INSTRUCTIONS FOR REMOVING THE TANK Removing the tank from the table top connector Remove the tank from the tank-support assembly and through the tank fastener. To replace the tank, repeat Step 6 and Step 7 in NOTE: the assembly instructions.
- Page 19 OPERATION Switch Usage Instruction OFF/Arrêt OFF/Arrêt LOW/ OFF/ Arrêt Min. LOW/ Allu- OFF/ Arrêt Min. mage Allu- mage CLOSE OPEN Max. Max. Lighting Adjusting and Shutting Down Open the igniter button and install an AAA battery If the burner is not lit, press down the control knob (not included), then secure the cap back on.
-
Page 20: Care And Cleaning
Read the following switch usage instructions for lighting and to extinguish: Step 4 Step 3 Instructions for lighting and shutting down the appliance: 1. Read instructions before lighting. 2. Press down the control knob to " LOW ", at the same time push in the ignition button and keep the button depressing for 15 seconds. - Page 21 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
