USE AND CARE GUIDE
Gas Fire Pit Table
・
・
・
・
・
・
・
・
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-841-1350
HOMEDEPOT.COM
improvement needs. Thank you for choosing Hampton Bay!
DANGER
LEAKING LP- GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED
CAUSING SERIOUS BODILY INJURY OR DEATH.
CONTACT THE LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS
WARNING
DO NOT USE OR STORE THE CYLINDER IN A BUILDING,
WARNING:
Know the odor of LP-gas. If you hear, see or smell
leaking LP-gas, immediately get everyone away
,
from the cylinder and call the Fire Department.
Do not attempt repairs.
Caution your LP-gas supplier to:
Be certain the cylinder is purged of trapped air prior to
LP-gas is heavier than air and may settle in low places
when dissipating.
Contact with the liquid contents of the cylinder will cause
freeze burns to the skin.
Do not allow children to tamper or play with the cylinder.
When not connected for use, keep the cylinder valve
turned off. Self contained appliances shall be limited to a
cylinder of 30 lb capacity or less.
Do not use, store or transport the cylinder where it would
be exposed to high temperatures. The relief valve may
When transporting, keep the cylinder secured in an upright
position with the cylinder valve turned off.
DO NOT REMOVE, DEFACE, OR OBLITERATE THIS LABEL
*EXCEPT AS AUTHORIZED BY ANSI/NFPA 58.
DANGER. Do not store a spare LP cylinder under or near a barbecue grill, or other
serious injury may occour.
THANK YOU
Item #1006 351 087
Model #GFT-31802
·
FLAMMABLE GAS UNDER PRESSURE.
CYLINDER OR UNUSED LP-GAS.
·
FOR OUTDOOR USE ONLY.*
GARAGE OR ENCLOSED AREA.
WHEN CONNECTING FOR USE:
・
Use only in compliance with applicable codes.
・
Read and follow the manufacturer's instructions.
・
Consult the manufacturer's instructions
concerning the cylinder connection provided
with your appliance.
・
Be sure the regulator vent is not pointing up.
・
Turn off all the valves on the appliance.
・
Do not check for gas leaks with a match or open
Open the cylinder valve. If bubbles appear, close
the valve and have an LP-gas service person
make any needed repairs. Also, check the
appliance valves and connections to make sure
they do not leak before lighting the appliance.
・
Light the appliance(s) following the
manufacturer's instructions.
・
When the appliance is not in use, keep the
cylinder valve closed.
X
Pressure relief valve
Cylinder
X
X
Cylinder valve hand wheel
Point of connection
X
X
Liquid level indicator
(optional)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GFT-31802 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAMPTON BAY GFT-31802

Summary of Contents for HAMPTON BAY GFT-31802

  • Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HOMEDEPOT.COM THANK YOU continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ..............2 Hardware Included............5 Safety Information...............2 Package Contents............6 Warranty................5 Assembly..………………………………………………….7 What is Covered..............5 Operating Instructions ............11 What is Not Covered............5 Maintenance...............14 Pre-Assembly..……………………...……………………. 5 Care and Cleaning...............14 Planning Assembly..
  • Page 3 Safety Information (continued) You must provide the propane gas and propane cylinder. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Lique ed Petroleum Gas, ANS/NFPA 58.
  • Page 4 Safety Information (continued) Solid fuels shall not be burned in this appliance. The installation must conform with local codes or, in the absence of local codes, ANSIZ223. 1/NFPA54, NFPA58 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).

  • Page 5: Warranty

    Warranty 1 YEAR LIMITED WARRANTY WHAT IS COVERED We warrant the metal frame to be free of manufacturing defects to the original purchaser for one year. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charge to and from our service center. This warranty does not cover s warranty.

  • Page 6: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Description Part Quantity Side panel Glass beads Side panel with window Back panel Table top with burner Leg D Door Leg E Gas tank support Cross bar Leg F AAA battery Leg G...

  • Page 7: Assembly

    Assembly Assembling the legs □ Attach leg (D), leg (E), leg (F) and leg (G) to the table top with burner (C) using eight (8) M6 x12 mm bolts (AA). □ Do not tighten the bolts at this step. Assembling the side panels □...
  • Page 8 Assembly (continued) Assembling the back panel □ Attach the back panel (J) to legs (E/D) using four (4) M6 x 12 mm bolts (AA). Assembling the gas tank support □ Attach the gas tank support (L) to the side panels (H/I) using four (4) M6 x 12 mm bolts (AA).
  • Page 9 Assembly (continued) Assembling the cross bar Attach the cross bar (M) to the bottom of the back panel (J) and □ to the gas tank support (L) using two (2) M6 x 12 mm bolts (AA). Tighten all the bolts (AA) with a Phillips screwdriver (not included). □...
  • Page 10 Assembly (continued) Assembling the cylinder □ Put the cylinder into the gas tank support (L), and secure the cyliner by tightening the screw in the gas tank support (L). Connect the hose and regulator to the cylinder. □ are not placed on the ignition portion of the burner. NOTE: The propane cylinder is sold separately.

  • Page 11: Operating Instructions

    Operation WARNING: Never use this appliance for other than the intended use. DO NOT use this appliance to prepare food. Initial Lighting: of internal paints and lubricants used in the manufacturing process and does not occur again. Simply run the main burner on high for approximately one-half hour.
  • Page 12 Operation (continued) LEAK TESTING OPERATION WARNING: A leak test must be performed annually or if a part of the gas system is replaced. WARNING: LEAK TESTING: This must be done before initial use, annually, and whenever any gas components are replaced or serviced. Do not smoke while performing this test, and remove all sources of ignition.
  • Page 13 Operation (continued) LIGHTING INSTRUCTIONS 1. Press and hold electronic igniter button. WARNING 2. Turn the burner control to the low position, press and hold. When the burner FOR YOUR SAFETY: lights, release the electronic igniter button. Keep face and body away from burner area when lighting.

  • Page 14: Maintenance

    Maintenance Storage between uses: □ Turn the control knob to the “OFF” position. □ Disconnect the LP source. □ Store the re pit upright in an area sheltered from direct contract with inclement weather( such as rain, sleet, hail, snow dust and debris). □...

  • Page 15: Troubleshooting

    Troubleshooting PROBLEM PROBLEM CAUSE SOLUTION The propane lighting procedure Ensure the lighting procedure is followed carefully. The valve must be was not followed correctly. in the off position when the tank valve is turned on. Turn the tank on when the valve is turned to high.

  • Page 16: Service Parts

    Service Parts Part Description Quantity Quantity Part Description Back panel Door Glass beads Gas tank support Table top with burner Cross bar Leg D Leg E AAA battery Leg F M6 x 12 mm bolt M5 x 12 mm bolt Leg G Side panel M6 x 20 mm bolt...
  • Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HOMEDEPOT.COM Retain this manual for future use.
