USE AND CARE GUIDE
River Crossing Firepit Set
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
y through the purchase of this sectional set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRS40G2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY TRS40G2

  • Page 1 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............2 Pre-Assembly ..............5 Safety Information ............2 Planning Assembly ..............5 Hardware Included ..............5 Product Caution ..............2 River Crossing Firepit Set Package Contents......6 Safety Warnings ..............2 Warranty ................
  • Page 3 Important Safety Instructions (continued) WARNING: For Outdoor Use Only Installation and service must be performed by a qualified installer, service agency, or the gas supplier. Warning: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. •...
  • Page 4 Important Safety Instructions (continued) WARNING WARNING If the appliance is not in use, the gas must be turned off at the supply cylinder. Keep the appliance area clear and free from Storage of an appliance indoors is permissible only combustible materials, gasoline, and other if the cylinder is disconnected and removed from the flammable vapors and liquids.
  • Page 5: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
  • Page 6 Pre-Assembly (continued) RIVER CROSSING 5PC CUSHION FIREPIT SET PACKAGE CONTENTS Part Description Quantity REAR FRAME FRAME A FRAME B CROSS BRACE BOTTOM FRAME FRONT DOOR BTABLE TOP COVER GLASS...
  • Page 7: Assembly

    Assembly Connecting the frame A and the frame B to the rear frame Fasten the frame A (B) and the frame B (C) to the rear frame (A) by using M6x40 bolts (AA). Keep the bolts loose. NOTE: Loosely tighten all the bolts using the hex wrenches (EE and FF). HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 8 Assembly(continued) Connecting the bottom frame and the cross brace to frames Fasten the bottom frame (E) and the cross brace (D) to frames (B and C) by using M6x25 bolts (BB) and ST4.8x16 screws (DD). NOTE: Loosely tighten all the bolts using the hex wrenches (EE and FF).
  • Page 9 Assembly(continued) Connecting the lower connector to the corner of the bottom rim of the frame B Fasten the lower connector (GG) to the corner of the bottom rim of the frame B (C) by using M6x15 bolt (CC). Then, insert the front door (F) into the connector tab of the lower connector (GG). NOTE: Loosely tighten all the bolts using the hex wrenches (EE and FF).
  • Page 10 Assembly(continued) Connecting the upper connector into the holes in the front door Insert the upper connector (HH) into the holes in the front door (F). Fasten the upper connector (HH) to the frame B (C) by using M6x15 bolt (CC).Completely tighten all of the nuts and bolts. Close the doors. NOTE: Loosely tighten all the bolts using the hex wrenches (EE and FF).
  • Page 11 Assembly(continued) Connecting the table top onto the frame assembly Place the table top (G) onto the frame assembly. Fasten them together by using M6x15 bolts (CC). Make sure that all of the bolts have been tightened completely. NOTE: Loosely tighten all the bolts using the hex wrenches (EE and FF). Igniter Valve HAMPTONBAY.COM...
  • Page 12 Assembly(continued) Connecting the front door and place the tank into the bottom frame Open the front door (F) and place the tank into the bottom frame (E). Secure in place by using the plastic screw. Plastic Screw...
  • Page 13 Assembly(continued) Connecting the table top Attach the table top (G) to the tank by rotating clockwise to its connector. Caution: The Tank must face this way. Rotate Clockwise HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 14 Assembly(continued) Connecting Place the glass Place the glass (I) into the steel cover. Fire Shield Note: Note: The glass cannot be The re shield on the exposed over top of the steel burner system must be cover surface. exposed.
  • Page 15 Assembly(continued) Connecting Place the cover onto the table top Place the cover (H) onto the table top (G) to cover the glass set. To repair any scratches on the table top, use the touch-up paint for table top (GG) provided. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 16 INSTRUCTIONS FOR REMOVING THE TANK Removing the tank from the table top connector To remove the fuel supply hose from the tank, rotate counter-clockwise. Close the valve tightly before removing the tank. NOTE: Counter-Clockwise FOR YOUR SAFETY: Surfaces of fire pit can remain extremely hot for a period after use.
  • Page 17 INSTRUCTIONS FOR REMOVING THE TANK Removing the tank from the table top connector Remove the tank from the tank-support assembly and through the tank fastener. To replace the tank, repeat Step 6 and Step 7 in NOTE: the assembly instructions. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 18 OPERATION Switch Usage Instruction OFF/Arrêt OFF/Arrêt LOW/ OFF/ Arrêt Min. LOW/ OFF/ Arrêt Allu- Min. mage Allu- mage CLOSE OPEN Max. Max. Lighting Adjusting and Shutting Down Open the igniter button and install an AAA battery If the burner is not lit, press down the control knob (not included), then secure the cap back on.
  • Page 19: Care And Cleaning

    Read the following switch usage instructions for lighting and to extinguish: Step 4 Step 3 Instructions for lighting and shutting down the appliance: 1. Read instructions before lighting. 2. Press down the control knob to " LOW ", at the same time push in the ignition button and keep the button depressing for 15 seconds.
  • Page 20 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
  • Page 21 We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
  • Page 22 Table of Contents Table of Contents............2 Chair Assembly............. 5 Safety Information ............2 Care and Cleaning............9 Product Caution ..............2 Safety Warnings ..............2 Warranty ................ 2 What is Covered ..............2 What is Not Covered ..............
  • Page 23: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
  • Page 24: Chair Package Contents

    Pre-Assembly (continued) CHAIR PACKAGE CONTENTS Part Description Quantity Back Assembly Left Leg Right Leg Support Seat post Back Cushion Seat Cushion...
  • Page 25: Chair Assembly

    Chair Assembly Connecting the chair support to the chair leg Fasten the support (D) to the legs (B and C) by using M6x35 bolts (AA) and d6.5xD13x1.0 washers (CC). NOTE: 1 ) Loosely tighten all of the bolts using the hex wrench (HH). 2 ) The labels marked “L”...
  • Page 26 Chair Assembly (continued) Connecting the chair seat post to the chair leg Fasten the seat post (E) to the legs (B and C) by using M8x40 bolts (BB) and d8.5xD17x1.6 washers (DD). NOTE: 1 ) Loosely tighten all of the bolts using the hex wrench (HH). 2 ) The arrow mark on the seat post ( E ) must coincide with step2 to ensure proper assembly.
  • Page 27 Chair Assembly (continued) Placing the chair back assembly onto the chair seat post Position the back assembly (A) onto the seat post (E) . HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
  • Page 28 Chair Assembly (continued) Connecting the chair back assembly to the chair seat post Fasten the back assembly (A) to the seat post (D) by using M8x40 bolts (BB), d8.5xD17x1.6 washers (DD), 50x24x4 washer (EE), 50x50x4 washer (FF) and M8x1.25 jam nuts (GG). NOTE: Loosely tighten all of the bolts using hex wrenches (HH and II).
  • Page 29: Care And Cleaning

    Chair Assembly (continued) Tightening the bolts Place cushions (F and G) onto the chair. Once all of the bolts are in place, fully tighten the bolts. Ensure all connections are secure before use. Care and Cleaning For best results, clean the set with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate.
  • Page 30 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service. 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
