8x8 4K HDR HDBaseT Matrix with 4 Mirrored HDMI
Outputs and Audio Breakout
MXV-0808-H2A-70
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC for the HDMI outputs, WyreStorm cannot
guarantee compatibility with all forms of CEC communication.
Basic Wiring Diagram
LAN Cat6a/7
Wireless Router
AC Mains
Power
Blu-ray Player
HDMI from source
Satellite Box
Copyright © 2019 WyreStorm Technologies |
MXV-0808-H2A-70 Quickstart Guide | 190625
section for important wiring
Control System
CAB-IR-LINK (Sold Separately)
IR
Matrix Control Only
HDMI from source
IR TX
wyrestorm.com
In the Box
1x MXV-0808-H2A-70 Matrix
1x AC Power Cord with EU pins
1x AC Power Cord with US pins
1x AC Power Cord with UK pins
1x AC Power Cord with AU pins
1x IR Remote (CR2025 Battery not Included)
8x IR Emitters
8x IR Receivers
2x Matrix Mounting Brackets with screws
1x Quickstart Guide (this document)
HDMI to display
IR RX
IR TX
RXV-70-4K-G2 (Receiver)
Cat6a/7
Cat6a/7
Mirrored HDMI
to display
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
IR RX
IR TX
RXV-70-4K-G2 (Receiver)
Receivers
powered by
Amplifier
MXV-0808-H2A-70 (Matrix)
KEY
HDMI
HDBaseT / Ethernet
Control
Power
Digital Audio
support@wyrestorm.com
HDMI to display
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wyrestorm MXV-0808-H2A-70
Summary of Contents for Wyrestorm MXV-0808-H2A-70
- Page 1 8x8 4K HDR HDBaseT Matrix with 4 Mirrored HDMI Outputs and Audio Breakout Quickstart Guide MXV-0808-H2A-70 WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation Requirements 1x MXV-0808-H2A-70 Matrix •...
- Page 2 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 3 • Verify that all HDMI and HDBaseT connections are not loose and are Troubleshooting Tips: functioning properly • WyreStorm recommends using a cable tester or connecting the cable to • Verify that the HDBaseT cable is properly terminated following EIA568B other devices to verify functionality.
- Page 4 Safety and Emission CE | FCC | RoHS | RCM Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a period of five (5) years from the date of purchase.
