Dimensions - Honeywell ComfortPoint Open Installation And Commissioning Instructions

TM
ComfortPoint Open System

Dimensions

Honeywell
TM
ComfortPoint Open
1 2 3 4 5 6 7 8 9 10 11 12
Install. Instr.
DI
MU1B-0463GE51
216
Binary Inputs Analog Inputs
B7 B8 B9 B10 B11 B12 AI5 AI6 AI7 AI8
7 8 9 10 11 12 17 18 19 20
3 5 6 13 15 16
1 2 4 14
B1 B2 B3 B4 B5 B6 AI1 AI2 AI3 AI4
Fig. 17. CPO-IO830A Mixed Panel Bus I/O Modules, dimensions (in mm)
GND Analog Outputs 24V Relays
AO5 AO6 AO7 AO8 IN1 IN2 IN3 IN4 IN5
25 26 27 28 35 36 37 38
23 29 30 31 32
G1 G2 21 22 24
41 42 AO1 AO2 AO3 AO4 NO1 NO2 NO3 NO4 NO5 NO6
1 2 3 4 5 6
13
IN6
39 40
33 34
!
DO
54.4
44
61.1
EN1B-0498GE51 R0512
