MAINTENANCE AND CARE

NOTE: Always turn off the vacuum and
remove the battery before performing
any service.

Emptying the Dust Cup

1. Press the wand release button and
remove the wand from the main body.
2. Hold the dust cup over a trash container.
3. Push the dust cup release button to
release the bottom of the dust cup
(Fig. 1). The base will drop down and
the debris will fall into the trash
container.
4. Shake the dust cup to release any debris
that might be inside the dust cup.
5. When the dust cup is empty of debris,
firmly push the base onto the dust cup
until it clicks and is fully latched (Fig. 2).
Removing and Replacing the
Dust Cup (for Cleaning)
1. Turn the dust cup counter-clockwise
to line-up the arrows and remove from
the main body (Fig. 3).
2. Turn the internal cylinder clockwise to
remove from the main body (Fig. 4).
3. Rinse the dust cup and internal cylinder
with warm water and allow to dry
thoroughly before re-attaching to
the main body.
4. Replace the internal cylinder and dust
cup onto the main body.
10
Fig. 1
Fig. 2
Fig. 3
Fig. 4
