Summary of Contents for Tacony Riccar RPT-P1
- Page 1 Central Vacuum Power Nozzle Accessory Kits O w n e r ’ s M a n u a l FOR ALL MODELS...
-
Page 3: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS Polarization Instructions Description of the Power Nozzle Accessory Kit Operating the Power Nozzle & Accessories Inserting the hose Turning on the power nozzle Using the power nozzle Remove / Insert the wand from the power nozzle Adjusting the wand Carpet height adjustment Using the accessories... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE WARNING: The manufacturer cannot accept responsibility for damage caused when the appliance is not used according to the instructions, or for uses other than those for which it was intended. -
Page 5: Polarization Instructions
Polarization Instructions POWER CORD, 2-WIRE POLARIZED CORD Riccar power nozzle accessory kit models: RPT-P1 & RPT-P2 To reduce the risk of electric shock this product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. -
Page 6: Description Of The Power Nozzle Accessory Kit
Description of the Power Nozzle Accessory Kit Power Control (for power unit and power nozzle) Flexible hose Handle release button Crushproof hose Wand extension button 3-in-1 Telescopic wand Multi-purpose tool Power cord (select models) Carpet height adjustment Wand release collar Handle release Warning light/dirt sensor Power nozzle... -
Page 7: Operating The Power Nozzle & Accessories
Operating The Power Nozzle & Accessories 1. Inserting the hose 4. Remove / Insert the wand from the To begin cleaning, locate a vacuum power nozzle port and lift the port lid. Insert the hose Removing the wand from the power into the port. -
Page 8: Carpet Height Adjustment
Operating The Power Nozzle & Accessories 6. Carpet height adjustment Your power nozzle has six different settings to clean a variety of carpet types and floor surfaces. To adjust the carpet height setting of the power nozzle, press the right pedal located on the back of the power nozzle (see Diagram 6 diagram). - Page 9 Operating The Power Nozzle & Accessories 7. Using the 3-in-1 Multi-Purpose tool 9. Using the hardwood floor brush The 3-in-1 tool is a highly versatile To clean bare flooring surfaces (i.e. cleaning tool that stores on your hardwood, linoleum, tile), use the telescopic wand for easy access while hardwood floor brush by attaching cleaning.
-
Page 10: Maintenance And Care
Maintenance and Care Your power nozzle may need maintenance To remove the brushroll, turn the unit on occasion to keep it operating in over and lift off the metal bottom plate peak condition. Listed below are a few by first unscrewing the two bottom plate maintenance procedures that can be screws located by the rear wheels (see performed by you or your retailer. -
Page 11: Replacing The Power Nozzle Belt
Maintenance and Care 2. Replacing the power nozzle belt 3. Replacing the bulb IMPORTANT: Before performing any IMPORTANT: Before performing any maintenance work on the power nozzle, maintenance work on the power nozzle, always disconnect the hose from the always disconnect the hose from the vacuum inlet and unplug the power cord, vacuum inlet and unplug the power cord, if your model has one. -
Page 12: Problem Solving Guide
Problem Solving Guide 1. Power nozzle warning light d. When the unit is turned back on, Your power nozzle comes equipped the warning light should be green with a circuit breaker safety system and ready to go. If the breaker trips that protects it from a jammed power again, repeat steps a-c to correct the nozzle situation. - Page 13 Problem Solving Guide 3. Dirt sensor (select models only) Some power nozzle accessory kits have nozzles featuring a built-in dirt sensor. The sensor detects whether or not the flooring surface you are vacuuming is clean. The sensor light is located on top of the nozzle and is part of the warning light system. Listed below are the potential warning / cleaning lights along with a description of that condition: Light:...
-
Page 14: Warranty
Warranty What is Covered: This warranty covers any defects in material and workmanship in your new Riccar central vacuum power nozzle accessory kit. How Long Coverage Lasts: Warranty coverage for your Riccar central vacuum power nozzle accessory kit lasts 3 years. This warranty is limited to your power nozzle, central vacuum hose and accessories included in the particular kit you purchased. - Page 16 ©2012 Tacony Corporation B503-2400B...
