The means of the fields for "SNMP Agent" are:
In the field "IP ADDRESS" the IP address of SNMP side of the converter is defined;
In the field "SUBNET Mask" the SubNet Mask of SNMP side of the converter is defined;
In the field "GATEWAY" the default gateway of the network is defined. This feature can be enabled or disabled pressing the Check
Box field. This feature is used for going out of the net;
In the field "SNMP Name of
In the field "Contact" the contact for SNMP Agent station is defined;
In the field "Location" the location for SNMP Agent station is defined;
In the field "Version" the version of SNMP protocol is defined. If version 3 is selected, the fields below appears:
"User": the user for the SNMP access is defined;
o
"Security Level": the type of security used is defined;
o
"Authority": if Authority level is enabled, in this field the password is defined;
o
"Authority Mode": if Authority level is enabled, in this field the type of encryption during the authorization phase is define;
o
"Privacy": if Privacy level is enabled, in this field the key is defined;
o
"Privacy Mode": if Privacy level is enabled, in this field the type of encryption during the communication is defined.
o
ADFweb.com Srl – IT31010 – Mareno – Treviso
Station" the name for SNMP Agent station is defined;
