Page 5 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.
Page 6: Table Of Contents
Contents Introduction ........2 In brief ..........4 Keys, doors and windows .... 19 Seats, restraints ......33 Storage ........48 Instruments and controls ..... 57 Lighting ........78 Climate control ......83 Driving and operating ....92 Vehicle care ....... 117 Service and maintenance ..
Page 7: Introduction
Introduction Introduction...
Page 8 Introduction Introduction ■ Depending on the model variant, Caution integrated special equipment and Your vehicle is a designed accessories, the scope of Text marked Caution provides combination of advanced technology, equipment of your vehicle can differ information on possible damage to safety, environmental friendliness from the descriptions in this and economy.
Page 9: In Brief
In brief In brief Vehicle unlocking Electronic key Radio remote control Initial drive information When in possession of the electronic key, press switch on door handle to unlock the vehicle and pull the door Press button c to unlock the doors handle to open the door.
Page 10 In brief Seat adjustment Seat positioning Seat backrests 9 Warning Only drive with the seat correctly adjusted. Pull handle, slide seat, release Pull lever, adjust inclination and handle. release lever. Allow the seat to engage audibly. Do not lean on Seat adjustment 3 35, Seat position backrest when adjusting.
Page 11 In brief Seat height Head restraint adjustment For horizontal adjustment, pull the head restraint forward, it engages in Lever pumping motion For height adjustment, pull the head 3 positions. To bring into rear position restraint upward. To move down higher automatically, pull head restraint press the catch and push the head close forward.
Page 12 In brief Seat belt Mirror adjustment Exterior mirrors Interior mirror Select the relevant exterior mirror and Pull out the seat belt and engage in adjust. belt buckle. The seat belt must not be Adjust the lever on the underside to Electric adjustment 3 29, Convex twisted and must fit close against the reduce glare.
Page 13 In brief Steering wheel adjustment Unlock lever, adjust steering wheel, then engage lever and ensure it is fully locked. Do not adjust steering wheel unless vehicle is stationary and steering wheel lock has been released. Airbag system 3 40, Ignition positions 3 93.
Page 14 In brief Instrument panel overview...
Page 15 In brief Light switch ......78 13 Front passenger airbag ..41 30 Anti-theft alarm system status LED ......27 14 Glovebox ......49 Front fog lights ..... 80 15 Climate control system ..83 Instrument illumination ..81 16 Traction control system ..103 Side air vents ......
Page 16 In brief Exterior lighting Press Headlight flash, high beam and low beam > = front fog lights (If fitted) Lighting 3 78. Turn headlight pull lever AUTO = Automatic light control: flash Headlights are switched high beam push lever on and off automatically low beam pull lever from high depending on external...
Page 17 In brief Turn and lane-change signals Hazard warning flashers Horn left lever up Operated with the ¨ button. Press j. right = lever down Hazard warning flashers 3 79. Turn and lane change signals 3 80.
Page 18 In brief Washer and wiper systems Windscreen washer system Rear window wiper and washer systems Windscreen wipers Pull lever. Press the rocker switch to activate the Windscreen washer system 3 58, fast rear window wiper: Washer fluid 3 127. slow upper position intermittent timed interval wiping...
Page 19 In brief Climate control Electronic climate control system (if fitted) Heated rear window, heated exterior mirrors Air conditioning system (if fitted) Push lever. Washer fluid is sprayed on the rear window and the wiper wipes a few Heating is operated by pressing the times.
Page 20 In brief Demisting and defrosting the Transmission Automatic transmission windows Manual transmission park reverse Press button V. neutral Reverse: when the vehicle is Set temperature control to warmest drive stationary, depress the clutch pedal level. and then pull up the ring on the shift Sport mode: move shift lever from D Cooling n on.
Page 21 In brief The shift lever can only be moved out Starting off Starting the engine of P when the ignition is on and the brake pedal is applied. To engage P Check before starting off or R, push the release button. ■...
Page 22 In brief Before restarting or to switch off the Starting engine with the To switch off the engine, press the engine, turn key back to 0. button again whilst the engine is Start/Stop button running. Starting the engine 3 93. ■...
Page 23 In brief Parking If the vehicle is on a downhill slope, engage reverse gear or set the shift ■ Always apply parking brake without lever to P before switching off the pressing release button. Apply as ignition. Turn the front wheels firmly as possible on a downhill towards the kerb.
Page 24: Keys, Doors And Windows
Keys, doors and windows Keys, doors and Keys, locks Radio remote control windows Keys Replacement keys The key number is specified on a Keys, locks ........19 detachable tag. Doors ........... 25 Locks 3 157. Vehicle security ......27 Exterior mirrors ......29 Key with foldaway key section Interior mirrors ......
Page 25 Keys, doors and windows Fault If the central locking system cannot be operated with the radio remote control, it may be due to the following: ■ Range exceeded, ■ Battery voltage too low, ■ Frequent, repeated operation of the remote control while not in range, which will require resynchronisation, ■...
Page 26 Keys, doors and windows Radio remote control Batteries do not belong in household ■ Battery voltage too low, waste. They must be disposed of at ■ Interference from higher-power an appropriate recycling collection radio waves from other sources. point. Try repositioning the electronic key or Radio remote control battery follow the electronic key manual replacement 3 19.
Page 27 Keys, doors and windows Unlocking Electronic key system Locking Remote control Remote control Close doors, boot and fuel filler flap. Press switch on a door handle to unlock the vehicle and pull the door handle to open the door, or press the Press button c.
Page 28 Keys, doors and windows Electronic key system Unlocking the boot lid 4 Door sedan 5 Door hatchback, Sportwagon Press the switch on a door handle. Press button x. The boot lid will unlock and open, whilst all other The electronic key must be outside Press button c once or twice, doors remain locked.
Page 29 Keys, doors and windows Fault in remote control system switch off the ignition, close the driver's door and lock it from the or electronic key system outside with the key. Unlocking Fault in central locking system Unlocking Manually unlock the driver's door by turning the key in the door barrel.
Page 30: Doors
Keys, doors and windows Doors Automatic locking 9 Warning Automatic locking after driving Load compartment Use the child locks whenever children are occupying the rear Opening This security feature can be seats. configured to automatically lock all 5 Door hatchback, Sportwagon doors, boot and fuel filler flap as soon Using a key or suitable screwdriver, as the vehicle starts to drive.
Page 31 Keys, doors and windows 4 Door sedan Note The installation of certain heavy accessories onto the boot lid may affect its ability to remain open. Closing 5 Door hatchback 9 Danger Push the button under the boot lid moulding or press button x on the Do not drive with the boot lid open remote control until boot lid is opened.
Page 32: Vehicle Security
Keys, doors and windows Vehicle security ■ Self-activated 30 seconds after Status LED locking the vehicle (initialisation of the system), or Anti-theft alarm system ■ Remote control: directly by Anti theft alarm system monitors: pressing e once more after locking, ■...
Page 33 (only electronic key assistance of your Holden Dealer. system) or switching on the ignition. Note Immobiliser The immobiliser does not lock the Unlocking the vehicle by pressing doors.
Page 34: Exterior Mirrors
Keys, doors and windows Exterior mirrors Then swivel the control to adjust the Heated mirrors mirror. Convex shape Air conditioning system (if fitted) Folding mirrors The convex exterior mirror reduces blind spots. The shape of the mirror makes objects appear smaller, which will affect the abilty to estimate distances.
Page 35: Interior Mirrors
Keys, doors and windows Interior mirrors Windows Electronic climate control system (if fitted) Manual anti-dazzle Power windows 9 Warning Take care when operating the power windows. Risk of injury, particularly to children. If there are children on the rear seat, switch on the child safety system for the power windows.
Page 36 Keys, doors and windows Operation of passenger's Child safety system for rear window and rear windows windows Pushing or pulling lightly to the first detent: window moves down or up as long as switch is operated. Pushing further to the second detent and then releasing: window moves down automatically.
Page 37 Keys, doors and windows warning message or a warning code Heated rear window Electronic climate control is displayed in the Driver Information system (if fitted) Centre. Air conditioning system (if fitted) Vehicle messages 3 72. Activate the window electronics as follows: 1.
Page 38: Seats, Restraints
Seats, restraints Seats, restraints Head restraints Head restraints on front seats Height adjustment Position Head restraints ......33 9 Warning Front seats ........34 Rear seats ........37 Only drive with the head restraint Seat belts ........37 set to the proper position. Airbag system ......
Page 39: Front Seats
Seats, restraints Front seats Head restraints on rear seats Height adjustment Seat position 9 Warning Only drive with the seat correctly adjusted. Horizontal adjustment To adjust horizontally, pull the head restraint forwards and engage in one of three positions. Pull the head restraint upwards. To return to its rearmost position, pull To move down press the catch and fully forwards and release.
Page 40 Seats, restraints applying the pedals. Slide the Seat adjustment Pull handle, slide seat, release passenger seat as far back as handle. possible. 9 Danger Seat backrests ■ Sit with your shoulders as far back against the backrest as possible. Do not sit nearer than 25 cm from Set the backrest rake so that you the steering wheel, to permit safe can easily reach the steering wheel...
Page 41 Seats, restraints Seat height Horizontal adjustment Activate front seat heating (while the engine is running) by pressing the ß Push button to slide the armrest. Lever pumping motion button in the control knob for higher temperature (left seat) or fan speed Heating down = lower...
Page 42: Rear Seats
Seats, restraints Rear seats Seat belts 9 Danger Armrest Seat belt reminder for driver's seat Fasten seat belt before each trip. and front passenger seat, seat belt In the event of an accident, people control indicator X 3 66. not wearing seat belts endanger their fellow occupants and themselves.
Page 43 Cleaning replaced. After an accident, have the may safely be carried out using belts and triggered belt tensioners mild soap and water. The belt replaced by your Holden Dealer. should be replaced if webbing becomes frayed, contaminated or Note damaged.
Page 44 Seats, restraints Triggered belt tensioners must be Withdraw belt from reel, guide it 9 Warning replaced by your Holden Dealer. Belt untwisted across the body and tensioners can only be triggered engage the latch plate in the buckle. The belt must not rest against hard once.
Page 45: Airbag System
Do not stick anything on the airbag covers and do not cover them with other materials. Each airbag is triggered only once. Have deployed airbags replaced by a Holden Dealer.
Page 46 Only then the airbag is instrument panel, all panelling parts, able to protect. the door seals, the handles and the seats replaced by your Holden Dealer. Control indicator v for airbag systems 3 66. Front airbag system...
Page 47 Seats, restraints Side airbag system Depending on the body style, a The risk of injury to the upper body different airbag label may be located and pelvis in the event of a side-on The side airbag system consists of an on the passenger's sunvisor.
Page 48: Child Restraints
Seats, restraints Child restraints Curtain airbag system Child restraint systems When a child restraint system is being used, pay attention to the following usage and installation instructions and also those supplied with the child restraint system. The risk of injury to the head in the event of a side impact is considerably The curtain airbag system consists of reduced.
Page 49 Depending on the body style, a approved child restraints. Holden equipment to the vehicle. different airbag label may be located strongly recommends that you Only child restraints that have clips on the passenger's sunvisor.
Page 50 Seats, restraints Ensure that the child restraint system the child wears it. Please see the Always follow the child restraint to be installed is compatible with the instructions on the relevant products manufacturer’s fitting instructions vehicle type. for child restraints. when installing a child restraint Ensure that the mounting location of into the vehicle.
Page 51 Seats, restraints Child restraint installation locations Permissible options for fitting a child restraint system Weight and age class On front passenger seat On rear outboard seats On rear centre seat Group 0: up to 10 kg or approx. 10 months Group 0+: up to 13 kg or approx.
Page 52 Seats, restraints Isofix child restraint In addition to the ISOFIX mounting, fasten the top-tether straps to the top- systems tether anchorage points. Top-tether child restraint systems 3 47. Top-tether child restraint systems The strap must run between the two guide rods of the head restraint. When using Top-tether for seat Fasten vehicle-approved ISOFIX mounting, universally approved child...
Page 53: Storage
Storage Storage Storage compartments Instrument panel storage Storage on top of the instrument 9 Warning panel Storage compartments ....48 Do not not store heavy or sharp Load compartment ....... 50 objects in the storage Roof rack system ......55 compartments.
Page 54 Storage Storage below the light switch Glovebox Cupholders Pull the grip to open the box. To open pull the grip. Cupholders are located in the centre console. 9 Warning To reduce the risk of injury in an accident or a sudden stop, always keep the glovebox door closed while driving.
Page 55 Storage Load compartment Additional cupholders are located in Armrest storage the rear armrest, when it is folded down. Storage in the front armrest Folding down rear seat backrests Sunglasses storage The rear backrest is divided into two (If fitted) parts. Both parts can be folded down. Push head restraints down by pressing the catch.
Page 56 Storage Insert all safety belts into the slots, if Rear storage seat belts are not coiled up On Sportwagon a tray is located automatically. behind the rear seats. The centre rear safety belt may lock when you raise the seatback. If this Removing tray happens, let the belt go back all the way and start again.
Page 57 Storage Load compartment cover Opening cover Do not place any objects on the cover. 5 Door hatchback Removing Lift cover at the rear and push it upwards at the front, from Pull the handle at the end of the cover underneath.
Page 58 Storage Cover in upper position Removing cover Rear floor storage cover Rear floor cover, Sportwagon Push the handle at the end of the Open the load compartment cover. cover downwards. The rear of the Pull the end of the cover inwards and cover is guided upwards lift the cover.
Page 59 Storage Lashing eyes Installation Behind the front seats Behind the rear seats Attach strap to eyes underneath the The lashing eyes are designed to rear seat cushion. secure items against slippage, e.g. Attach lower hook with opening facing Fold backrests forward. using lashing straps or luggage net.
Page 60 For safety reasons, and to avoid the roof frame: suspend and engage damaging the roof, use only the rod of net at one side, compress rod roof rack approved by Holden for and suspend and engage at other your vehicle. The maximum side.
Page 61 Storage Loading information ■ When transporting objects in the and secure it properly with retaining load compartment, the backrests of straps. Adjust the tyre pressure and the rear seats must not be angled vehicle speed according to the load forward. conditions.
Page 62: Instruments And Controls
Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Controls ........57 Warning lights, gauges and indi‐ cators ........... 61 Information displays ..... 70 Vehicle messages ......72 Trip computer ....... 74 Vehicle personalisation ....75 The Infotainment system can be operated by the controls on the steering wheel.
Page 63 Instruments and controls Horn Windscreen wiper/washer Adjustable wiper interval Windscreen wiper Wiper lever in position P. Press j. Turn the adjuster wheel to adjust the fast desired wipe interval: slow short turn adjuster wheel timed interval wiping interval downwards § = long turn adjuster wheel interval...
Page 64 Instruments and controls Windscreen washer Rear window wiper/washer Push lever. Washer fluid is sprayed onto the rear window and the wiper Pull lever. Washer fluid is sprayed Press the rocker switch to activate the wipes a few times. onto the windscreen and the wiper rear window wiper: Do not use if the rear window is swipes for a few strokes.
Page 65 Instruments and controls The rear window washer system is Colour-Info-Display deactivated when the fluid level is Set date and time low. To set the time: Outside temperature 1. Press CLOCK, then rotate and press MENU SEL to select SET TIME. 2.
Page 66 Instruments and controls Warning lights, gauges To set the date: 12V power outlets are located in the front and rear floor console. 1. Press CLOCK, then rotate and and indicators press MENU SEL to select SET Do not exceed the maximum power DATE.
Page 67 Instruments and controls Odometer recorded distance reaches 2000, trip Caution odometer automatically shows 0 without resetting. If the needle is in the red warning zone, the maximum permitted Tachometer engine speed is exceeded. Engine is at risk. Fuel gauge The bottom line displays the recorded distance.
Page 68 Instruments and controls Because of the fuel remaining in the an oil change is necessary. CodE 82 Caution tank, the top-up quantity may be less or Change Engine Oil Soon appears than the specified tank capacity. in the Driver Information Centre. Do not continue driving with the Change the oil as soon as possible temperature gauge needle in the...
Page 69 Instruments and controls Display of remaining engine oil life versions. Depending on the equipment, the position of the control indicators may vary. Different displays are used depending on model. When the ignition is switched on, most control indicators will illuminate briefly as a functionality test.
Page 70 Instruments and controls Control indicators in the instrument...
Page 71 Have the cause of the fault starting the engine or reaching a 3 137. remedied immediately by your specific distance or speed, or until the Holden Dealer. Turn signals 3 80. seat belt is fastened. Airbag system, belt tensioners 3 40, Flashes Seat belt reminder 3 37.
Page 72 3 127. Antilock brake system 3 101. Seek the assistance of your Holden Dealer. 9 Warning Power steering Malfunction indicator light Stop.
Page 73 Have the cause of the fault in the system remedied by your Holden ■ If the control indicator remains n illuminates yellow. Dealer. illuminated, turn the steering wheel...
Page 74 % illuminates or flashes yellow. Illuminates for a few seconds after the Check oil level before seeking Caution ignition is switched on. assistance of your Holden Dealer 3 124. The diesel particle filter requires Engine lubrication may be cleaning. interrupted. This may result in...
Page 75 The engine cannot be started. Illuminates when the front fog lights are on 3 80. Have the cause of the fault remedied by your Holden Dealer. Cruise control Apply footbrake m illuminates white or green. 0 Press Brake to Start Engine is Illuminates white displayed on the DIC.
Page 76 Instruments and controls Turn the adjuster wheel to scroll through a menu option or to set a numeric value. Press the SET/CLR button to select a function or to confirm a message. Vehicle personalisation 3 75. Trip computer 3 74. Colour-Info-Display The vehicle has a Colour-Info-Display.
Page 77 27 Right front turn indicator failure If necessary seek the assistance of Selecting menus and settings your Holden Dealer. 28 Right rear turn indicator failure Rotate the MENU SEL button to scroll Vehicle messages on the...
Page 78 Instruments and controls ■ Wiper/washer system ■ If a warning code appears in the Driver Information Centre. ■ Doors, windows ■ If the parking assist detects an ■ Remote control object (If fitted). ■ Seat belts When the vehicle is parked and/ ■...
Page 79 Instruments and controls Trip computer Trip meter To reset, press the SET/CLR button for a few seconds. The menus and functions can be Average consumption selected with the turn signal lever. Display of average consumption. The measurement can be reset at any time.
Page 80 Instruments and controls Vehicle personalisation Instantaneous consumption Display of the instantaneous consumption is displayed while the The vehicle's parameters can be vehicle is moving. personalised by changing the settings in the Driver Information Centre and in the Info-Display. Depending on vehicle equipment some of the functions described below might not be available.
Page 81 Instruments and controls Different displays are used In the corresponding submenus the Different displays are used depending on model. following settings can be changed by depending on model. rotating and pressing the MENU Displayed units cannot be changed. 3 Press the SET/CLR button to select SEL knob: (Metric) is the only setting available.
Page 82 Instruments and controls ■ Display Off: Switches off the rear window wiper when reverse ■ Remote Lock / Unlock / Start display. Press any button to switch gear is engaged. Remote Unlock Feedback: Activate back on. ■ Collision Detection Systems or deactivate flashing the lights ■...
Page 83: Lighting
Lighting Lighting Exterior lighting Parking lights Headlights and parking lights Light switch When switching on ignition, automatic Exterior lighting ......78 light control is always active. Interior lighting ......81 When lights are on, 8 lights up. Lighting features ......82 Control indicator 8 3 70.
Page 84 Lighting Automatic light control function High beam Headlight flash When the automatic light control To activate the headlight flash, pull function is switched on and the lever. engine is running, the system switches the headlights and taillights Hazard warning flashers on and off according to ambient light conditions.
Page 85 Lighting Misted light covers Turn and lane-change Switch the indicator off manually by moving the lever to its original signals The inside of the light housing may position. mist up briefly in poor, wet and cold weather conditions, in heavy rain or Front fog lights after washing.
Page 86 Lighting Interior lighting Turn knob k and hold until the desired Operate rocker switch: brightness is obtained. automatic switching on Instrument panel and off Interior lights press u = always on illumination control press v = always off Courtesy light Reading lights Brightness of the following lights can be adjusted when the exterior lights...
Page 87 Lighting Lighting features Exit lighting Headlights and tail lights illuminate Entry lighting the way for an adjustable time after leaving the vehicle. Welcome lighting Activation, deactivation and duration Headlights, tail lights and interior of lighting of this function can be lights illuminate for a short time when changed in the menu Vehicle unlocking the vehicle with the remote...
Page 88: Climate Control
Climate control Climate control Climate control systems 9 Danger Air conditioning system Do not sleep in a vehicle with the air conditioning or heating system (If fitted) Climate control systems ....83 on. It may cause serious harm or Air vents ........89 death due to a drop in the oxygen level and/or body temperature.
Page 89 Climate control Heating will not be fully effective until Air conditioning n The exchange of fresh air is the engine has reached its operating Operated with the n button and is reduced in air recirculation mode. temperature. functional only when the engine and In operation without cooling the air fan are running.
Page 90 Climate control Maximum cooling Indication of settings Adjust the air flow by switching the fan (Info-Display) to the desired speed. ■ Push button V: the air distribution is directed automatically to the windscreen. Each change of settings is indicated ■ Set temperature control to warmest Briefly open the windows so that hot in the Info-Display for a few seconds.
Page 91 Climate control Controls for automatic mode: The preselected temperature is 9 Danger automatically regulated. In the AUTO automatic mode, all automatic mode the fan speed and air settings except Do not sleep in a vehicle with the distribution automatically regulate the temperature are air conditioning or heating system air flow.
Page 92 Climate control Automatic mode AUTO Air distribution is selected If the maximum temperature is set, automatically in automatic mode. The the climate control system runs at air vents should therefore always be maximum heating. open. Demisting and defrosting the Temperature preselection windows V ■...
Page 93 Climate control Fan speed x Air distribution MODE Return to automatic air distribution: Deactive corresponding setting or press button AUTO. Cooling n Activate or deactivate with the n button. The air conditioning system cools and dehumidifies (dries) the interior of the vehicle.
Page 94 Climate control Air vents 9 Warning Adjustable air vents The exchange of fresh air is reduced in air recirculation mode. At least one air vent must be open In operation without cooling the air while cooling is on in order to prevent humidity increases, so the the evaporator from icing up due to windows may mist up.
Page 95 Remove any leaves, Service dirt or snow. For optimal cooling performance, it is recommended to have the climate control system checked annually by your Holden Dealer. ■ Functionality and pressure test ■ Heating functionality ■ Leakage check...
Page 96 Climate control ■ Check of drive belts ■ Cleaning of condenser and evaporator drainage ■ Performance check...
Page 97: Driving And Operating
Driving and operating Driving and operating Driving hints Starting and operating Control of the vehicle New vehicle running-in Use the following precautions for the Driving hints ......... 92 Never coast with engine not first few hundred kilometres to Starting and operating ....92 running improve the performance and Engine exhaust ......
Page 98 Driving and operating Starting the engine Diesel particle filter 3 95. ■ Diesel engine: turn the key to position 2 for preheating until control indicator ! goes out Ignition switch positions Starting engine with the ignition switch ■ Turn the key to position 3 and release when engine is running Before restarting or to switch off the engine, turn key back to 0.
Page 99 Driving and operating ■ Automatic transmission: depress yellow LED in the button illuminates. Electronic key manual override brake and move shift lever to P or N In this mode steering wheel lock is If either the battery of the electronic released and some electrical key is weak or the radio remote ■...
Page 100 ■ Do not park the vehicle on an easily console. Place the electronic key over ignitable surface. The high the cover with the Holden Logo facing 9 Danger temperature of the exhaust system could ignite the surface.
Page 101 3 109, If g illuminates additionally, 3 169 could damage the catalytic cleaning is not possible, seek the converter or electronic assistance of your Holden Dealer. components. Under certain driving conditions, e.g. Unburnt petrol will overheat and Caution short distances, the system cannot damage the catalytic converter.
Page 102: Automatic Transmission
The automatic transmission permits problems, have the cause of the fault manual gearshifting (manual mode) rectified by your Holden Dealer as or automatic gearshifting (automatic soon as possible. In an emergency, mode). driving can be continued for a short...
Page 103 Driving and operating To start the engine, press the brake Sport mode To activate sport mode: pedal in either P or N position. 1. Move shift lever to position D. (If fitted) Do not accelerate while engaging a 2. Push the shift lever to the left. gear.
Page 104 Driving and operating Manual mode No automatic shifting to a higher gear Kickdown takes place at high engine revolutions. For reasons of safety, kickdown is also available in manual mode. Electronic driving programmes ■ Following a cold start, the operating temperature programme increases engine speed to quickly bring the catalytic converter to the required...
Page 105 P. If P is engaged again, the shift lever Have the cause of the fault remedied will be locked in position again. by your Holden Dealer. Have the cause of the power supply interruption remedied by Interruption of power your Holden Dealer.
Page 106: Manual Transmission
Considerably more force is needed for this. The braking distance is extended. Seek the assistance of your Holden Dealer before continuing your journey. When the engine is not running, the support of the brake servo unit...
Page 107 Control indicator & 3 67. Have the cause of the fault ABS control is made apparent remedied by your Holden Dealer. through a pulse in the brake pedal Brake assist and the noise of the regulation...
Page 108: Ride Control Systems
Driving and operating Ride control systems TC is reactivated by pressing the a 9 Warning button again. Traction Control system TC is also reactivated the next time Do not let this special safety the ignition is switched on. feature tempt you into taking risks Traction control system (TC) when driving.
Page 109: Cruise Control
Driving and operating Cruise control Control indicator n illuminates and 9 Warning both ESC and TC are deactivated. ESC is reactivated by pressing the a The cruise control can store and Do not let this special safety button again. If the TC System was maintain speeds.
Page 110 Driving and operating Switching on Reduce speed Switching off Press rocker switch m at the upper With cruise control active, hold thumb Press rocker switch m at the lower end, control indicator m illuminates wheel turned to SET/- or briefly turn to end, control indicator m is off.
Page 111: Object Detection Systems
Driving and operating Object detection Additionally if the system does not Control indicator r 3 68. work due to temporary conditions like systems Note snow covered sensors, r Attached parts in the detection area illuminates. cause system malfunction. Parking assist Important hints for using the Activation (If fitted)
Page 112 Driving and operating Functionality Special conditions apply if there 9 Warning are taller vehicles involved (e.g. off-road vehicles, mini vans, The rear view camera does not vans). Object identification in the replace driver vision. Note that upper part of these vehicles objects that are outside the cannot be guaranteed.
Page 113 Driving and operating 5 Door hatchback: The camera is Warning symbols Fault mounted in the rear bumper above Warning symbols are indicated as The rear view camera may not the license plate. triangles 9 on the picture which show operate properly when: obstacles detected by the rear ■...
Page 114: Fuel
Driving and operating Fuel Equivalent standardised fuels with an acid methyl ester ("FAME"), also ethanol content of max. 10% by known as "B5", is also permitted volume may be used. provided that the FAME meets the Fuel for petrol engines Euro standard EN 14214 and the Use clean, unleaded petrol of regular 9 Warning...
Page 115 New Vehicle Before refuelling, switch off engine Warranty. In no event will GM and mobile phones. Holden be responsible or bear any Follow the operating and safety liabilty for any damage or loss that instructions of the filling station may arise in connection with the when refuelling.
Page 116: Trailer Hitch
Your The fuel filler cap can be retained in Holden Dealer will help supply and the bracket on the fuel filler flap. install towing equipment to suit your When refuelling, fully insert the pump requirements.
Page 117 Never exceed the loads given for the towing equipment fitted to the vehicle. For your safety and the vehicle’s durability, all mandatory equipment must be fitted. Otherwise you may void the New Vehicle Warranty, to the extent that Holden considers the overloading or missing equipment to have affected the specifications or quality of the vehicle.
Page 118 Holden towing equipment is recommended where it is available. Where it is not available, no recommendation is made as to the make of equipment to be used. Holden will not accept liability for defects occurring in inappropriate towing equipment or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment.
Page 119 Driving and operating If the tow ball load is too light or too heavy, the steering and handling of the vehicle may be affected. As a general guideline, for single axle trailers, the ball load should be approximately 10 % of the loaded trailer mass. For heavy trailers with more than one axle, the ball load should be in the range of 5 % - 10 % of the loaded trailer mass.
Page 120 Driving and operating Note At no time may the maximum towing capacity exceed the maximums specified. Refer to Maximum towing capacity previously in this chapter. At no time may the total rear axle load exceed the maximums specified. Refer to Loading the vehicle previously in this chapter.
Page 121 Remember that bull bars may affect airbag operation. Running in before towing Holden recommends that you drive your new vehicle for at least 1,500 km before towing. If you must tow in the first 1,500 km of the vehicle’s life, do not exceed 80 km/h.
Page 122: Vehicle Care
Vehicle care Vehicle care General Information ■ Check coolant anti-freeze and corrosion protection. Accessories and vehicle ■ Adjust tyre pressure to the value specified for full load. modifications General Information ....117 ■ Park vehicle in dry, well ventilated We recommend to use Genuine Parts Vehicle checks ......
Page 123: Vehicle Checks
Vehicle care Vehicle checks ■ Check the coolant level. 9 Danger ■ Fit the number plate if necessary. Performing work The ignition system uses extremely high voltage. Do not touch. Bonnet Opening 9 Warning Only perform engine compartment checks when the ignition is off. The cooling fan may start operating even if the ignition is off.
Page 124 Vehicle care Closing Before closing the bonnet, press the support into the holder. Lower the bonnet and allow it to drop into the catch. Check that the bonnet is engaged. Push the safety catch to the right and open the bonnet. Secure the bonnet support.
Page 125 Vehicle care Engine compartment overview 1.4L Petrol engine...
Page 126 Vehicle care 1.6L Petrol engine...
Page 127 Vehicle care 1.8L Petrol engine...
Page 128 Vehicle care 2.0L Diesel engine...
Page 129 Vehicle care 1. Power steering fluid container Different dipsticks are used 3 126 depending on engine variant. 2. Brake fluid container 3 127 1.4L Petrol: 3. Engine oil cap 3 124 4. Engine coolant container 3 126 5. Fuse box 3 138 6.
Page 130 Vehicle care When the engine oil level has Caution dropped to the MIN mark, top up engine oil. When driving at a slope, the warning code 79 might be displayed in the Driver Information Centre 3 72. If the code disappears when driving in a flat area again, do not top up engine oil.
Page 131 Vehicle care Engine coolant concentration checked and have the cause of the coolant loss remedied by The coolant provides freeze your Holden Dealer. protection down to approx. -28 °C. Power steering fluid 9 Warning Caution Do not spill coolant on the vehicle's exterior surfaces.
Page 132 Avoid contact with eyes, The vehicle is equipped with a lead skin, fabrics and painted surfaces. If the fluid level is too low, seek the acid battery. The battery is assistance of your Holden Dealer. maintenance-free. Washer fluid Caution A specifically developed battery with a ventilation system is required for this vehicle.
Page 133: Bulb Replacement
5 seconds. Use only the same bulb type for If the engine fails to start, seek the replacement. assistance of your Holden Dealer. Replace headlight bulbs from within the engine compartment. Wiper blade replacement Halogen headlights Lift wiper arm.
Page 134 Vehicle care 4. Remove bulb from reflector housing. 5. When fitting a new bulb, engage the lugs in the recesses on the reflector. 6. Engage the spring clip. 7. Place headlamp protective cover in position. 8. Plug connector onto bulb. Parking lights 2.
Page 135 2. Push bulb into socket slightly, rotate anti-clockwise, remove and renew bulb. 3. Insert bulb holder in reflector, 1. Open both covers. rotate clockwise to engage. Fog lights 1. Rotate bulb holder anti-clockwise and disengage. Have bulbs replaced by your Holden Dealer.
Page 136 Vehicle care 5. Rotate bulb holder anti-clockwise. 2. Unscrew both screws. 4. Reverse light (1) Turn signal light (2) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (3) clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and rotate clockwise into place.
Page 137 Vehicle care Tail lights in boot lid 3. Remove bulb holder. Push bulb into socket slightly, rotate anti- clockwise, remove and renew bulb. 4. Insert bulb holder into boot. Refit the inner panelling to boot lid. 5. Switch on ignition, operate and check the lights.
Page 138 Vehicle care Sportwagon 4. Turn signal light (1) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (2) 1. Open both covers. clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and screw into place.
Page 139 Vehicle care 4. Turn signal light (1) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (2) clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and screw into place. Install tail light assembly in body and tighten screws.
Page 140 4. Insert bulb holder in bulb housing clockwise. Attach cover. and rotate clockwise. 4. Switch on ignition, operate and 5. Insert bulb housing and secure using a screwdriver. check the lights. Side turn signal lights Have bulbs replaced by your Holden Dealer.
Page 141 5. Insert bulb holder in bulb housing 2. Remove bulb housing downward, and rotate clockwise. taking care not to pull on the 6. Insert and engage bulb housing. cable. Interior lights Courtesy light, reading lights Have bulbs replaced by your Holden Dealer.
Page 142: Electrical System
There are two fuse boxes in the illumination vehicle: ■ in the front left of the engine Have bulbs replaced by your Holden compartment, Dealer. ■ in the interior behind the glove box. In a box above the positive terminal of the battery are some main fuses.
Page 143 Vehicle care Engine compartment fuse Place the fuse extractor on the various types of fuse from the top or side, and withdraw fuse. The fuse box is in the front left of the engine compartment. Disengage the cover, lift it upwards and remove.
Page 144 Vehicle care No. Circuit No. Circuit Transmission control module 18 Fuel system control module Engine control module 19 – – 20 Fuel pump Canister vent sol 21 Rear power windows Ignition 22 – Front wipers 23 – – 24 Front power windows Fuel injection 25 Electronic vacuum pump Fuel injection, ignition system...
Page 145 Vehicle care No. Circuit No. Circuit No. Circuit 35 Infotainment system, Amplifier 52 Instrument panel 69 Battery voltage sensor 36 – 53 Electrochromatic mirror 70 Rain sensor 37 High beam, right side 54 Light switch, Light control 71 – 38 High beam, left side 55 Mirror folding Instrument panel fuse box 39 –...
Page 146 Vehicle care No. Circuit No. Circuit Body control module 25 Steering column lock Body control module 26 Rear power outlet 10 Body control module 11 Interior fan 12 – 13 Heated seats 14 Diagnostic connector No. Circuit 15 Airbag 16 Central locking system Infotainment system, handsfree phone 17 Air conditioning system...
Page 147: Vehicle Tools
Vehicle care Vehicle tools Vehicles with spare wheel Tools Vehicles with tyre repair kit A LONG wheel tub stud may also be stored with the vehicle tools. The jack and the tools are in a stowage compartment in the boot below the spare wheel.
Page 148: Wheels And Tyres
Regularly check the wheels and tyres Check tread depth at regular for damage. Seek the assistance intervals. from your Holden Dealer in the event of damage or unusual tyre wear. Refer to the tyre pressure placard on Tyres should be replaced for safety reasons when the front right door frame.
Page 149 Vehicle care location of the damage. If in doubt If there is more wear at the front than Tyre chains about the extent of the damage to the rear, swap round front wheels and the tyre, have it removed from the rear wheels.
Page 150 Vehicle care Tyre repair kit (If fitted) Minor damage to the tyre tread or sidewall can be repaired with the tyre repair kit. Do not remove foreign bodies from the tyres. Tyre damage exceeding 4 mm or that is at tyre's side wall near the rim The tyre repair kit is in a compartment 3.
Page 151 Vehicle care 4. Screw the compressor air hose to 9. Connect the compressor plug to 12. All of the sealant is pumped into the connection on the sealant the accessory socket at the rear of the tyre. Then the tyre is inflated. bottle.
Page 152 15 minutes, the driver's field of view. must not be used. Seek the vehicle should not be driven. The assistance of your Holden Dealer. tyre is too severly damaged and 17. Continue driving immediately so that sealant is evenly distributed 18.
Page 153 Vehicle care The compressor and sealant can be Use the jack only at the vehicle was new, it can lose air used from approx. -30 °C. designated lifting points. Use in over time. Check the inflation The adapters supplied can be used other locations may result in the pressure regularly.
Page 154 Vehicle care ■ Never change more than one wheel Install the wheel wrench ensuring at once. that it locates securely and loosen each wheel nut by half a turn. ■ Use the jack only to change wheels in case of puncture. Variant 2: ■...
Page 155 Vehicle care Set the jack to the necessary height. Position it directly below the jacking point in a manner that prevents it from slipping. Place hand behind the edge of the 4. Ensure the jack is positioned cover on the sill panelling. correctly with the vehicle jacking Pull down and out to remove the points.
Page 156 Vehicle care Attach wheel wrench and with the jack correctly aligned rotate wheel wrench until wheel is clear of the ground. 6. Unscrew the wheel nuts. 7. Change the wheel. 8. Screw on the wheel nuts. 9. Lower vehicle. 10. Install the wheel wrench ensuring that it locates securely and tighten each nut in a crosswise Reinstall cover.
Page 157 Vehicle care Sedan with 17" or 18" alloy 9 Warning wheels and a 16" steel spare wheel As soon as possible after Stow in spare wheel well and secure changing a wheel, you should with the wing nut. have the wheels tightened with a torque of 150 Newton metre and Sportwagon with 16"...
Page 158 Vehicle care Sedan with 17" or 18" alloy wheels and a space saver spare wheel The removed wheel must be stowed in the spare wheel well and secured with the wing nut and LONG wheel tub stud. Vehicle tools 3 142. 1.
Page 159: Jump Starting
Vehicle care Jump starting 3. Remove the plastic spacer from Directional tyres the jack package and stow safely. Fit directional tyres such that they roll in the direction of travel. The rolling 4. Install the jack package over the Do not start with quick charger. direction is indicated by a symbol LONG wheel tub stud.
Page 160 Vehicle care ■ Switch off all unnecessary electrical Lead connection order: 9 Warning consumers. 1. Connect the red lead to the ■ The vehicles must not come into positive terminal of the booster Never expose the battery to naked contact with each other during the battery.
Page 161: Towing
Vehicle care Towing 3. Allow both engines to idle for approx. 3 minutes with the leads connected. Towing the vehicle 4. Switch on electrical consumers (e.g. headlights, heated rear window) of the vehicle receiving the jump start. 5. Reverse above sequence exactly when removing leads.
Page 162: Appearance Care
Road bloom is a gradual build up of anti-clockwise. To install the roof road and environmental grime. This antenna, rotate it clockwise. Seek the assistance of your Holden should be removed with a paint Dealer. If you wash your vehicle by hand,...
Page 163 Have the door hinges of all doors Wax the vehicle regularly (at the Rims are painted and can be treated greased by your Holden Dealer. latest when water no longer beads). with the same agents as the body. Polishing is necessary only if the paint...
Page 164 PVC coating. Have ■ Clean and protect leather at least underbody work carried out by your twice a year. Close Velcro fasteners as open Holden Dealer. ■ Do not use synthetic cloths or Velcro fasteners on clothing could brushes. damage seat upholstery.
Page 165: Service And Maintenance
Service and maintenance Service and General information When the change engine oil soon message displays in the DIC, have maintenance the engine oil and filter changed as Service information soon as possible within the next 1,000 In order to ensure economical and km.
Page 166 Service and maintenance Recommended fluids, Engine oil certification mark indicates that the oil has been approved to the dexos Engine oil is identified by its quality lubricants and parts specification. and its viscosity. Quality is more important than viscosity when Your vehicle was filled at the factory Recommended fluids and selecting which engine oil to use.
Page 167 Service and maintenance Topping up engine oil For acceptable alternative viscosity for consequences resulting from the grade oils 3 168. use of additional coolant additives will Engine oils of different manufacturers be rejected. and brands can be mixed as long as When selecting an oil of the they comply with the required engine appropriate viscosity grade be sure to...
Page 168 Service and maintenance 9 Warning Using brake fluid other than GM recommended brake fluid may cause corrosion to components of the braking system and reduced braking performance. Use only new brake fluid. Use of old, used or inferior brake fluid may endanger the functioning of the brake system.
Page 169: Technical Data
Technical data Technical data Vehicle identification Vehicle Identification Number Vehicle identification ....164 Vehicle data ....... 168 A further label is located in the vehicle floor on the right-hand side under a cover between the front door and seat. The Vehicle Identification Number is visible through the windscreen.
Page 170 Technical data Identification plate Information on identification label: Approval number Manufacturer Category Number of seats Vehicle identification number Compliance date Information on identification plate: Manufacturer An identification label is located on Body color the front left door frame. Build date Vehicle identification number A further identification plate is located under the bonnet on the dash panel.
Page 171 Technical data Engine serial number 1.6L Petrol engine 1.8L Petrol engine 1.4L Petrol engine The engine serial number is located The engine serial number is located in the front part of the engine next to the oil filter. The engine serial number is located compartment.
Page 172 Technical data 2.0L Diesel engine The engine serial number is located under the centre branch of the exhaust manifold.
Page 173 Technical data Vehicle data Recommended fluids and lubricants Manufacturer's specifications Engine oil specification Engine oil specification Best viscosity grade for the vehicle Alternative viscosity 1.4L Petrol dexos 2 5W-30 0W-30 1.6L Petrol dexos 1 5W-30 0W-30 1.8L Petrol dexos 1 5W-30 0W-30 2.0L Diesel...
Page 174 1.6L Petrol 1.8L Petrol 2.0L Diesel Number of cylinders 1364 1598 1796 1998 Piston displacement [cm Engine power [kW] Refer to holden.com.au at rpm Torque [Nm] Refer to holden.com.au at rpm Fuel type Petrol Petrol Petrol Diesel Octane rating RON Minimum –...
Page 175 Technical data Vehicle weight Additional weight Maximum vehicle payloads Vehicle Occupants (Average 68 kg each) Luggage (kg) Total Load (kg) 4 Door sedan 5 Door hatchback Sportwagon Maximum front and rear axle loads Vehicle Front axle loads (kg) Rear axle loads (kg) 1.4L Petrol 1060 1000...
Page 176 Technical data Vehicle dimensions 4 Door sedan EQUIPE/CDX SRi/SRi-V Length [mm] 4615 4629 Width without exterior mirrors [mm] 1797 1797 Height (without antenna) [mm] 1477 1477 Wheelbase [mm] 2685 2685 5 Door hatchback EQUIPE/CDX SRi/SRi-V Length [mm] 4519 4543 Width without exterior mirrors [mm] 1797 1797 Height (without antenna) [mm]...
Page 177 Technical data Sportwagon CD/CDX Length [mm] 4675 Width without exterior mirrors [mm] 1797 Height (without antenna) [mm] 1521 Wheelbase [mm] 2685...
Page 178 Technical data Capacities Engine oil Engine 1.4L Petrol 1.6L Petrol 1.8L Petrol 2.0L Diesel including Filter [l] Engine coolant Engine 1.4L Petrol 1.6L Petrol 1.8L Petrol 2.0L Diesel capacity [l] Fuel tank Petrol/diesel, nominal capacity [l]...
Page 179 Technical data Tyre pressures 4 Door sedan, 5 Door hatchback Tyre size Wheel size and profile Recommended pressure Normal load Eco normal load Maximum load Spare Front Rear Front Rear Front Rear – 215/50 R17 91V – – 17 x 7.0, J 225/50 R17 94V –...
Page 180 Technical data Sportwagon Tyre size Wheel size and profile Recommended pressure Normal load Eco normal load Maximum load Spare Front Rear Front Rear Front Rear – 205/60 R16 92V – – 16 x 6.5 , J 215/50 R17 91V – –...
Page 181: Customer Information
Owner Assistance ......176 be happy to assist you. Holden Customer Care Holden Customer Care Office At Holden, we want you to be completely satisfied with your Should you wish to speak to a ownership experience. This applies Holden representative, you are...
Page 182 Written Correspondence • Date of purchase 0800 HOLDEN (0800 465 336) You can also write to Holden at the • Current odometer reading This number provides access to address below: New Zealand Roadside Assistance Most of this information will be...
Page 183: Index
Index Accessories and vehicle Capacities ........173 modifications ......117 Catalytic converter ....... 96 Adjustable air vents ..... 89 Central locking system ....21 Airbag and belt tensioners ... 66 Charging system ......66 Airbag system ......40 Child locks ........25 Air conditioning regular operation 90 Child restraint installation Air conditioning system ....
Page 184 Footbrake........70 Instrument panel illumination ..137 Front airbag system ..... 41 Instrument panel illumination Electric adjustment ...... 29 Front fog lights ......80 control ........81 Electronic climate control system 85 Fuel for diesel engines ....109 Instrument panel overview ..... 9 Electronic driving programmes ..
Page 185 Mirror adjustment ......7 Rear window wiper/washer ..59 Sunglasses storage ..... 50 Misted light covers ....... 80 Recommended fluids and Sun visors ........32 lubricants ......161, 168 Symbols ......... 3 Refuelling ........110 New vehicle running-in ....92 Reversing lights ......
Page 186 Upholstery........159 Using this manual ......3 Vehicle battery ......127 Vehicle dimensions ....171 Vehicle Identification Number ..164 Vehicle messages ....... 72 Vehicle personalisation ....75 Vehicle storage......117 Vehicle unlocking ......4 Vehicle weight ......170 Warning chimes ......73 Washer and wiper systems ..
Page 187 JH CRUZE OWNER’S HANDBOOK...
Page 188 JH CRUZE OWNER’S HANDBOOK...
Page 189 Change of name, address or ownership In the event of a Safety Recall, or for various reasons, Holden may need to contact you as the owner of this vehicle. If you have recently changed your address, or name, or purchased this vehicle second-hand, please help us to help you by taking a few minutes to fill in and mail the forms at the beginning of the Service/warranty booklet.
Page 190 Contents Introduction ........2 In brief ..........4 Keys, doors and windows .... 19 Seats, restraints ......33 Storage ........48 Instruments and controls ..... 57 Lighting ........78 Climate control ......83 Driving and operating ....92 Vehicle care ....... 117 Service and maintenance ..
Page 191: Introduction
Introduction Introduction...
Page 192 Introduction Introduction ■ Depending on the model variant, Caution integrated special equipment and Your vehicle is a designed accessories, the scope of Text marked Caution provides combination of advanced technology, equipment of your vehicle can differ information on possible damage to safety, environmental friendliness from the descriptions in this and economy.
Page 193: In Brief
In brief In brief Vehicle unlocking Electronic key Radio remote control Initial drive information When in possession of the electronic key, press switch on door handle to unlock the vehicle and pull the door Press button c to unlock the doors handle to open the door.
Page 194 In brief Seat adjustment Seat positioning Seat backrests 9 Warning Only drive with the seat correctly adjusted. Pull handle, slide seat, release Pull lever, adjust inclination and handle. release lever. Allow the seat to engage audibly. Do not lean on Seat adjustment 3 35, Seat position backrest when adjusting.
Page 195 In brief Seat height Head restraint adjustment For horizontal adjustment, pull the head restraint forward, it engages in Lever pumping motion For height adjustment, pull the head 3 positions. To bring into rear position restraint upward. To move down higher automatically, pull head restraint press the catch and push the head close forward.
Page 196 In brief Seat belt Mirror adjustment Exterior mirrors Interior mirror Select the relevant exterior mirror and Pull out the seat belt and engage in adjust. belt buckle. The seat belt must not be Adjust the lever on the underside to Electric adjustment 3 29, Convex twisted and must fit close against the reduce glare.
Page 197 In brief Steering wheel adjustment Unlock lever, adjust steering wheel, then engage lever and ensure it is fully locked. Do not adjust steering wheel unless vehicle is stationary and steering wheel lock has been released. Airbag system 3 40, Ignition positions 3 93.
Page 198 In brief Instrument panel overview...
Page 199 In brief Light switch ......78 13 Front passenger airbag ..41 30 Anti-theft alarm system status LED ......27 14 Glovebox ......49 Front fog lights ..... 80 15 Climate control system ..83 Instrument illumination ..81 16 Traction control system ..103 Side air vents ......
Page 200 In brief Exterior lighting Press Headlight flash, high beam and low beam > = front fog lights (If fitted) Lighting 3 78. Turn headlight pull lever AUTO = Automatic light control: flash Headlights are switched high beam push lever on and off automatically low beam pull lever from high depending on external...
Page 201 In brief Turn and lane-change signals Hazard warning flashers Horn left lever up Operated with the ¨ button. Press j. right = lever down Hazard warning flashers 3 79. Turn and lane change signals 3 80.
Page 202 In brief Washer and wiper systems Windscreen washer system Rear window wiper and washer systems Windscreen wipers Pull lever. Press the rocker switch to activate the Windscreen washer system 3 58, fast rear window wiper: Washer fluid 3 127. slow upper position intermittent timed interval wiping...
Page 203 In brief Climate control Electronic climate control system (if fitted) Heated rear window, heated exterior mirrors Air conditioning system (if fitted) Push lever. Washer fluid is sprayed on the rear window and the wiper wipes a few Heating is operated by pressing the times.
Page 204 In brief Demisting and defrosting the Transmission Automatic transmission windows Manual transmission park reverse Press button V. neutral Reverse: when the vehicle is Set temperature control to warmest drive stationary, depress the clutch pedal level. and then pull up the ring on the shift Sport mode: move shift lever from D Cooling n on.
Page 205 In brief The shift lever can only be moved out Starting off Starting the engine of P when the ignition is on and the brake pedal is applied. To engage P Check before starting off or R, push the release button. ■...
Page 206 In brief Before restarting or to switch off the Starting engine with the To switch off the engine, press the engine, turn key back to 0. button again whilst the engine is Start/Stop button running. Starting the engine 3 93. ■...
Page 207 In brief Parking If the vehicle is on a downhill slope, engage reverse gear or set the shift ■ Always apply parking brake without lever to P before switching off the pressing release button. Apply as ignition. Turn the front wheels firmly as possible on a downhill towards the kerb.
Page 208 Keys, doors and windows Keys, doors and Keys, locks Radio remote control windows Keys Replacement keys The key number is specified on a Keys, locks ........19 detachable tag. Doors ........... 25 Locks 3 157. Vehicle security ......27 Exterior mirrors ......29 Key with foldaway key section Interior mirrors ......
Page 209 Keys, doors and windows Fault If the central locking system cannot be operated with the radio remote control, it may be due to the following: ■ Range exceeded, ■ Battery voltage too low, ■ Frequent, repeated operation of the remote control while not in range, which will require resynchronisation, ■...
Page 210 Keys, doors and windows Radio remote control Batteries do not belong in household ■ Battery voltage too low, waste. They must be disposed of at ■ Interference from higher-power an appropriate recycling collection radio waves from other sources. point. Try repositioning the electronic key or Radio remote control battery follow the electronic key manual replacement 3 19.
Page 211 Keys, doors and windows Unlocking Electronic key system Locking Remote control Remote control Close doors, boot and fuel filler flap. Press switch on a door handle to unlock the vehicle and pull the door handle to open the door, or press the Press button c.
Page 212: Keys, Doors And Windows
Keys, doors and windows Electronic key system Unlocking the boot lid 4 Door sedan 5 Door hatchback, Sportwagon Press the switch on a door handle. Press button x. The boot lid will unlock and open, whilst all other The electronic key must be outside Press button c once or twice, doors remain locked.
Page 213 Keys, doors and windows Fault in remote control system switch off the ignition, close the driver's door and lock it from the or electronic key system outside with the key. Unlocking Fault in central locking system Unlocking Manually unlock the driver's door by turning the key in the door barrel.
Page 214 Keys, doors and windows Doors Automatic locking 9 Warning Automatic locking after driving Load compartment Use the child locks whenever children are occupying the rear Opening This security feature can be seats. configured to automatically lock all 5 Door hatchback, Sportwagon doors, boot and fuel filler flap as soon Using a key or suitable screwdriver, as the vehicle starts to drive.
Page 215 Keys, doors and windows 4 Door sedan Note The installation of certain heavy accessories onto the boot lid may affect its ability to remain open. Closing 5 Door hatchback 9 Danger Push the button under the boot lid moulding or press button x on the Do not drive with the boot lid open remote control until boot lid is opened.
Page 216 Keys, doors and windows Vehicle security ■ Self-activated 30 seconds after Status LED locking the vehicle (initialisation of the system), or Anti-theft alarm system ■ Remote control: directly by Anti theft alarm system monitors: pressing e once more after locking, ■...
Page 217 (only electronic key assistance of your Holden Dealer. system) or switching on the ignition. Note Immobiliser The immobiliser does not lock the Unlocking the vehicle by pressing doors.
Page 218 Keys, doors and windows Exterior mirrors Then swivel the control to adjust the Heated mirrors mirror. Convex shape Air conditioning system (if fitted) Folding mirrors The convex exterior mirror reduces blind spots. The shape of the mirror makes objects appear smaller, which will affect the abilty to estimate distances.
Page 219 Keys, doors and windows Interior mirrors Windows Electronic climate control system (if fitted) Manual anti-dazzle Power windows 9 Warning Take care when operating the power windows. Risk of injury, particularly to children. If there are children on the rear seat, switch on the child safety system for the power windows.
Page 220 Keys, doors and windows Operation of passenger's Child safety system for rear window and rear windows windows Pushing or pulling lightly to the first detent: window moves down or up as long as switch is operated. Pushing further to the second detent and then releasing: window moves down automatically.
Page 221 Keys, doors and windows warning message or a warning code Heated rear window Electronic climate control is displayed in the Driver Information system (if fitted) Centre. Air conditioning system (if fitted) Vehicle messages 3 72. Activate the window electronics as follows: 1.
Page 222: Seats, Restraints
Seats, restraints Seats, restraints Head restraints Head restraints on front seats Height adjustment Position Head restraints ......33 9 Warning Front seats ........34 Rear seats ........37 Only drive with the head restraint Seat belts ........37 set to the proper position. Airbag system ......
Page 223: Front Seats
Seats, restraints Front seats Head restraints on rear seats Height adjustment Seat position 9 Warning Only drive with the seat correctly adjusted. Horizontal adjustment To adjust horizontally, pull the head restraint forwards and engage in one of three positions. Pull the head restraint upwards. To return to its rearmost position, pull To move down press the catch and fully forwards and release.
Page 224 Seats, restraints applying the pedals. Slide the Seat adjustment Pull handle, slide seat, release passenger seat as far back as handle. possible. 9 Danger Seat backrests ■ Sit with your shoulders as far back against the backrest as possible. Do not sit nearer than 25 cm from Set the backrest rake so that you the steering wheel, to permit safe can easily reach the steering wheel...
Page 225 Seats, restraints Seat height Horizontal adjustment Activate front seat heating (while the engine is running) by pressing the ß Push button to slide the armrest. Lever pumping motion button in the control knob for higher temperature (left seat) or fan speed Heating down = lower...
Page 226: Rear Seats
Seats, restraints Rear seats Seat belts 9 Danger Armrest Seat belt reminder for driver's seat Fasten seat belt before each trip. and front passenger seat, seat belt In the event of an accident, people control indicator X 3 66. not wearing seat belts endanger their fellow occupants and themselves.
Page 227 Cleaning replaced. After an accident, have the may safely be carried out using belts and triggered belt tensioners mild soap and water. The belt replaced by your Holden Dealer. should be replaced if webbing becomes frayed, contaminated or Note damaged.
Page 228 Seats, restraints Triggered belt tensioners must be Withdraw belt from reel, guide it 9 Warning replaced by your Holden Dealer. Belt untwisted across the body and tensioners can only be triggered engage the latch plate in the buckle. The belt must not rest against hard once.
Page 229: Airbag System
Do not stick anything on the airbag covers and do not cover them with other materials. Each airbag is triggered only once. Have deployed airbags replaced by a Holden Dealer.
Page 230 Only then the airbag is instrument panel, all panelling parts, able to protect. the door seals, the handles and the seats replaced by your Holden Dealer. Control indicator v for airbag systems 3 66. Front airbag system...
Page 231 Seats, restraints Side airbag system Depending on the body style, a The risk of injury to the upper body different airbag label may be located and pelvis in the event of a side-on The side airbag system consists of an on the passenger's sunvisor.
Page 232: Child Restraints
Seats, restraints Child restraints Curtain airbag system Child restraint systems When a child restraint system is being used, pay attention to the following usage and installation instructions and also those supplied with the child restraint system. The risk of injury to the head in the event of a side impact is considerably The curtain airbag system consists of reduced.
Page 233 Depending on the body style, a approved child restraints. Holden equipment to the vehicle. different airbag label may be located strongly recommends that you Only child restraints that have clips on the passenger's sunvisor.
Page 234 Seats, restraints Ensure that the child restraint system the child wears it. Please see the Always follow the child restraint to be installed is compatible with the instructions on the relevant products manufacturer’s fitting instructions vehicle type. for child restraints. when installing a child restraint Ensure that the mounting location of into the vehicle.
Page 235 Seats, restraints Child restraint installation locations Permissible options for fitting a child restraint system Weight and age class On front passenger seat On rear outboard seats On rear centre seat Group 0: up to 10 kg or approx. 10 months Group 0+: up to 13 kg or approx.
Page 236 Seats, restraints Isofix child restraint In addition to the ISOFIX mounting, fasten the top-tether straps to the top- systems tether anchorage points. Top-tether child restraint systems 3 47. Top-tether child restraint systems The strap must run between the two guide rods of the head restraint. When using Top-tether for seat Fasten vehicle-approved ISOFIX mounting, universally approved child...
Page 237: Storage
Storage Storage Storage compartments Instrument panel storage Storage on top of the instrument 9 Warning panel Storage compartments ....48 Do not not store heavy or sharp Load compartment ....... 50 objects in the storage Roof rack system ......55 compartments.
Page 238 Storage Storage below the light switch Glovebox Cupholders Pull the grip to open the box. To open pull the grip. Cupholders are located in the centre console. 9 Warning To reduce the risk of injury in an accident or a sudden stop, always keep the glovebox door closed while driving.
Page 239 Storage Load compartment Additional cupholders are located in Armrest storage the rear armrest, when it is folded down. Storage in the front armrest Folding down rear seat backrests Sunglasses storage The rear backrest is divided into two (If fitted) parts. Both parts can be folded down. Push head restraints down by pressing the catch.
Page 240 Storage Insert all safety belts into the slots, if Rear storage seat belts are not coiled up On Sportwagon a tray is located automatically. behind the rear seats. The centre rear safety belt may lock when you raise the seatback. If this Removing tray happens, let the belt go back all the way and start again.
Page 241 Storage Load compartment cover Opening cover Do not place any objects on the cover. 5 Door hatchback Removing Lift cover at the rear and push it upwards at the front, from Pull the handle at the end of the cover underneath.
Page 242 Storage Cover in upper position Removing cover Rear floor storage cover Rear floor cover, Sportwagon Push the handle at the end of the Open the load compartment cover. cover downwards. The rear of the Pull the end of the cover inwards and cover is guided upwards lift the cover.
Page 243 Storage Lashing eyes Installation Behind the front seats Behind the rear seats Attach strap to eyes underneath the The lashing eyes are designed to rear seat cushion. secure items against slippage, e.g. Attach lower hook with opening facing Fold backrests forward. using lashing straps or luggage net.
Page 244 For safety reasons, and to avoid the roof frame: suspend and engage damaging the roof, use only the rod of net at one side, compress rod roof rack approved by Holden for and suspend and engage at other your vehicle. The maximum side.
Page 245 Storage Loading information ■ When transporting objects in the and secure it properly with retaining load compartment, the backrests of straps. Adjust the tyre pressure and the rear seats must not be angled vehicle speed according to the load forward. conditions.
Page 246: Instruments And Controls
Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Controls ........57 Warning lights, gauges and indi‐ cators ........... 61 Information displays ..... 70 Vehicle messages ......72 Trip computer ....... 74 Vehicle personalisation ....75 The Infotainment system can be operated by the controls on the steering wheel.
Page 247 Instruments and controls Horn Windscreen wiper/washer Adjustable wiper interval Windscreen wiper Wiper lever in position P. Press j. Turn the adjuster wheel to adjust the fast desired wipe interval: slow short turn adjuster wheel timed interval wiping interval downwards § = long turn adjuster wheel interval...
Page 248 Instruments and controls Windscreen washer Rear window wiper/washer Push lever. Washer fluid is sprayed onto the rear window and the wiper Pull lever. Washer fluid is sprayed Press the rocker switch to activate the wipes a few times. onto the windscreen and the wiper rear window wiper: Do not use if the rear window is swipes for a few strokes.
Page 249 Instruments and controls The rear window washer system is Colour-Info-Display deactivated when the fluid level is Set date and time low. To set the time: Outside temperature 1. Press CLOCK, then rotate and press MENU SEL to select SET TIME. 2.
Page 250 Instruments and controls Warning lights, gauges To set the date: 12V power outlets are located in the front and rear floor console. 1. Press CLOCK, then rotate and and indicators press MENU SEL to select SET Do not exceed the maximum power DATE.
Page 251 Instruments and controls Odometer recorded distance reaches 2000, trip Caution odometer automatically shows 0 without resetting. If the needle is in the red warning zone, the maximum permitted Tachometer engine speed is exceeded. Engine is at risk. Fuel gauge The bottom line displays the recorded distance.
Page 252 Instruments and controls Because of the fuel remaining in the an oil change is necessary. CodE 82 Caution tank, the top-up quantity may be less or Change Engine Oil Soon appears than the specified tank capacity. in the Driver Information Centre. Do not continue driving with the Change the oil as soon as possible temperature gauge needle in the...
Page 253 Instruments and controls Display of remaining engine oil life versions. Depending on the equipment, the position of the control indicators may vary. Different displays are used depending on model. When the ignition is switched on, most control indicators will illuminate briefly as a functionality test.
Page 254 Instruments and controls Control indicators in the instrument...
Page 255 Have the cause of the fault starting the engine or reaching a 3 137. remedied immediately by your specific distance or speed, or until the Holden Dealer. Turn signals 3 80. seat belt is fastened. Airbag system, belt tensioners 3 40, Flashes Seat belt reminder 3 37.
Page 256 3 127. Antilock brake system 3 101. Seek the assistance of your Holden Dealer. 9 Warning Power steering Malfunction indicator light Stop.
Page 257 Have the cause of the fault in the system remedied by your Holden ■ If the control indicator remains n illuminates yellow. Dealer. illuminated, turn the steering wheel...
Page 258 % illuminates or flashes yellow. Illuminates for a few seconds after the Check oil level before seeking Caution ignition is switched on. assistance of your Holden Dealer 3 124. The diesel particle filter requires Engine lubrication may be cleaning. interrupted. This may result in...
Page 259 The engine cannot be started. Illuminates when the front fog lights are on 3 80. Have the cause of the fault remedied by your Holden Dealer. Cruise control Apply footbrake m illuminates white or green. 0 Press Brake to Start Engine is Illuminates white displayed on the DIC.
Page 260 Instruments and controls Turn the adjuster wheel to scroll through a menu option or to set a numeric value. Press the SET/CLR button to select a function or to confirm a message. Vehicle personalisation 3 75. Trip computer 3 74. Colour-Info-Display The vehicle has a Colour-Info-Display.
Page 261 27 Right front turn indicator failure If necessary seek the assistance of Selecting menus and settings your Holden Dealer. 28 Right rear turn indicator failure Rotate the MENU SEL button to scroll Vehicle messages on the...
Page 262 Instruments and controls ■ Wiper/washer system ■ If a warning code appears in the Driver Information Centre. ■ Doors, windows ■ If the parking assist detects an ■ Remote control object (If fitted). ■ Seat belts When the vehicle is parked and/ ■...
Page 263 Instruments and controls Trip computer Trip meter To reset, press the SET/CLR button for a few seconds. The menus and functions can be Average consumption selected with the turn signal lever. Display of average consumption. The measurement can be reset at any time.
Page 264 Instruments and controls Vehicle personalisation Instantaneous consumption Display of the instantaneous consumption is displayed while the The vehicle's parameters can be vehicle is moving. personalised by changing the settings in the Driver Information Centre and in the Info-Display. Depending on vehicle equipment some of the functions described below might not be available.
Page 265 Instruments and controls Different displays are used In the corresponding submenus the Different displays are used depending on model. following settings can be changed by depending on model. rotating and pressing the MENU Displayed units cannot be changed. 3 Press the SET/CLR button to select SEL knob: (Metric) is the only setting available.
Page 266 Instruments and controls ■ Display Off: Switches off the rear window wiper when reverse ■ Remote Lock / Unlock / Start display. Press any button to switch gear is engaged. Remote Unlock Feedback: Activate back on. ■ Collision Detection Systems or deactivate flashing the lights ■...
Page 267: Lighting
Lighting Lighting Exterior lighting Parking lights Headlights and parking lights Light switch When switching on ignition, automatic Exterior lighting ......78 light control is always active. Interior lighting ......81 When lights are on, 8 lights up. Lighting features ......82 Control indicator 8 3 70.
Page 268 Lighting Automatic light control function High beam Headlight flash When the automatic light control To activate the headlight flash, pull function is switched on and the lever. engine is running, the system switches the headlights and taillights Hazard warning flashers on and off according to ambient light conditions.
Page 269 Lighting Misted light covers Turn and lane-change Switch the indicator off manually by moving the lever to its original signals The inside of the light housing may position. mist up briefly in poor, wet and cold weather conditions, in heavy rain or Front fog lights after washing.
Page 270 Lighting Interior lighting Turn knob k and hold until the desired Operate rocker switch: brightness is obtained. automatic switching on Instrument panel and off Interior lights press u = always on illumination control press v = always off Courtesy light Reading lights Brightness of the following lights can be adjusted when the exterior lights...
Page 271 Lighting Lighting features Exit lighting Headlights and tail lights illuminate Entry lighting the way for an adjustable time after leaving the vehicle. Welcome lighting Activation, deactivation and duration Headlights, tail lights and interior of lighting of this function can be lights illuminate for a short time when changed in the menu Vehicle unlocking the vehicle with the remote...
Page 272: Climate Control
Climate control Climate control Climate control systems 9 Danger Air conditioning system Do not sleep in a vehicle with the air conditioning or heating system (If fitted) Climate control systems ....83 on. It may cause serious harm or Air vents ........89 death due to a drop in the oxygen level and/or body temperature.
Page 273 Climate control Heating will not be fully effective until Air conditioning n The exchange of fresh air is the engine has reached its operating Operated with the n button and is reduced in air recirculation mode. temperature. functional only when the engine and In operation without cooling the air fan are running.
Page 274 Climate control Maximum cooling Indication of settings Adjust the air flow by switching the fan (Info-Display) to the desired speed. ■ Push button V: the air distribution is directed automatically to the windscreen. Each change of settings is indicated ■ Set temperature control to warmest Briefly open the windows so that hot in the Info-Display for a few seconds.
Page 275 Climate control Controls for automatic mode: The preselected temperature is 9 Danger automatically regulated. In the AUTO automatic mode, all automatic mode the fan speed and air settings except Do not sleep in a vehicle with the distribution automatically regulate the temperature are air conditioning or heating system air flow.
Page 276 Climate control Automatic mode AUTO Air distribution is selected If the maximum temperature is set, automatically in automatic mode. The the climate control system runs at air vents should therefore always be maximum heating. open. Demisting and defrosting the Temperature preselection windows V ■...
Page 277 Climate control Fan speed x Air distribution MODE Return to automatic air distribution: Deactive corresponding setting or press button AUTO. Cooling n Activate or deactivate with the n button. The air conditioning system cools and dehumidifies (dries) the interior of the vehicle.
Page 278 Climate control Air vents 9 Warning Adjustable air vents The exchange of fresh air is reduced in air recirculation mode. At least one air vent must be open In operation without cooling the air while cooling is on in order to prevent humidity increases, so the the evaporator from icing up due to windows may mist up.
Page 279 Remove any leaves, Service dirt or snow. For optimal cooling performance, it is recommended to have the climate control system checked annually by your Holden Dealer. ■ Functionality and pressure test ■ Heating functionality ■ Leakage check...
Page 280 Climate control ■ Check of drive belts ■ Cleaning of condenser and evaporator drainage ■ Performance check...
Page 281: Driving And Operating
Driving and operating Driving and operating Driving hints Starting and operating Control of the vehicle New vehicle running-in Use the following precautions for the Driving hints ......... 92 Never coast with engine not first few hundred kilometres to Starting and operating ....92 running improve the performance and Engine exhaust ......
Page 282 Driving and operating Starting the engine Diesel particle filter 3 95. ■ Diesel engine: turn the key to position 2 for preheating until control indicator ! goes out Ignition switch positions Starting engine with the ignition switch ■ Turn the key to position 3 and release when engine is running Before restarting or to switch off the engine, turn key back to 0.
Page 283 Driving and operating ■ Automatic transmission: depress yellow LED in the button illuminates. Electronic key manual override brake and move shift lever to P or N In this mode steering wheel lock is If either the battery of the electronic released and some electrical key is weak or the radio remote ■...
Page 284: Engine Exhaust
■ Do not park the vehicle on an easily console. Place the electronic key over ignitable surface. The high the cover with the Holden Logo facing 9 Danger temperature of the exhaust system could ignite the surface.
Page 285 3 109, If g illuminates additionally, 3 169 could damage the catalytic cleaning is not possible, seek the converter or electronic assistance of your Holden Dealer. components. Under certain driving conditions, e.g. Unburnt petrol will overheat and Caution short distances, the system cannot damage the catalytic converter.
Page 286: Automatic Transmission
The automatic transmission permits problems, have the cause of the fault manual gearshifting (manual mode) rectified by your Holden Dealer as or automatic gearshifting (automatic soon as possible. In an emergency, mode). driving can be continued for a short...
Page 287 Driving and operating To start the engine, press the brake Sport mode To activate sport mode: pedal in either P or N position. 1. Move shift lever to position D. (If fitted) Do not accelerate while engaging a 2. Push the shift lever to the left. gear.
Page 288 Driving and operating Manual mode No automatic shifting to a higher gear Kickdown takes place at high engine revolutions. For reasons of safety, kickdown is also available in manual mode. Electronic driving programmes ■ Following a cold start, the operating temperature programme increases engine speed to quickly bring the catalytic converter to the required...
Page 289 P. If P is engaged again, the shift lever Have the cause of the fault remedied will be locked in position again. by your Holden Dealer. Have the cause of the power supply interruption remedied by Interruption of power your Holden Dealer.
Page 290: Manual Transmission
Considerably more force is needed for this. The braking distance is extended. Seek the assistance of your Holden Dealer before continuing your journey. When the engine is not running, the support of the brake servo unit...
Page 291 Control indicator & 3 67. Have the cause of the fault ABS control is made apparent remedied by your Holden Dealer. through a pulse in the brake pedal Brake assist and the noise of the regulation...
Page 292: Ride Control Systems
Driving and operating Ride control systems TC is reactivated by pressing the a 9 Warning button again. Traction Control system TC is also reactivated the next time Do not let this special safety the ignition is switched on. feature tempt you into taking risks Traction control system (TC) when driving.
Page 293: Cruise Control
Driving and operating Cruise control Control indicator n illuminates and 9 Warning both ESC and TC are deactivated. ESC is reactivated by pressing the a The cruise control can store and Do not let this special safety button again. If the TC System was maintain speeds.
Page 294 Driving and operating Switching on Reduce speed Switching off Press rocker switch m at the upper With cruise control active, hold thumb Press rocker switch m at the lower end, control indicator m illuminates wheel turned to SET/- or briefly turn to end, control indicator m is off.
Page 295: Object Detection Systems
Driving and operating Object detection Additionally if the system does not Control indicator r 3 68. work due to temporary conditions like systems Note snow covered sensors, r Attached parts in the detection area illuminates. cause system malfunction. Parking assist Important hints for using the Activation (If fitted)
Page 296 Driving and operating Functionality Special conditions apply if there 9 Warning are taller vehicles involved (e.g. off-road vehicles, mini vans, The rear view camera does not vans). Object identification in the replace driver vision. Note that upper part of these vehicles objects that are outside the cannot be guaranteed.
Page 297 Driving and operating 5 Door hatchback: The camera is Warning symbols Fault mounted in the rear bumper above Warning symbols are indicated as The rear view camera may not the license plate. triangles 9 on the picture which show operate properly when: obstacles detected by the rear ■...
Page 298: Fuel
Driving and operating Fuel Equivalent standardised fuels with an acid methyl ester ("FAME"), also ethanol content of max. 10% by known as "B5", is also permitted volume may be used. provided that the FAME meets the Fuel for petrol engines Euro standard EN 14214 and the Use clean, unleaded petrol of regular 9 Warning...
Page 299 New Vehicle Before refuelling, switch off engine Warranty. In no event will GM and mobile phones. Holden be responsible or bear any Follow the operating and safety liabilty for any damage or loss that instructions of the filling station may arise in connection with the when refuelling.
Page 300: Trailer Hitch
Your The fuel filler cap can be retained in Holden Dealer will help supply and the bracket on the fuel filler flap. install towing equipment to suit your When refuelling, fully insert the pump requirements.
Page 301 Never exceed the loads given for the towing equipment fitted to the vehicle. For your safety and the vehicle’s durability, all mandatory equipment must be fitted. Otherwise you may void the New Vehicle Warranty, to the extent that Holden considers the overloading or missing equipment to have affected the specifications or quality of the vehicle.
Page 302 Holden towing equipment is recommended where it is available. Where it is not available, no recommendation is made as to the make of equipment to be used. Holden will not accept liability for defects occurring in inappropriate towing equipment or for defects in the vehicle arising from the use of such equipment or for loss or injury caused by use of such equipment.
Page 303 Driving and operating If the tow ball load is too light or too heavy, the steering and handling of the vehicle may be affected. As a general guideline, for single axle trailers, the ball load should be approximately 10 % of the loaded trailer mass. For heavy trailers with more than one axle, the ball load should be in the range of 5 % - 10 % of the loaded trailer mass.
Page 304 Driving and operating Note At no time may the maximum towing capacity exceed the maximums specified. Refer to Maximum towing capacity previously in this chapter. At no time may the total rear axle load exceed the maximums specified. Refer to Loading the vehicle previously in this chapter.
Page 305 Remember that bull bars may affect airbag operation. Running in before towing Holden recommends that you drive your new vehicle for at least 1,500 km before towing. If you must tow in the first 1,500 km of the vehicle’s life, do not exceed 80 km/h.
Page 306: Vehicle Care
Vehicle care Vehicle care General Information ■ Check coolant anti-freeze and corrosion protection. Accessories and vehicle ■ Adjust tyre pressure to the value specified for full load. modifications General Information ....117 ■ Park vehicle in dry, well ventilated We recommend to use Genuine Parts Vehicle checks ......
Page 307: Vehicle Checks
Vehicle care Vehicle checks ■ Check the coolant level. 9 Danger ■ Fit the number plate if necessary. Performing work The ignition system uses extremely high voltage. Do not touch. Bonnet Opening 9 Warning Only perform engine compartment checks when the ignition is off. The cooling fan may start operating even if the ignition is off.
Page 308 Vehicle care Closing Before closing the bonnet, press the support into the holder. Lower the bonnet and allow it to drop into the catch. Check that the bonnet is engaged. Push the safety catch to the right and open the bonnet. Secure the bonnet support.
Page 309 Vehicle care Engine compartment overview 1.4L Petrol engine...
Page 310 Vehicle care 1.6L Petrol engine...
Page 311 Vehicle care 1.8L Petrol engine...
Page 312 Vehicle care 2.0L Diesel engine...
Page 313 Vehicle care 1. Power steering fluid container Different dipsticks are used 3 126 depending on engine variant. 2. Brake fluid container 3 127 1.4L Petrol: 3. Engine oil cap 3 124 4. Engine coolant container 3 126 5. Fuse box 3 138 6.
Page 314 Vehicle care When the engine oil level has Caution dropped to the MIN mark, top up engine oil. When driving at a slope, the warning code 79 might be displayed in the Driver Information Centre 3 72. If the code disappears when driving in a flat area again, do not top up engine oil.
Page 315 Vehicle care Engine coolant concentration checked and have the cause of the coolant loss remedied by The coolant provides freeze your Holden Dealer. protection down to approx. -28 °C. Power steering fluid 9 Warning Caution Do not spill coolant on the vehicle's exterior surfaces.
Page 316 Avoid contact with eyes, The vehicle is equipped with a lead skin, fabrics and painted surfaces. If the fluid level is too low, seek the acid battery. The battery is assistance of your Holden Dealer. maintenance-free. Washer fluid Caution A specifically developed battery with a ventilation system is required for this vehicle.
Page 317: Bulb Replacement
5 seconds. Use only the same bulb type for If the engine fails to start, seek the replacement. assistance of your Holden Dealer. Replace headlight bulbs from within the engine compartment. Wiper blade replacement Halogen headlights Lift wiper arm.
Page 318 Vehicle care 4. Remove bulb from reflector housing. 5. When fitting a new bulb, engage the lugs in the recesses on the reflector. 6. Engage the spring clip. 7. Place headlamp protective cover in position. 8. Plug connector onto bulb. Parking lights 2.
Page 319 2. Push bulb into socket slightly, rotate anti-clockwise, remove and renew bulb. 3. Insert bulb holder in reflector, 1. Open both covers. rotate clockwise to engage. Fog lights 1. Rotate bulb holder anti-clockwise and disengage. Have bulbs replaced by your Holden Dealer.
Page 320 Vehicle care 5. Rotate bulb holder anti-clockwise. 2. Unscrew both screws. 4. Reverse light (1) Turn signal light (2) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (3) clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and rotate clockwise into place.
Page 321 Vehicle care Tail lights in boot lid 3. Remove bulb holder. Push bulb into socket slightly, rotate anti- clockwise, remove and renew bulb. 4. Insert bulb holder into boot. Refit the inner panelling to boot lid. 5. Switch on ignition, operate and check the lights.
Page 322 Vehicle care Sportwagon 4. Turn signal light (1) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (2) 1. Open both covers. clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and screw into place.
Page 323 Vehicle care 4. Turn signal light (1) 6. Remove bulb holder. Push bulb into socket slightly, rotate anti- Tail light/brake light (2) clockwise, remove and renew bulb. 7. Insert bulb holder into the tail light assembly and screw into place. Install tail light assembly in body and tighten screws.
Page 324 4. Insert bulb holder in bulb housing clockwise. Attach cover. and rotate clockwise. 4. Switch on ignition, operate and 5. Insert bulb housing and secure using a screwdriver. check the lights. Side turn signal lights Have bulbs replaced by your Holden Dealer.
Page 325 5. Insert bulb holder in bulb housing 2. Remove bulb housing downward, and rotate clockwise. taking care not to pull on the 6. Insert and engage bulb housing. cable. Interior lights Courtesy light, reading lights Have bulbs replaced by your Holden Dealer.
Page 326: Electrical System
There are two fuse boxes in the illumination vehicle: ■ in the front left of the engine Have bulbs replaced by your Holden compartment, Dealer. ■ in the interior behind the glove box. In a box above the positive terminal of the battery are some main fuses.
Page 327 Vehicle care Engine compartment fuse Place the fuse extractor on the various types of fuse from the top or side, and withdraw fuse. The fuse box is in the front left of the engine compartment. Disengage the cover, lift it upwards and remove.
Page 328 Vehicle care No. Circuit No. Circuit Transmission control module 18 Fuel system control module Engine control module 19 – – 20 Fuel pump Canister vent sol 21 Rear power windows Ignition 22 – Front wipers 23 – – 24 Front power windows Fuel injection 25 Electronic vacuum pump Fuel injection, ignition system...
Page 329 Vehicle care No. Circuit No. Circuit No. Circuit 35 Infotainment system, Amplifier 52 Instrument panel 69 Battery voltage sensor 36 – 53 Electrochromatic mirror 70 Rain sensor 37 High beam, right side 54 Light switch, Light control 71 – 38 High beam, left side 55 Mirror folding Instrument panel fuse box 39 –...
Page 330 Vehicle care No. Circuit No. Circuit Body control module 25 Steering column lock Body control module 26 Rear power outlet 10 Body control module 11 Interior fan 12 – 13 Heated seats 14 Diagnostic connector No. Circuit 15 Airbag 16 Central locking system Infotainment system, handsfree phone 17 Air conditioning system...
Page 331: Vehicle Tools
Vehicle care Vehicle tools Vehicles with spare wheel Tools Vehicles with tyre repair kit A LONG wheel tub stud may also be stored with the vehicle tools. The jack and the tools are in a stowage compartment in the boot below the spare wheel.
Page 332: Wheels And Tyres
Regularly check the wheels and tyres Check tread depth at regular for damage. Seek the assistance intervals. from your Holden Dealer in the event of damage or unusual tyre wear. Refer to the tyre pressure placard on Tyres should be replaced for safety reasons when the front right door frame.
Page 333 Vehicle care location of the damage. If in doubt If there is more wear at the front than Tyre chains about the extent of the damage to the rear, swap round front wheels and the tyre, have it removed from the rear wheels.
Page 334 Vehicle care Tyre repair kit (If fitted) Minor damage to the tyre tread or sidewall can be repaired with the tyre repair kit. Do not remove foreign bodies from the tyres. Tyre damage exceeding 4 mm or that is at tyre's side wall near the rim The tyre repair kit is in a compartment 3.
Page 335 Vehicle care 4. Screw the compressor air hose to 9. Connect the compressor plug to 12. All of the sealant is pumped into the connection on the sealant the accessory socket at the rear of the tyre. Then the tyre is inflated. bottle.
Page 336 15 minutes, the driver's field of view. must not be used. Seek the vehicle should not be driven. The assistance of your Holden Dealer. tyre is too severly damaged and 17. Continue driving immediately so that sealant is evenly distributed 18.
Page 337 Vehicle care The compressor and sealant can be Use the jack only at the vehicle was new, it can lose air used from approx. -30 °C. designated lifting points. Use in over time. Check the inflation The adapters supplied can be used other locations may result in the pressure regularly.
Page 338 Vehicle care ■ Never change more than one wheel Install the wheel wrench ensuring at once. that it locates securely and loosen each wheel nut by half a turn. ■ Use the jack only to change wheels in case of puncture. Variant 2: ■...
Page 339 Vehicle care Set the jack to the necessary height. Position it directly below the jacking point in a manner that prevents it from slipping. Place hand behind the edge of the 4. Ensure the jack is positioned cover on the sill panelling. correctly with the vehicle jacking Pull down and out to remove the points.
Page 340 Vehicle care Attach wheel wrench and with the jack correctly aligned rotate wheel wrench until wheel is clear of the ground. 6. Unscrew the wheel nuts. 7. Change the wheel. 8. Screw on the wheel nuts. 9. Lower vehicle. 10. Install the wheel wrench ensuring that it locates securely and tighten each nut in a crosswise Reinstall cover.
Page 341 Vehicle care Sedan with 17" or 18" alloy 9 Warning wheels and a 16" steel spare wheel As soon as possible after Stow in spare wheel well and secure changing a wheel, you should with the wing nut. have the wheels tightened with a torque of 150 Newton metre and Sportwagon with 16"...
Page 342 Vehicle care Sedan with 17" or 18" alloy wheels and a space saver spare wheel The removed wheel must be stowed in the spare wheel well and secured with the wing nut and LONG wheel tub stud. Vehicle tools 3 142. 1.
Page 343: Jump Starting
Vehicle care Jump starting 3. Remove the plastic spacer from Directional tyres the jack package and stow safely. Fit directional tyres such that they roll in the direction of travel. The rolling 4. Install the jack package over the Do not start with quick charger. direction is indicated by a symbol LONG wheel tub stud.
Page 344 Vehicle care ■ Switch off all unnecessary electrical Lead connection order: 9 Warning consumers. 1. Connect the red lead to the ■ The vehicles must not come into positive terminal of the booster Never expose the battery to naked contact with each other during the battery.
Page 345: Towing
Vehicle care Towing 3. Allow both engines to idle for approx. 3 minutes with the leads connected. Towing the vehicle 4. Switch on electrical consumers (e.g. headlights, heated rear window) of the vehicle receiving the jump start. 5. Reverse above sequence exactly when removing leads.
Page 346: Appearance Care
Road bloom is a gradual build up of anti-clockwise. To install the roof road and environmental grime. This antenna, rotate it clockwise. Seek the assistance of your Holden should be removed with a paint Dealer. If you wash your vehicle by hand,...
Page 347 Have the door hinges of all doors Wax the vehicle regularly (at the Rims are painted and can be treated greased by your Holden Dealer. latest when water no longer beads). with the same agents as the body. Polishing is necessary only if the paint...
Page 348 PVC coating. Have ■ Clean and protect leather at least underbody work carried out by your twice a year. Close Velcro fasteners as open Holden Dealer. ■ Do not use synthetic cloths or Velcro fasteners on clothing could brushes. damage seat upholstery.
Page 349: Service And Maintenance
Service and maintenance Service and General information When the change engine oil soon message displays in the DIC, have maintenance the engine oil and filter changed as Service information soon as possible within the next 1,000 In order to ensure economical and km.
Page 350 Service and maintenance Recommended fluids, Engine oil certification mark indicates that the oil has been approved to the dexos Engine oil is identified by its quality lubricants and parts specification. and its viscosity. Quality is more important than viscosity when Your vehicle was filled at the factory Recommended fluids and selecting which engine oil to use.
Page 351 Service and maintenance Topping up engine oil For acceptable alternative viscosity for consequences resulting from the grade oils 3 168. use of additional coolant additives will Engine oils of different manufacturers be rejected. and brands can be mixed as long as When selecting an oil of the they comply with the required engine appropriate viscosity grade be sure to...
Page 352 Service and maintenance 9 Warning Using brake fluid other than GM recommended brake fluid may cause corrosion to components of the braking system and reduced braking performance. Use only new brake fluid. Use of old, used or inferior brake fluid may endanger the functioning of the brake system.
Page 353: Technical Data
Technical data Technical data Vehicle identification Vehicle Identification Number Vehicle identification ....164 Vehicle data ....... 168 A further label is located in the vehicle floor on the right-hand side under a cover between the front door and seat. The Vehicle Identification Number is visible through the windscreen.
Page 354 Technical data Identification plate Information on identification label: Approval number Manufacturer Category Number of seats Vehicle identification number Compliance date Information on identification plate: Manufacturer An identification label is located on Body color the front left door frame. Build date Vehicle identification number A further identification plate is located under the bonnet on the dash panel.
Page 355 Technical data Engine serial number 1.6L Petrol engine 1.8L Petrol engine 1.4L Petrol engine The engine serial number is located The engine serial number is located in the front part of the engine next to the oil filter. The engine serial number is located compartment.
Page 356 Technical data 2.0L Diesel engine The engine serial number is located under the centre branch of the exhaust manifold.
Page 357 Technical data Vehicle data Recommended fluids and lubricants Manufacturer's specifications Engine oil specification Engine oil specification Best viscosity grade for the vehicle Alternative viscosity 1.4L Petrol dexos 2 5W-30 0W-30 1.6L Petrol dexos 1 5W-30 0W-30 1.8L Petrol dexos 1 5W-30 0W-30 2.0L Diesel...
Page 358 1.6L Petrol 1.8L Petrol 2.0L Diesel Number of cylinders 1364 1598 1796 1998 Piston displacement [cm Engine power [kW] Refer to holden.com.au at rpm Torque [Nm] Refer to holden.com.au at rpm Fuel type Petrol Petrol Petrol Diesel Octane rating RON Minimum –...
Page 359 Technical data Vehicle weight Additional weight Maximum vehicle payloads Vehicle Occupants (Average 68 kg each) Luggage (kg) Total Load (kg) 4 Door sedan 5 Door hatchback Sportwagon Maximum front and rear axle loads Vehicle Front axle loads (kg) Rear axle loads (kg) 1.4L Petrol 1060 1000...
Page 360 Technical data Vehicle dimensions 4 Door sedan EQUIPE/CDX SRi/SRi-V Length [mm] 4615 4629 Width without exterior mirrors [mm] 1797 1797 Height (without antenna) [mm] 1477 1477 Wheelbase [mm] 2685 2685 5 Door hatchback EQUIPE/CDX SRi/SRi-V Length [mm] 4519 4543 Width without exterior mirrors [mm] 1797 1797 Height (without antenna) [mm]...
Page 361 Technical data Sportwagon CD/CDX Length [mm] 4675 Width without exterior mirrors [mm] 1797 Height (without antenna) [mm] 1521 Wheelbase [mm] 2685...
Page 362 Technical data Capacities Engine oil Engine 1.4L Petrol 1.6L Petrol 1.8L Petrol 2.0L Diesel including Filter [l] Engine coolant Engine 1.4L Petrol 1.6L Petrol 1.8L Petrol 2.0L Diesel capacity [l] Fuel tank Petrol/diesel, nominal capacity [l]...
Page 363 Technical data Tyre pressures 4 Door sedan, 5 Door hatchback Tyre size Wheel size and profile Recommended pressure Normal load Eco normal load Maximum load Spare Front Rear Front Rear Front Rear – 215/50 R17 91V – – 17 x 7.0, J 225/50 R17 94V –...
Page 364 Technical data Sportwagon Tyre size Wheel size and profile Recommended pressure Normal load Eco normal load Maximum load Spare Front Rear Front Rear Front Rear – 205/60 R16 92V – – 16 x 6.5 , J 215/50 R17 91V – –...
Page 365: Customer Information
Owner Assistance ......176 be happy to assist you. Holden Customer Care Holden Customer Care Office At Holden, we want you to be completely satisfied with your Should you wish to speak to a ownership experience. This applies Holden representative, you are...
Page 366 Written Correspondence • Date of purchase 0800 HOLDEN (0800 465 336) You can also write to Holden at the • Current odometer reading This number provides access to address below: New Zealand Roadside Assistance Most of this information will be...
Page 367: Index
Index Accessories and vehicle Capacities ........173 modifications ......117 Catalytic converter ....... 96 Adjustable air vents ..... 89 Central locking system ....21 Airbag and belt tensioners ... 66 Charging system ......66 Airbag system ......40 Child locks ........25 Air conditioning regular operation 90 Child restraint installation Air conditioning system ....
Page 368 Footbrake........70 Instrument panel illumination ..137 Front airbag system ..... 41 Instrument panel illumination Electric adjustment ...... 29 Front fog lights ......80 control ........81 Electronic climate control system 85 Fuel for diesel engines ....109 Instrument panel overview ..... 9 Electronic driving programmes ..
Page 369 Mirror adjustment ......7 Rear window wiper/washer ..59 Sunglasses storage ..... 50 Misted light covers ....... 80 Recommended fluids and Sun visors ........32 lubricants ......161, 168 Symbols ......... 3 Refuelling ........110 New vehicle running-in ....92 Reversing lights ......
Page 370 Upholstery........159 Using this manual ......3 Vehicle battery ......127 Vehicle dimensions ....171 Vehicle Identification Number ..164 Vehicle messages ....... 72 Vehicle personalisation ....75 Vehicle storage......117 Vehicle unlocking ......4 Vehicle weight ......170 Warning chimes ......73 Washer and wiper systems ..

HOLDEN JH CRUZE Owner's Handbook Manual

Table of Contents

Keys, Doors and Windows

Seats, Restraints Head Restraints

Driving and Operating

Vehicle Care

Table of Contents

Seats, Restraints Head Restraints

Driving and Operating

Vehicle Care

Quick Links

Chapters

Related Manuals for HOLDEN JH CRUZE

Summary of Contents for HOLDEN JH CRUZE

Table of Contents
