Ocation Of; Components; Right Unit - Automatic Systems FirstLane 960 Technical Manual

L E

OCATION OF

The following figures apply to both narrow versions

Right unit

5
1
The information contained in this document is the property of Automatic Systems and is confidential. The recipient shall refrain from using it for any purpose other than the
use of the products or the execution of the project to which it refers, and from communicating it to third parties without Automatic Systems' prior written agreement.
Document subject to change without notice.
FirstLane
-MT-EN
C
XTERNAL OMPONENTS
7 8
Ref.: Designation:
1 Extension cover
2 Top cover
3 Fixed glass
4 Reader cover
5 Cover without reader
6 Orientation and function pictogram
7 Moving obstacle
8 Panel for access to the mechanism(s)
9 DIRAS cells behind tinted Plexiglass
10 End panel
(FL 960) and wide versions
2 3
9
(FL
4
6
970).
10
