Operation and Parts
Texture Gun & Hopper
- For Water-Based Materials Only -
Model 245924 Series A, B, and C
100 psi (7 bar, 0.7 MPa) Maximum Working Air Pressure
60 psi (4.1 bar, 0.41 MPa) Maximum Working Fluid Pressure
Read warnings and instructions.
Related Manuals
309585
309586
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
www.graco.com
Copyright 2003
ti 2445b
309584H
ti2620a
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco 245924 A Series
Summary of Contents for Graco 245924 A Series
- Page 1 100 psi (7 bar, 0.7 MPa) Maximum Working Air Pressure 60 psi (4.1 bar, 0.41 MPa) Maximum Working Fluid Pressure Read warnings and instructions. Related Manuals 309585 309586 ti2620a ti 2445b Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 www.graco.com Copyright 2003...
-
Page 2: Electric Shock Hazard
• Route hoses away from traffic areas, sharp edges, moving parts and hot surfaces. Do not expose Graco hoses to temperatures above 130 F (55 C) or below -35 F (-37 C). • Store hazardous fluid in an approved container. Dispose of hazardous fluid according to all local, state and national guidelines. -
Page 3: Pressure Relief Procedure
WARNINGS Pressurized Equipment Hazard Fluid from gun, leaks or ruptured components can splash in the eyes or on skin and cause serious injury. • Follow Pressure Relief Procedure, page 3 when you stop spraying and before cleaning, checking or servicing. •... -
Page 4: Component Identification
Hose Plug Must be installed when hopper is used. This feature is not utilized in this application. See Graco RTX manual for installation and operating instructions for this feature. Air Fitting Quick Disconnect used to attach air hose to gun. -
Page 5: Basic Operation
Basic Operation Basic Operation Hopper Installation 4. Fasten clamp. 1. The Hose Plug must be 5. Connect air hose to gun. securely fastened to bot- tom of gun when using the Hopper. Gun Plug must be removed from top of gun. ti2449 6. -
Page 6: Mixing Material
Mixing Material Mixing Material 2. Agitate to mix, using a Correct material mixture is essential to achieve half-inch, variable speed the desired finish. drill with mixing paddle, to a smooth, lump-free con- Mix the material in a separate container before sistency. -
Page 7: Spray Techniques
Spray Techniques Spray Techniques Recommended Nozzle Selection Chart • When adjusting flow nut, release trigger, then Application adjust. Nozzle Size Air Volume • If adjusting while triggered, needle will turn Simulated 6 mm, white medium to high but provide no adjustment. Acoustic (fine to medium) •... - Page 8 Cleanup Cleanup When you have finished spraying 6. Connect air line to gun. Turn on compressor. Open gun air valve, forcing air through tip to clear out any 1. Shut off compressor. Disconnect air line from gun. remaining material. 2. Drain remaining material into a bucket until most of 7.
-
Page 9: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Material will not flow from hopper • Material too thick. • Thin material • Not enough air • Open gun air valve more • Gun adjustment set too low • Increase trigger travel • Nozzle too small •... - Page 10 Parts Parts Part No. Description 277138 BODY, gun (series C) 234162 KIT, plugs, includes 2a, 2b and 2c PLUG, hose port PLUG, hopper port O-RING 234159 KIT, needle repair, includes 3a, 3b, 3c, 3d, 3e, and 3f NEEDLE includes o-ring GUIDE, spring, includes o-ring SPRING NUT, flow adjustment...
- Page 11 Notes Notes 309584H...
-
Page 12: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
