TECHNICAL SPECIFICATIONS

Projector Type
Dimensions
(W x H x D)
Net Weight
LCD Panel System
Panel Resolution
Number of Pixels
Color System
Scanning Frequency
Projection Image size
(Diagonal)
Horizontal Resolution
Projection Lens
Throw Distance
Projection Lamp
AV Input Jacks
Computer Input Jacks
Control Port Jack
Monitor Output Jack
Computer Audio Input Jack
Audio Output Jack
Internal Audio Amp
Built-in Speaker
Feet Adjustment
Voltage
Power Consumption
Operating Temperature
Storage Temperature
Remote Control Transmitter
Accessories
The specifications are subject to change without notice.
This symbol on the nameplate means the product is Listed by Underwriters Laboratories Inc. It
is designed and manufactured to meet rigid U.L. safety standards against risk of fire, casualty
and electrical hazards.
Multi-media Projector
9.41" x 3.54" x 12.72" (239mm x 90mm x 323mm)
8.6 lbs (3.9 kg)
0.9" TFT Active Matrix type, 3 panels
800 x 600 dots
1,440,000 (800 x 600 x 3 panels)
PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N
H-sync. 15 ~ 80 KHz, V-sync. 50 ~ 100 Hz
Adjustable from 30" to 300"
750 TV lines
F 1.7 ~ 2.0 lens with f 33.2mm ~ 43.1mm Motor zoom and focus
4.6' ~ 35.4' (1.4 m ~ 10.8 m)
150 W
RCA Type x 1 (Video, Audio R and L) and DIN 4 pin (S-Video) x 1
(VGA) HDB 15 Terminal x 1
DIN 8 pin x 1
(VGA) HDB 15 Terminal x 1
Mini Jack (stereo)
Mini Jack (stereo)
1W RMS (Monaural)
1 speaker, 1.57" x 1.18" (40mm x 30mm)
0˚ to 10˚
AC 100 ~ 120 V / 200 - 240 V, 50 / 60 Hz
2.5 A / 1.4 A (Max. Ampere)
41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)
14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)
Power Source : AA Type x 2
Operating Range : 16.4' (5m) / ±30˚
Dimensions : 2.2" x 1.3" x 7.6" (55mm x 34mm x 192mm)
Net Weight : 0.35 lbs (160 g) (including batteries)
Laser Pointer : Class II Laser
Owner's Manual
AC Power Cord
Remote Control Transmitter and Batteries
VGA Cable
Control Cable for PS/2 port
Dust Cover
Lens Cover
(not including Adjustable Feet)
(Max. Output : 1mW / Wave length : 650±20nm)
