BEFORE OPERATION
MENU BAR IN COMPUTER MODE
MODE MENU
Used to select
the Computer
input mode.
(Refer to P22)
SYSTEM MENU
Used to select a
computer
system.
(Refer to P22)
MENU BAR IN VIDEO MODE
MODE MENU
Used to select
the Video input.
(Refer to P29)
18

MENU BAR

Press MENU BUTTON while in Computer mode.
AUTO IMAGE MENU PC ADJUST MENU
Used to adjust Fine Used to adjust the
sync., Total dots, parameters to
and Picture Position match with the input
automatically. signal format.
(Refer to P27) (Refer to P24, 25)
IMAGE MENU
Used to adjust the
computer image. [Fine
sync. / Total dots /
White Balance /
Contrast / Brightness]
(Refer to P26)
Press MENU BUTTON while in Video mode.
IMAGE MENU
Used to adjust the
picture image. [
Tint / White Balance /
Contrast / Brightness/
]
Sharpness
(Refer to P30)
SYSTEM MENU
Used to select a
color system among
[
PAL, SECAM, NTSC,
NTSC 4.43, PAL-M and
].
PAL-N
(Refer to P29)
SETTING MENU
Used to set the Display
Menu and to reset
Lamp Replacement
Monitor Timer.
(Refer to P31)
POSITION MENU SCREEN MENU
Used to adjust Used to adjust
the position of the size of the
the image. image.
(Refer to P27) (Refer to P28)
Color /
These icons have the
same function as the
Computer Mode.
SCREEN MENU
Used to set the size
of the image either
Regular or Wide,
or to correct the
Keystone distortion.
(Refer to P29)
LANGUAGE MENU
Used to select
the language
used in the
Menu.
(Refer to P31)
