2. Specifications
■ HE225F/HEZ2500F
Overall size(LxWxH) ···························· 68.1(1730)x12.3(313)x12.3(312) / 69.8(1773)x12.6(320)x12.3(312) in(mm)
Dry weight w/o acc. ····································································································· 13.1(5.94) / 14.1(6.39) lbs(kg)
Engine Type·················································································································· Air-cooled 2-stroke gasoline
Model··································································································································· G24LS / GZ25N
Displacement ··················································································· 1.4cu-in (22.5cm
Max. output ···································· 1.08Hp (0.8kW) at 8000 min
Idle speed·················································································································· 2800 / 3000 min
Fuel ·················································································································· Mixture (Gasoline 50 : Oil 1)
Carburetor ··············································································································· Walbro Diaphragm type
Spark plug ································································································ Champion RCJ6Y / NGK CMR7A
Fuel tank capacity ····························································································· 20.3 fl.oz (0.6 ) / 22.0 fl.oz (0.65 )
Transmission···································································································· Centrifugal clutch, Flexible driveshaft
Reduction ratio····················································································································································· 1.25
Cutting head rotating direction ··················································································· Clockwise (Vew against blade)
Durability period ···············································································································································300hrs.
Blade length ···································································································································7.87 (200) in (mm)
Use for ·················································································································································· Lawn edging
4
English
1. Parts location
1. Loop handle
2. Ignition switch
3. Throttle cable
4. Throttle lever
5. Throttle set button
6. Blade guard
7. Blade
8. Wheel
9. Spark arrester
10. Starter knob
11. Fuel tank
12. Primer pump
13. Choke lever
14. Air cleaner cover
(rpm) / 1.2Hp (0.9kW) at 7500 min
-1
(when using RedMax/ZENOAH genuine oil)
Specifications are subject to change without notice.
English
) / 1.6cu-in (25.4cm
)
3
3
(rpm)
-1
(rpm)
-1
