HEZ2450S
HEZ3050S
HEZ2450S/HEZ3050S
115256926 (909)
OWNER'S/OPERATOR'S
MANUAL
STICK EDGERS
WARNING
The engine exhaust from this
product contains chemicals
known to the State of California to
cause cancer, birth defects or
other reproductive harm.
WARNING
Before using our products,
please read this manual carefully
to understand the proper use of
your unit.
APPLICABLE SERIAL NUMBERS :
DRIVE UNIT 90800101 and up
ENGINE UNIT 90800101 and up
2009-08
U
S
US-1

Advertisement

Table of Contents
loading

Related Manuals for RedMax STICK HEZ2450S

Summary of Contents for RedMax STICK HEZ2450S

  • Page 1 HEZ2450S HEZ3050S HEZ2450S/HEZ3050S 115256926 (909) 2009-08 OWNER'S/OPERATOR'S MANUAL STICK EDGERS WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products, please read this manual carefully to understand the proper use of your unit.

  • Page 2: Table Of Contents

    Contents US-2 WARNING symbol 1. Read this stick edger Owner/Operator Manual carefully. Be sure you understand how to operate this unit properly before you use it. Failure to do so could result in serious injury.

  • Page 3: Parts Location

    Displacement ·················································································································· 1.5cu-in (23.6 cm Max. output ························································································ 1.15Hp (0.858kW) at 8000 min Idle speed····················································································································· 3000±200 min Fuel ··················································································································· Mixture(Gasoline 50 : Oil 1) ·················································································································(when using RedMax genuine oil) Carburetor ··············································································································· Walbro Diaphragm type Spark plug ································································································································NGK CMR7H Fuel tank capacity····························································································································21.3 fl.oz (0.63 ) Transmission ·······················································...

  • Page 4: Warning Labels On The Machine

    HEZ2450S/HEZ3050S 3. Warning labels on the machine ( 1 ) ( 2 ) ( 3 ) (1) Read owner's manual before operating this machine. (2) Wear head, eye and ear protection. (3) Warning! Danger of kickback. (4) Beware of thrown objects. (5) Warning/Attention (6) Keep all children, bystanders and helpers 15 meters away from the machine.

  • Page 5: For Safe Operation

    5. For safe operation WARNING • A brushcutter or trimmer can be dangerous if used incorrectly or carelessly, and can cause serious or fatal injury to the operater or others. It is extremely important that you read and understand the contents of this Owner's manual.
  • Page 6 RedMax servicing dealer for repair. ■ Using the product IMPORTANT Cut only materials recommended by the manufacturer.
  • Page 7 5. For safe operation ■ Transport 1. Drain the fuel from the fuel tank before transporting or storing the product. 2. When hand-carrying the product, cover over the cutting part, lift up the product and carry it paying attention to the blade. 3.
  • Page 8 5. For safe operation lubricant, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax product. 5. In the event that any part must be replaced or any maintenance or repair work not...

  • Page 9: Set Up

    6. Set up ■ MOUNTING OTHER PARTS 1. Insert the driveshaft into the clutch drum, then attach the gearbox to the shaft tube as aligning the positioning holes and fasten the screw (A). Fasten the clamp bolt (B) firmly. (SE1) (A) Screw (B) Clamp bolt (B) Tightning Torque:...

  • Page 10: Fuel

    • Poor quality gasolines or oils may damage sealing rings, fuel US-10 lines or fuel tank of the engine. • Failures caused by operating engines on gasoline with octane rating lower than 89 are not covered by the RedMax Two- Stroke engine warranty. WARNING • Alternative Fuels (Not Gasoline)
  • Page 11 Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel stabilizer is added. RedMax Air-Cooled "Max Life" Synthetic blend Premium two-stroke engine oil "Contains fuel stabilizer" and will automatically extend your gasoline/oil mixture life up to 60 days.

  • Page 12: Operation

    HEZ2450S/HEZ3050S 8. Operation The RedMax stick edgers are designed for edging lawn in gardens, parks, roadsides and so on. Before starting the engine, take the operating position and adjust the handle position and the wheel height as necessary. ■ ADJUSTING WHEEL HEIGHT 1.
  • Page 13 • Before edging, make sure the area is soft enough so the blade does not bog down. • Do not move the edger into the work so fast that the engine or blade bogs down. • Do not operate using starting throttle lock.

  • Page 14: Maintenance

    • Never alter the stick edger or take the engine apart. • When replacing parts, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax stick edger. ■ BE SURE TO CHECK THE FOLLOWING BEFORE USING YOUR STICK EDGER...
  • Page 15 Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type specified by RedMax. (MA3) .025 in HEZ2450S: NGK CMR7H 0.655mm HEZ3050S: NGK CMR7H IMPORTANT •...
  • Page 16 HEZ2450S/HEZ3050S 9. Maintenance ■ BLADE (MA6) • Place the blade between holders (A) and (B) while locking the gear shaft by putting the bar, through the key holes on the holder (A) and the gearcase. Use the socket to tighten the blade mounting bolt.

  • Page 17: Storage

    10. Storage • Aged fuel is one of major causes of engine starting failure. Before storing the unit, empty the fuel tank and run the engine until it uses all the fuel left in the fuel line and the carburetor. Store the unit indoor taking necessary measures for rust prevention.
  • Page 18 As the small off-road engine owner, you should however be aware that the RedMax may deny you warranty coverage if your small off-road engine or a part has failed due to abuse, neglect, or improper maintenance or unapproved modifications.
  • Page 19 Add-on or modified parts that are not exempted by CARB or EPA may not be used. The use of any non- exempted add-on or modified parts will be grounds for disallowing a warranty claim. RedMax will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
