  • Page 1 COMBI 65 For 600mm, 640mm & 650mm Worktops...

  • Page 2: Table Of Contents

    Dear Customer Contents Thank you for purchasing this Trend product. Items Enclosed _______________________2 The Combi 65 is designed to be used with most Safety Precautions ____________________3 heavy duty plunge routers. The router should be – Cutter Care__________________________3 fitted with a 30mm outside diameter guide bush –...

  • Page 3: Items Enclosed

    Combi 65 ITEMS ENCLOSED 1 x Solid laminate template 3 x Location bushes 1 x Manual 1 x Guarantee Card Specification Length = 905mm Width = 215mm Thickness = 13mm Weight = 2.7kg...

  • Page 4: Safety Precautions

    Combi 65 SAFETY PRECAUTIONS damage the shank. n Always switch off the power and unplug the router when changing cutters or when making n Do not over-tighten collet as this will score the adjustments. shank and create a weakness there.

  • Page 5: Accessories

    Makita 3612BR & 3600B Trend sub-bases have a central recess to allow Ryobi RE600N & R600N, RE601 GB/5/A fitting of the Trend guide bush to most makes of routers and are available ready to fit the most Hitachi M12V, M12SA & TR12 GB/5/D popular makes.
  • Page 6 Combi 65 UNIBASE comprises the following Fits following Router Models Atlas Copco OFSE2000 UNIBASE Bosch GOF 1300ACE, 1600A, 1700ACE Casals FT2000VCE DeWalt DW625EK, 629 UNIBASE Draper R1900V Elu MOF 31, 77, 98, 131, 177(E) Felisatti TP246(E), R346EC 170mm Ø x 8mm...

  • Page 7: Panel Butt Connectors

    Biscuit Jointer for the Router Worktops with inadequate support below them need additional stability by biscuit jointing the edges. The Trend biscuit jointing set for the router together with the No.20 biscuits will ensure worktops do not sag or warp in time, see Description Order Ref.

  • Page 8: Assembly

    Combi 65 ASSEMBLY Location Bush Identification Margin Distance Three location bushes are used in different holes Allow 8.5mm when cutting joints. Measure or in the jig to align the correct template aperture use a batten of this thickness to aid setting out.

  • Page 9: Operation

    Combi 65 OPERATION Setting the Length Stop for the Female Cut Carry out the setting operation first: n With the label side uppermost fit the length stop bush in one of the three holes depending on width of worktop. If worktop...

  • Page 10: Male Joint

    Combi 65 Male Joint Routing the male part of the Joint Depending on accessibility lay female worktop into position on units. Lay male worktop on top and support other end. Using a pencil draw round the female cut onto the male from underside.

  • Page 11: Cutting The Bolt Recesses

    Combi 65 Cutting the Bolt Recesses Routing the bolt recess in the When the joint has been tested, proceed as follows to cut the recess for panel butt female part of the joint connectors on the underside of the worktop. The...

  • Page 12: Strengthening The Joint

    The biscuit jointing Underside View cutter set Trend Ref. 342, C152 or TR35 can be used with a portable router. The size of biscuit used should be No. 20.

  • Page 13: Spare Parts - Spare Parts List & Diagram

    Combi 65 COMBI 65 SPARE PARTS DIAGRAM COMBI 65 - SPARE PARTS LIST v2.0 11/2000 Item Description Ref. Combi 65 Jig COMBI/65 Alloy Bush BUSH/650 Combi Jig ‘O’ Ring Pack for Bushes (pack of 5) CJ/ORS Manual MANU/65 -12-...

  • Page 14: Trouble Shooting

    Combi 65 TROUBLE SHOOTING Fault Cause Remedy n Joint does not fit correctly Cutter or guide bush is the Check concentricity of cutter at the radius. incorrect diameter or location with guide bush. Cutter 12.7mm bushes are not against diameter with 30mm diameter worktop edge.
