Parts Description - Powerfix Profi ST10A Operation And Safety Notes

Recommended
installation height:

Parts description

Sensor
1
Scew with screw anchor (ø approx. 6 mm)
2
Screw terminal
3
Base plate
4
Cable opening
5
Control dial SENS („Coverage area")
6
Control dial TIME („Time")
7
Control dial LUX („Light sensitivity")
8
Safety
Please read all the safety information and instructions.
Failure to observe the safety information and instructions
can result in electric shock, fire and / or serious injury.
The manufacturer is not liable for cases of material dam-
age or personal injury caused by incorrect handling or
non-compliance with the safety instructions. In such
cases, the warantee is voided.
PLEASE KEEP ALL SAFETY INSTRUCTIONS AND
INSTRUCTIONS FOR USE FOR FUTURE REFERENCE!
Avoid the danger of death
from electric shock!
Before installation, check the motion detector, as well
as connection cords to ensure that these are intact. A
defective product and defective cords increase the
risk of electrical shock.
SHOCK! Before installation or performing any work
on the lamp, switch off the electrical circuit at the cir-
cuit breaker box or remove the fuse from the fuse box.
Only install the motion detector while wearing dry
clothing and preferably, shoes with rubber soles or
while using an insulation mat.
If not working properly, only allow the sensor
be repaired by an electrician.
Introduction / Safety
1.8–2.5 m
DANGER TO LIFE BY ELECTRIC
to
1
GB/IE 7
