Installation and Operational Instructions for
®
EAS
-HTL housed overload clutch, Type 4190._5400
Sizes 4 and 5
Please read these Operational Instructions carefully and follow them accordingly!
Ignoring these Instructions may lead to malfunctions or to clutch failure, resulting in damage to other parts.
Contents:
Page 1: - Contents
Page 3: - Clutch Illustration
Page 5: - Technical Data
- Installation
Page 9: - Adjustment Tables
14/04/2020 TK/GH/MD/SU
Page 1 of 12
Chr. Mayr GmbH + Co. KG
Eichenstraße 1, D-87665 Mauerstetten, Germany
Phone: +49 8341 804-0, Fax: +49 8341 804-421
www.mayr.com, E-Mail:
info@mayr.com
(B.4.15.8.EN)
Advertisement
Table of Contents
Related Manuals for Mayr EAS-HTL 4190. 5400 Series
Summary of Contents for Mayr EAS-HTL 4190. 5400 Series
-
Page 1: Table Of Contents
Page 11: - Maintenance and Maintenance Intervals - Disposal Page 12: - Malfunctions / Breakdowns 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 1 of 12 www.mayr.com, E-Mail:... -
Page 2: Safety And Guideline Signs
Cover all moving parts to protect against seizure, dust impacts or foreign body impact. ® The clutches may not be put into operation without a limit switch unless mayr has been contacted and has agreed otherwise. To prevent injury or damage, only specialist personnel are allowed to work on the components. They must be familiar with the dimensioning, transport, installation, initial operation, maintenance and disposal according to the relevant standards and regulations. - Page 3 -HTL housed overload clutch, Type 4190._5400 Sizes 4 and 5 (B.4.15.8.EN) Fig. 1 Stroke Fig. 2 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 3 of 12 www.mayr.com, E-Mail: info@mayr.com...
-
Page 4: Parts List
240 – 600 480 – 1200 960 – 2400 1200 – 3000 3000 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 4 of 12 www.mayr.com, E-Mail: info@mayr.com... - Page 5 Value C refers to purely static loads. In case of oscillation or vibration occurrence, please use a safety factor of 2.5. 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 5 of 12 www.mayr.com, E-Mail:...
-
Page 6: Design
(pressure flange (1.2)). If the set limit torque is exceeded (overload), the clutch disengages and remains disengaged. 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 6 of 12 www.mayr.com, E-Mail:... -
Page 7: Installation Preparations
The maximum permitted shaft length is: the O-ring (13) placed under it. -2 mm. 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 7 of 12 www.mayr.com, E-Mail:... -
Page 8: Torque Adjustment
Spring path S Operating range Fig. 6 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 8 of 12 www.mayr.com, E-Mail: info@mayr.com... - Page 9 1x4 //// 419_.8_ _ _ _ 1200-3000 Nm 1x5 ///// Fig. 7 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 9 of 12 www.mayr.com, E-Mail: info@mayr.com...
-
Page 10: Limit Switch
-25 °C Active surface material: Housing material: stainless steel Cable sheath material: 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 10 of 12 www.mayr.com, E-Mail: info@mayr.com... -
Page 11: Maintenance And Maintenance Intervals
If large amounts of dirt or dust are present or in extreme ambient conditions, it may well be necessary to carry out inspections at shorter maintenance intervals. 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 11 of 12 www.mayr.com, E-Mail:... -
Page 12: Malfunctions / Breakdowns
® mayr , or for damage resulting from the use of these products. 14/04/2020 TK/GH/MD/SU Chr. Mayr GmbH + Co. KG Eichenstraße 1, D-87665 Mauerstetten, Germany Phone: +49 8341 804-0, Fax: +49 8341 804-421 Page 12 of 12 www.mayr.com, E-Mail:...
