Installation Instructions for Meter Hopper Seal
for the 1.6 bushel hopper and 3.0 bushel hopper
Before Getting Started
Before you begin installation of your Meter Hopper
Seal, read these instructions carefully and check that all
parts and tools in kit are accounted for. All hand and
specialty tools for installation are provided at owner's
expense. Please retain these installation instructions for
future reference and parts ordering information.
These installation instructions contain information for
assembling the Meter Hopper Seal to the 1.6 bushel
and 3.0 bushel hoppers.
To view an online video version of these instructions
use the following link:
http://www.greatplainsag.com/en/10551/
installation-instructions-meter-hopper-seal
General Information
The Meter Hopper Seal kit adds a seal and gasket for a
better fit of the hopper to the seed meter.
Kit Description
Meter Hopper Seal
Refer to page 3 for a detailed list of parts included in
these kits. Use this list to inventory parts received.
Tools Required
General hand tools are required for installation:
Refer to page 6 for torque values chart.
© Copyright 2016
Reference Number
403-787K
Printed 09/26/16
Models Covered
3P3025AH
3-Point 30 Foot Stack-Fold Yield-Pro®
Planter
YP425A
4-Row Yield-Pro® Planter
YP625A
6-Row Yield-Pro® Planter
YP825A
8-Row Yield-Pro® Planter
YP625TD
3-Point 6-Row 110 cm Yield-Pro® Planter
YP925TD
3-Point 9-Row 65 cm Yield-Pro® Planter
1625IRHD
2-Section 25 Series Yield-Pro® Planter
with Individual Row Control
YP825AR
8-Row Rotating Yield-Pro® Planter
3P4025AH
3-Point 40 Foot Stack-Fold Yield-Pro®
Planter
1625AHD
2-Section 25 Series Yield-Pro® Planter
with Dry Fertilizer
1625AHL
2-Section 25 Series Yield-Pro® Planter
with Liquid Fertilizer
YP425A3P
3-Point 4-Row Yield-Pro® Planter
YP625A3P
3-Point 6-Row Yield-Pro® Planter
YP825A3P
3-Point 8-Row Yield-Pro® Planter
YP1025A3P
3-Point 10-Row Yield-Pro® Planter
403-788M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3P3025AH and is the answer not in the manual?

Questions and answers

Summary of Contents for GREAT PLAINS 3P3025AH

  • Page 1 To view an online video version of these instructions use the following link: http://www.greatplainsag.com/en/10551/ installation-instructions-meter-hopper-seal General Information Models Covered 3P3025AH 3-Point 30 Foot Stack-Fold Yield-Pro® The Meter Hopper Seal kit adds a seal and gasket for a Planter better fit of the hopper to the seed meter. YP425A 4-Row Yield-Pro®...
  • Page 2: Recommended Manuals

    YP425A, YP625A, YP825A Parts Manual The information in this manual is current at printing. Some parts may change to assure top performance. 401-755M YP625TD, YP925TD Operator’s Manual Use this kit only in conjunction with a Great Plains 401-755P YP625TD, YP925TD Parts Manual implement. 411-240M 1625IRHD Operator’s Manual...
  • Page 3: Safety & Symbol Information

    Great Plains Manufacturing, Inc. Safety & Symbol Information Further Assistance Great Plains Manufacturing, Inc. wants you to be When you see this symbol, the subsequent satisfied with your new meter hopper seal. If for any instructions and warnings are serious - follow reason you do not understand any part of this manual or without exception.
  • Page 4: Installation Instructions

    Meter Hopper Seal Great Plains Manufacturing, Inc. Installation Instructions Before you begin installation of your meter hopper seal kit, lower the planter on a solid, clean surface. Detach implement from the tractor. Refer to Figure 1 1. Beginning at one end of the machine, remove the...
  • Page 5 Great Plains Manufacturing, Inc. Installation Instructions Refer to Figure 2 2. Turn the hopper upside down so it is resting on the lid. 3. Push the plastic insert (5) into the hopper outlet with the flared lip of the insert toward the hopper lid.
  • Page 6 Meter Hopper Seal Great Plains Manufacturing, Inc. Refer to Figure 4 6. Make sure the holes on the hopper line up with the holes on the hopper mount. If the holes do not line up, remove the hopper and trim the seed chute about inch to inch.
  • Page 7 Great Plains, Mfg. 1525 E. North St. P.O. Box 5060 Salina, KS 67402...
