- Page 1 PointWrite User Manual...
-
Page 2: Table Of Contents
Shipping contents....3 Prepare for setup....4 Environmental condition ......4 Instructions for surface......5 Camera Installation on Projector ....... 7 About PointWrite Pen ..8 Installing the batteries ......8 Replacing the pen tip........8 Driver Installation....9 Driver installation complete....10 Running the PointWrite ......11 Start for interactive function ........ -
Page 3: Shipping Contents
Shipping contents The PointWrite is a built in Interactive Whiteboard on the projector. To use the PointWrite correctly, please find the standard accessories below and follow the instructions in this manual. PointWrite Installation CD Quick manual Two PointWrite pens Two sets of batteries... -
Page 4: Prepare For Setup
Prepare for setup Environmental condition For an BenQ projector with the scalable interactive functionality, transforming any flat surface into a virtual interactive whiteboard. For an optimal interactive writing quality, follow these guidelines: Close window curtains. Select a projection area away from direct sunlight to prevent writing interference. -
Page 5: Instructions For Surface
Instructions for surface Optimal interactive quality will be dependent on the selected surface condition. It is important to choose a flat and non-reflective surface to secure the writing performance. Selecting a wall surface • Select a wall that is straight and flat, avoid any protruding objects on it. •... - Page 6 Selecting a board surface Attach a dry-erase board to the wall if you’re projecting on a textured wall surface. A dry- erase board is a flat surface that works well with your interactive projector and allows you to write smoothly in digital ink. Instructions for a board surface Consider the following factors when selecting a board to project to optimized the interactive quality.
-
Page 7: Camera Installation On Projector
Camera Installation on Projector The PointWrite camera is available for BenQ selected projector. Make sure the PointWrite camera is installed properly before you active interactive function. Use the USB cable to connect the projector to PC. Plug the USB mini-B end into the projector and plug the USB type-A end into PC. -
Page 8: About Pointwrite Pen
Right Button Click: Touch an icon or menu for at least 1.5 seconds. Drag: Touch and drag an object on the screen. Installing the batteries Caution: When inserting the batteries into the PointWrite Pen, make sure the battery polarities are correct. Replacing the pen tip Removing the pen tip Hold the pen tip with your fingers. -
Page 9: Driver Installation
Driver Installation Use the PointWrite driver in CD to enable the interactive function with PointWrite Pen. Disconnect the USB cable from PC when installing. Driver Installation... -
Page 10: Driver Installation Complete
, the PointWrite icon appears on the system tray area. • Click on the PointWrite icon on system tray area and a popup menu will appear. When using the PointWrite for the first time, the configuration window will appear on the desktop to help you configure the PointWrite. -
Page 11: Running The Pointwrite
PointWrite icon will be created on the system tray area. Right click on the PointWrite icon on the system tray area and a pull-up menu appears. Configuration: Choose this when you want to change the installation position of the projector. -
Page 12: Start For Interactive Function
Start for interactive function To use the PointWrite, the proper setting of the PointWrite configuration is needed. The Configuration setting window will help you to set up PointWrite correctly. Configuration setting PointWrite configuration: Select the PointWrite type that you're going to use. -
Page 13: Alignment Instructions
Alignment instructions Alignement view The PointWrite Alignment function is to set the orientation of the PointWrite to the screen. Alignment View: When clicking on the “Alignment View”, the screen image is displayed on the alignment view as illustrated. If the screen image is not in the center, the calibration will fail. Please make sure the PointWrite module is attached to the projector properly. -
Page 14: Pointwrite Calibration
Manual calibration: Click on and the calibration window will be projected on the screen. Use the PointWrite pen to click on the center of calibration cursor immediately after it appears. Then the next cursor will display. Repeat this process until the last calibration cursor disappears. -
Page 15: Calibration Complete
Calibration complete After completing calibration, you can use PointWrite pen as mouse function or launch QWrite software for writing and annotation. Calibration complete... -
Page 16: Specifications
-20°C ~ 60°C Operating Temperature 5°C ~ 40°C Dimensions 93 mm x 38.7 mm x 44 mm Weight 50 g Selected BenQ Ultra short throw models Compatible model (Throw ratio 0.23 ~ 0.3) PointWrite Pen Power AAA Battery*2 Length 176 mm...
