DLP PROJECTOR
PB2220/ PB2120
USER'S GUIDE
Thank you for purchasing the BenQ DLP Projector.
Please read this user's guide to ensure correct use of the device. Save this user's
guide for future reference.
OUTLINE
This DLP projector can display various computer signals and NTSC/PAL/SECAM video
signals.
FEATURES
1. High Brightness
2. High Resolution
3. Compact Size, Feather Weight for Portability
4. Durable Magnesium Alloy Body
5. RGB Input Terminal
6. One Touch Auto-Adjustment Function
7. Easy Keystone Adjustment
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BenQ PB2220
Summary of Contents for BenQ PB2220
- Page 1 DLP PROJECTOR PB2220/ PB2120 USER’S GUIDE Thank you for purchasing the BenQ DLP Projector. Please read this user’s guide to ensure correct use of the device. Save this user’s guide for future reference. OUTLINE This DLP projector can display various computer signals and NTSC/PAL/SECAM video signals.
- Page 2 Copyright Copyright © 2003 by BENQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BENQ Corporation.
-
Page 3: Table Of Contents
Projector Descriptions ........ - Page 4 Projector Specifications ........26...
-
Page 5: Important Safety Instructions
• Do not look straight at the projector lens during operation. The intense light beam may damage your eyes. BenQ PB2220/ PB2120 User’s Guide CAUTION • Refer servicing to qualified service personnel. • Always open the lens shutter or remove the lens cap when the projector lamp is on. -
Page 6: Safety Instructions
BenQ PB2220/ PB2120 User’s Guide The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45 minutes prior to removing the lamp assembly for replacement. Do not operate lamps beyond the rated lamp life. Excessive operation... -
Page 7: Introduction
INTRODUCTION Shipping Contents The projector is shipped with the necessary cables required for standard PC or laptop computer connections. Carefully unpack and verify that you have all the items shown below. If any of these items are missing, please contact your place of purchase. -
Page 8: Projector Descriptions
BenQ PB2220/ PB2120 User’s Guide Projector Descriptions Your Projector at a Glance Ventilation grill S-Video connector Video connector D-Sub connector (for computer/ HDTV input) Audio input Lamp access door (underneath unit) Ventilation grill IR remote sensor Rear adjustment feet Introduction... - Page 9 Menu Auto • Press and hold Power for 1 second to turn the projector on or off. • When the projector is on, Back-lit Power will blink during warm-up and turn to solid green to indicate the projector is ready for use.
-
Page 10: Adjuster
BenQ PB2220/ PB2120 User’s Guide Adjuster The projector is equipped with a quick-release adjuster foot and button for adjusting its tilt angle. Lift the projector up and press the adjuster button to release the adjuster. The adjuster will drop into position and be locked. -
Page 11: Remote Control Description
PIP S-Video Remote Control Effective Range The remote sensors are located on the front and the back of the projector. It can function in a range of 30 degrees horizontally and 30 degrees vertically relative to a line that is a right angle to the remote sensors. The distance between the remote control and the remote sensors must be shorter than 6 meters (19.5 feet). -
Page 12: Remote Control Features
BenQ PB2220/ PB2120 User’s Guide Remote Control Features FREEZE The image can be frozen when FREEZE is pressed. An icon will appear in the lower right corner of the screen for three seconds. To release the freeze function, press the FREEZE button, RETURN button or SOURCE button (when the input source is switched over during display) again. -
Page 13: Installing Or Replacing Batteries
Avoid excessive heat and humidity. There may be danger of an explosion if a battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries accord- ing to the manufacturer’s instructions. BenQ PB2220/ PB2120 User’s Guide Introduction... -
Page 14: Installation
BenQ PB2220/ PB2120 User’s Guide INSTALLATION Screen Size Place the projector at the required distance from the screen according to the desired picture size (see the table below). • PB2220 (XGA) screen size chart Diagonal measurement Distance from Minimum screen... -
Page 15: Connecting To Various Equipment
14.67 176.1 17.97 15.65 187.8 19.17 Connecting to Various Equipment It only takes a few seconds to connect your projector to your computer/notebook, VCR or other systems. However, a Mac adapter (an optional accessory) is needed for connection for Macintosh users. -
Page 16: Operation
BenQ PB2220/ PB2120 User’s Guide OPERATION Start Up Plug the power cord into a wall socket. Press and hold POWER for 1 second. • The back-lit POWER key blinks green and stays green when the power is turned on. (When the power is turned off, there is a 60-second cooling period before the projector can be re-started.) -
Page 17: Digital Keystone Correction
In some cases, you may have to optimize the picture quality manually. To do this, press the AUTO key on the control panel of the projector or on the remote control. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust to the best picture quality. -
Page 18: Source Selection
BenQ PB2220/ PB2120 User’s Guide Source Selection When several input sources are available, press the SOURCE key to make a selection from the control panel of the projector or the remote control. Menu System Press Menu for the main menu and press again to select items in the sub-menu. -
Page 19: Display Menu
*This function is not available when the input mode is PC. Adjusts to make the image look more red or blue. Tint *This function is not available when the input mode is PC. BenQ PB2220/ PB2120 User’s Guide DESCRIPTION Operation... -
Page 20: Image Menu
BenQ PB2220/ PB2120 User’s Guide 2. Image Menu FUNCTION Ratio H-position V-position Color Temp. Information System Sharpness Color Tint Operation DESCRIPTION Users have 3 options for the image ratio. 1. 4:3 2. 16:9 3. 1:1 *1:1 is available only when the input mode is PC. -
Page 21: Source Menu
BenQ PB2220/ PB2120 User’s Guide 3. Source Menu FUNCTION DESCRIPTION Ceiling-mounted projection Default Mirror Ceiling-mounted and rear Reare screen projection screen projection. If Source Scan is on, all the input sources will be detected during the Source Scan start-up process. Otherwise, the projector will only detect the last input source. -
Page 22: Control Menu
BenQ PB2220/ PB2120 User’s Guide 4. Control Menu FUNCTION Language OSD Time Auto Off Reset Lamp Hour 5. PIP Menu These functions are valid only when the input mode is PC and the PIP source is Video or S-Video. FUNCTION... -
Page 23: Shutdown
The fan will continue to run for approximately 60 seconds. Disconnect the power cord from the wall socket. Caution Please do not unplug the power cord before POWER is shut down or during the 60-second cooling process. BenQ PB2220/ PB2120 User’s Guide Operation... -
Page 24: Maintenance
The LAMP indicator will light up if the lamp becomes too hot. Turn off the power and let the projector cool for 45 minutes. If the LAMP indicator is still red when turning the power on, please contact your dealer. -
Page 25: Lamp Replacement
Lamp Replacement Caution To reduce the risk of electrical shock, always turn off the projector and dis- connect the power cord before changing the lamp. Press the POWER button to switch off the projector. Disconnect the power cord from the outlet and the projector. -
Page 26: Resetting Lamp Hours
BenQ PB2220/ PB2120 User’s Guide Caution To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp. To reduce the risk of injuries to fingers and damage to internal components, use caution when removing lamp glass that has shattered into sharp pieces. -
Page 27: Service Information
Presentation wizard kit ........60.J2478.001 Ordering Parts or Getting Information For product information, product assistance, service information, or to order accessories, please contact BENQ Corporation at http://www.BenQ.com. BenQ PB2220/ PB2120 User’s Guide Maintenance... -
Page 28: Troubleshooting
Use the Keystone correction key on the control panel of the projector or the remote control unit. Select the correct video system. Adjust brightness, contrast, or saturation. Press Auto on the control panel of the projector or the remote control unit to get better picture quality. Adjust the focus. -
Page 29: Status Messages
CHANGE THE LAMP, THE POWER WILL TURN OFF AFTER 20 HOURS CHANGE THE LAMP! BenQ PB2220/ PB2120 User’s Guide Description Projector is searching for input. Projector has identified the input signal and is running the auto image adjustment function. Input signal frequency exceeds the projector’s range. -
Page 30: Specifications
BenQ PB2220/ PB2120 User’s Guide SPECIFICATIONS Projector Specifications TECHNICAL SPECIFICATIONS Note: All specifications are subject to change without notice. General Product name Model name Optical Display system Lens F/Number Lamp Electrical Power supply Power consumption Mechanical Dimensions Operating Temperature range... -
Page 31: Timing Chart
720x400 720x400 640x480 640x480 640x480 640x480 800x600 800x600 800x600 800x600 800x600 832x624 1024x768 1024x768 1024x768 1024x768 1280x1024 BenQ PB2220/ PB2120 User’s Guide V SYNC (HZ) 31.5 70.1 37.9 85.1 31.5 70.0 37.9 85.1 31.5 60.0 37.9 72.8 35.0 66.7 43.3 85.0... -
Page 32: Dimensions
BenQ PB2220/ PB2120 User’s Guide DIMENSIONS 220mm Dimensions... -
Page 33: Warranty
In the event this product is found to be defective within the warranty period, BENQ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, imme- diately notify the dealer from which you purchased the product of any defects. -
Page 34: Safety Regulations
BenQ PB2220/ PB2120 User’s Guide SAFETY REGULATIONS FCC Statement CLASS A: This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interfer- ence to radio communications. It has been tested and found to comply with the limits for a Class “A”...
