- Page 1 SPOOL VALVE VAQ214NC Installation, Maintenance and Operating Instructions...
- Page 2 These instructions provide information about safe handling and operation of the valve. If you require additional assistance, please contact the manufacturer or manufacturer’s representative. Addresses and phone numbers are printed on the back cover. See also www.metso.com/valves for the latest documentation. SAVE THESE INSTRUCTIONS! IMO 3/20...
- Page 3 CAUTION: If not observed, user may incur damage to product and/or injury to personnel. Thank you for choosing METSO product. Each product is fully NOTE: Advisory and information comments provided to assist inspected after the production to offer you the highest quality.
- Page 4 IMO-334 EN TECHNICAL SPECIFICATION Model VAQ214NC Operation type Internal Pilot operated Type 3/2 single solenoid Port 1/4" BSP / 1/4" NPT Operating Pressure 2.5 to 10 kg/cm2 MAINTENANCE NOTE: The VAQ214NC must be removed from installation Since 2 screw (16) are removed hence we can separate prior to maintenance.
- Page 5 IMO-334 EN Exploded view IMO 3/20...
- Page 6 IMO-334 EN ASSEMBLY Insert guide plunger (9) and cover plate (5) screw it into EL cover (2) with the help of 2 screw (16). NOTE: Follow the sequence as given below to ensure proper assembly. Clean all parts with soap water and dry. Apply a layer of RMEBS recommended grease to the inner face of the body (1).(grease: RMEBS m 55).
- Page 7 IMO-334 EN Part list PACKAGING & STORE When not in use, VAQ214NC ASSEMBLY should be kept Sr. No. Name Quantity in a sealed plastic bag in a cardboard box to prevent BODY moisture or dust from contacting product. EL COVER VAQ214NC should be stored in a dry place free from SPOOL water and dust.
- Page 8 IMO-334 EN Subject to change without prior notice. Product names in this bulletin are all trademarks of Neles Finland Inc. Metso Corporation Töölönlahdenkatu 2, P.O. Box 1220, 00100 Helsinki, Finland Tel. +358 20 484 100 Neles Finland Inc. Vanha Porvoontie 229, P.O. Box 304, FI-01301 Vantaa, Finland Tel.
