DM12
Stand-mount/Bookshelf loudspeaker system
Product Summary
The DM12 addressed the noticeable trend towards smaller loudspeakers. But nearly all these so
called mini monitors suffer from inadequate bass performance, low sensitivity or poor power
handling capability.
Technical highlights
The unique B&W polymer bass/mid-range driver cone enables the DM12 to recreate realistic
sound pressure levels, even at low frequencies.
Utilising B&W's APOC overload-protection circuit, the DM12 can safely be used with even the
highest powered amplifiers.
Drive Units
1 x 26mm polyester weave dome
26mm high temperature voice coil
1 x 150mm bass/midrange driver
Bextrene cone with 26mm high-
temperature voice coil
Frequency Response
85Hz to 20kHz ±2dB
Sensitivity
1 watt into 8 ohms for spl of 85dB at
1m sinewave input at 300Hz
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Nominal Impedance
8 ohms
Power Handling
15W. No upper limit because of
electronic overload protection device.
Dimensions
Height: 355mm Width: 220mm
Depth: 270mm
Finish
Standard: teak, walnut,
Special: rosewood, black ash
www.bwspeakers.com
