DM4
Stand-mount/Bookshelf loudspeaker system
Product Summary
The DM4 is a three-unit monitor loudspeaker system that produces high quality results from an
incredibly small cabinet, making it perfect for home or small studio where space is at a premium.
Acoustic loading is by a very dense, critically damped enclosure with a small controlling vent to
optimise the response between 60 and 120Hz. This also produces considerably reduction in
cone excursion from 30 to 60Hz.
Technical highlights
The bass/midrange units come in a critically contoured Bextrene cone configuration. This is
laminated in a highly resistant damping compound that ensures linear frequency response to
at least an octave above crossover.
The upper mid frequency unit offers wide dispersion from a virtual point source and a 19mm
low diaphragm mass plastic dome unit extends frequency response to above 25KHz
Drive Units
1 x 19mm voice coil
1 x 34mm mid/high frequency unit
1 x 164mm bass/midrange unit
Frequency Response
30Hz – 25kHz. Better than ± 2dB,
Sensitivity
4.8 watts into nominal impedance (i.e
6.2 volts) for a sound pressure of 95dB
pink noise at 1 metre
Nominal Impedance
8 ohms
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
Power Handling
10W – 30W
Dimensions
Height: 530mm Width: 255mm
Depth: 256mm
Finish
Standard: teak or walnut
Special: satin white or selected veneers
of rosewood or black ash
www.bwspeakers.com
