EVAL-AD5161DBZ User Guide
Table 8. Daughter Board Bill of Materials
Qty Reference Designator
1 U1
1 U2
1 P8
5 P5, P6, P7, P9, P10
2 C2, C4
2 C1, C3
1 P1
1 P2
2 P3, P4
1 FEC refers to Farnell Electronic Component Distributors.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Description
256-position digital potentiometer
Quad 2:1 multiplexer
2-pin (0.1" pitch) header and shorting shunt
3-pin SIL header and shorting link
6.3 V, X5R, ceramic capacitor, 10 µF, ±20%
50 V, X7R, ceramic capacitor, 0.1 µF, ±10%
Header, 2.54 mm, PCB, 1 × 8-way
12-pin (2 × 6), 0.1" pitch header
5-pin SIL header
Rev. 0 | Page 15 of 16
Supplier 1 /Part Number
AD5161BRMZ10
ADG774ABCPZ
FEC 1022247 and FEC 150411
FEC 1022248 and FEC 150410
GRM188R60J106ME47D
GRM188R71H104KA93D
FEC 1766172
FEC 1804099
FEC 1929016
UG-624
