Loading Documents - Ambir ImageScan Pro 800ix Series Installation And Setup Manual

1. Plug the AC adapter into the scanner's power receptor.
2. Plug the other end of the AC adapter into a standard AC power outlet.
3. Plug the square end of the included USB cable to the USB port at the rear of the scanner.
4. Plug the rectangular end of the USB cable to an available USB port on your computer.
5. If you plan to connect your scanner to a USB hub, first connect the hub to a USB port on your
computer, then connect the scanner to the USB hub.
6. Switch the scanner ON using the scanner power switch. Wait until the number on the
LED on the display changes from 0 to 1.
7. When number 1 is displayed you are ready to start scanning.

Loading Documents

1. Load documents in the center of the ADF headfirst and face down. Ensure that the
documents are loaded all the way in and touch the bottom of the ADF feeder.
2. If needed, pull out the Paper Chute Extension and install the Stacker Tray by snapping the
tray guide pins into the holes in the bottom of the ADF.
3
