Bowers & Wilkins DM16 Specification

DM16
Floor-standing loudspeaker system

Product Summary

As the top of the line model in B&W's DM Series, The DM16 represents the ultimate integration
of high style and performance.
Without resorting to professional studio-style configurations, the DM16 incorporates many of
B&W's major technological innovations; including the use of polymer driver cones and domes.
Technical highlights
B&W's ability to reduce the number of crossover network components to an absolute minimum
means that the signal has a more direct path to the drivers – an advantage which produces a
cleaner, more linear performance. B&W's patented APOC Circuit protects both systems
against excessive overload.
The enclosures have matched the design simplicity with the beauty of real wood veneers.
Their high density, bevel wedged front baffles are more than just visually pleasing – the bevel
actually helps top reproduce diffraction and so improve dispersion.
Drive Units 1 x 26mm polyester weave dome
26mm dia. high temperature voice coil
1 x 100mm midrange polymide fibre
matrix cone
1 x 220mm bass driver diameter
thermo-plastic cone with PVA compound
coating
Frequency Response 65Hz – 20kHz ± 2dB free-field
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
87dB spl (2.83V, 1m)
Sensitivity
8 ohms
Nominal Impedance
15W Automatic Overload Protection
Power Handling
Circuit (APOC)
Height: 950mm Width: 335mm
Dimensions
Depth: Max 415mm Min 310mm
Teak, walnut or black ash
Finish
