Contents Technical specifications Reference diagram Preparation before test Operation of peak hold release and tracking button Adjustment of indicator dial Hand-held testing Peak hold and load tracking pointer Accessories Actual dimensions Maintenance Packaging checklist page 1... -
Page 3: Technical Specifications
1. TECHNICAL SPECIFICATION Model SL-2 SL-10 SL-20 SL-50 SL-100 Range 10lb 20lb 50lb 100lb Graduation 0.01lb 0.05lb 0.1lb 0.2lb 0.5lb Accuracy ±2% Stroke 10mm Work temperature 20±10ºC Carry temperature -27ºC~+70ºC Relative humidity 15%~80% RH page 2... -
Page 4: Reference Diagram
2. REFERENCE DIAGRAM page 3... -
Page 5: Preparation Before Test
3. PREPARATION BEFORE TEST Choose appropriate accessory and attach to gauge a) Pull Test Choose test hook and attach to the load application rod marked [PULL]. b) Push Test Choose appropriate accessory from items supplied and attach to the load application rod marked [PUSH]. -
Page 6: Hand-Held Testing
[0]. 8. ACCESSORIES The unit is supplied with a range of standard accessories. Should your application require a special fixture please contact your Mecmesin supplier who will be pleased to review your requirement. page 5... -
Page 7: Actual Dimensions
9. ACTUAL DIMENSIONS Please note that if you wish to use the gauge with a Mecmesin test stand then an additional bracket will be required. This will increase the * dimension by 13.5mm approximately. page 6... -
Page 8: Maintenance
Ensure that any accessory used has the necessary rated capacity other wise the gauge, operator or sample could be damaged. b) When using on a Mecmesin test stand, please use the 4 x M3 screws provided to secure the mounting bracket (Part No 408-471-F99). - Page 9 page 8...
