KTR SYNTEX Hub design 1.0 Operating & Assembly Instructions

KTR Kupplungstechnik
GmbH
D-48407 Rheine
Hub design 1.0
®
The SYNTEX is an overload system with positive locking. It protects the following
components against destruction. The design DK (ratchet) re-engages after 30° each into the
following lock-in position in case of an overload.
Table of Contents
1 Technical Data
2 Hints
2.1 General Hints
2.2 Safety and Advice Hints
2.3 General Hints to Danger
2.4 Proper Use
3 Storage
4 Assembly
4.1 Components SYNTEX
4.2 Assembly (General)
4.3 Adjustment of the Torque of Engagement
4.4 Adjustment of the Torque of Engagement after the Disassembly
4.5 Assembly SYNTEX
4.6 Limit Switch
4.7 Spares Inventory, Customer Service Addresses
Schutzvermerk Gezeichnet:
ISO 16016 beachten.
Geprüft:
SYNTEX
Operating-/Assembly Instructions
design DK (ratchet)
®
SYNTEX design DK
®
-Overload System
®
-Overload System
30.06.10 Li/Lm
30.06.10 Li
® KTR-N
sheet:
edition:
Hub design 4.5
Ersatz für: KTR-N vom 17.03.10
Ersetzt durch:
46210 EN
1 of 8
6
