  • Page 1 Integrated networking solu ons Optical line terminals LTP-8X, LTP-4X EasyMode manual Версия ПО 3.38.0 www.eltexalatau.kz/en...

  • Page 2: Table Of Contents

    LTP EasyMode manual 3.38.0 Содержание LTP-X EasyMode description ....................4 Software and hardware requirements ..................5 Installation and connection.......................6 Connection to the terminal......................7 Console cable connection ......................7 Connection via Telnet/SSH .....................12 Service model in EasyMode ....................13 EasyMode enabling and configuration ...................14 Default configuration .......................14 Custom configuration......................15 6.2.1 VLAN configuration ......................15...
  • Page 3   LTP EasyMode manual 3.38.0 Notes and warnings  Notes contain important information, tips, or recommendations on device operation and setup.  Warnings are used to inform the user about harmful situations for the device and the user alike, which could cause malfunction or data loss.

  • Page 4: Ltp-X Easymode Description

    EasyMode is a function set of LTP optical terminals. EasyMode is dedicated to fast GPON deployment according to realized service model. EasyMode allows providers to configure Triple-Play services promptly. EasyMode can be used for: • Acquaintance with GPON technology and Eltex equipment; • Fast testing of the main capabilities of the equipment; •...

  • Page 5: Software And Hardware Requirements

      LTP EasyMode manual 3.38.0 2 Software and hardware requirements The EasyMode is supported by the hardware of B and C revisions and by NTU terminals. For EasyMade operation, it is necessary to use the software no below than: For LTP-8X(4X) 3.26.1 For NTU-1 3.24.0 For NTU-2W...

  • Page 6: Installation And Connection

      LTP EasyMode manual 3.38.0 3 Installation and connection To familiarize yourself with the hardware of the device, the installation and connection procedure, refer to the 'LTP Operation Manual', which you can find at the linkhttps://eltex-co.com/catalog/olt_gpon/.

  • Page 7: Connection To The Terminal

    RS-232 console port for local control of the device GE Port 0..3 4 RJ-45 connectors of 10/100/1000Base-T Gigabit uplink interfaces for connection to IP networks (for LTP-8X) Combo GE 0..3 4 chassis for SFP modules of 1000Base-X uplink interface for...
  • Page 8 2 chassis for SFP modules of 10GBase/1000Base-X uplink interface for connection to IP networks 4 chassis for SFP modules of xPON 2.5 G (for LTP-4X) 8 chassis for SFP modules of xPON 2.5 G (for LTP-8X) Power Device power LED...
  • Page 9 Configuring the response to a button click is done in the CLI of the terminal. GE Port 0..3 4 RJ-45 connectors of 10/100/1000Base-T Gigabit uplink interfaces for connection to IP networks (for LTP-8X) Combo GE 0..3 4 chassis for SFP modules of 1000Base-X uplink interface for...
  • Page 10   LTP EasyMode manual 3.38.0 Front panel element Description 4 chassis for SFP modules of xPON 2.5 G (for LTP-4X) 8 chassis for SFP modules of xPON 2.5 G (for LTP-8X) Connect the cable and configure the following connection parameters: Baud rate 115200...
  • Page 11   LTP EasyMode manual 3.38.0 Default login and password: admin/password.

  • Page 12: Connection Via Telnet/Ssh

      LTP EasyMode manual 3.38.0 4.2 Connection via Telnet/SSH Connect the Ethernet cable to any of the GE/ComboGE ports. By default, the IP address of the LTP management interface – 192.168.1.2/24. Configure an address 192.168.1.1 on your computer and subnet mask 255.255.255.0 as it shown in Figure 4.

  • Page 13: Service Model In Easymode

      LTP EasyMode manual 3.38.0 5 Service model in EasyMode The EasyMode includes a prepared configuration for the network, a diagram of which is shown in Figure 5. Figure 5 – EasyMode network diagram Service model of this network: • Internet service using IPoE technology.

  • Page 14: Easymode Enabling And Configuration

      LTP EasyMode manual 3.38.0 6 EasyMode enabling and configuration  Enabling EasyMode will lose the current configuration. Save it if you may need it later. EasyMode can be used with the values you specify or with default values. 6.1 Default configuration Parameters to be applied by default: IP address for LTP management 192.168.1.2...

  • Page 15: Custom Configuration

      LTP EasyMode manual 3.38.0 6.2 Custom configuration You can change the settings of the LTP management interface, service VLANs and DHCP options of option 82 using the Wizard. In addition, you can quickly add already connected subscriber terminals and after completing the configuration, get a network ready for operation.
  • Page 16   LTP EasyMode manual 3.38.0 simply pressing <Enter>.

  • Page 17: Dhcp Relay Agent (Option 82) Configuration

      LTP EasyMode manual 3.38.0 As an example, change the management settings as follows: Management IP 10.189.55.19 Management mask 255.255.255.0 Management gateway 10.189.55.254 Management vid Current management settings: IP: 192.168.1.2 Mask: 255.255.255.0 Gateway: 0.0.0.0 Management VLAN ID: 1 Do you want to change management configuration? Attention, it may cause disconnection from remote sessions! (y/N): Enter management IP (leave blank for default) [192.168.1.2]: 10.189.55.19 Enter management mask (leave blank for default) [255.255.255.0]:...
  • Page 18   LTP EasyMode manual 3.38.0 When configuring the values of options, tokens are used, in place of which the corresponding values will be substituted. The rest of the text will be left unchanged. Tokens used: %HOSTNAME% LTP terminal name %MNGIP% Mangement IP address %GPON-PORT% ONT GPON port number...
  • Page 19   LTP EasyMode manual 3.38.0 Do you want to use option 82? (y/N): Current configuration dhcp-ra overwrite-option 82: Circuit id: %HOSTNAME%-%PONSERIAL%-%VLAN0% Remote id: - Do you want to setup Option 82 format? (answer No for default option) (y/N): Enter Circuit ID (leave blank for empty option): %GPON-PORT%-%ONTID% Enter Remote ID (leave blank for empty option): %MNGIP%...

  • Page 20: Saving Configuration

      LTP EasyMode manual 3.38.0 6.3 Saving configuration After applying the new configuration, you will see a message: Configured easy-mode... Easy mode enable successfully Save the configuration changes by executing the save command. After that, the configuration will be saved in non-volatile memory.

  • Page 21: Adding New Onts

    After enabling and configuring EasyMode to add new connected ONTs to the configuration, you need to: Disable ONT auto-activation LTP-8X(config)# no gpon olt auto-activation ont enable Find out the ONT serial numbers, their types, and the GPON port numbers to which they are connected. ...
  • Page 22   LTP EasyMode manual 3.38.0 Define free ONT IDs for this GPON port. To do this, run the show interface ont 2 unconfigured command. LTP-4X# show interface ont 2 unconfigured   GPON-port 2 ONT unconfigured list: 2-127 Total ONT count: 126 LTP-4X# Switch to the configuration mode.

  • Page 23: Configuration Of Voip On The Ont

    8 Configuration of VoIP on the ONT Consider configuring RG ONT parameters using the internal ACS using the example of VoIP settings. For more information about working with ACS, refer to the 'Eltex ACS User manual', which can be found at https://eltex- co.com/catalog/management/.
  • Page 24   LTP EasyMode manual 3.38.0 Apply the changes with the commit command and reconfigure the ONT with the reconfigure command. LTP-4X(acs-ont-sn='454C545866000101')#commit LTP-4X(acs-ont-sn='454C545866000101')#reconfigure LTP-4X(acs-ont-sn='454C545866000101')# Exit the ACS mode using the exit command. LTP-4X(acs-ont-sn='454C545866000101')#exit LTP-4X(acs-ont)#exit LTP-4X(acs)#exit LTP-4X#...

  • Page 25: Using A Predefined Ont Configuration Without Using Easymode

      LTP EasyMode manual 3.38.0 9 Using a predefined ONT configuration without using EasyMode If you are not satisfied with the proposed EasyMode service model, you can only use the predefined ONT configuration by configuring LTP by yourself, according to your needs. The predefined configuration includes: •...
