Precision Digital Corporation Trident PD765 Quick Start Manual

Trident & Trident X2 PD765
Thank you for purchasing the Trident
PD765 process meter!
This quick start guide will briefly
describe some of the common setup
procedures for this meter.
This guide includes:
Basic Wiring for Trident Meter..............
Program and Scale 4-20 mA Input.......
Program RTD Input..............................
Program Thermocouple Input..............
Program Relays for Automatic Reset...
Program 4-20 mA Analog Output.........
Setup Password Protection..................
Return Meter to Factory Defaults.........
For additional information about the
Trident PD765 meter not covered in
this quick start guide, please consult
the instruction manual included on the
CD or available at
Check out the Trident
Virtual Meter
interactive demo
at tvm.predig.com
© 2017 Precision Digital Corporation. All rights reserved.
Quick Start Guide
www.predig.com.
Menu Button - Use this button to
access Programming Mode and to
return to Run Mode.
Note: If you think you have made a mistake while
programming the meter, use this button to
return the meter to Run Mode without saving.
Reset Button - Use this button to
reset the high or low value while it is
being displayed (see the Max Button below)
2
or to change the selected digit while inputting
3
a numeric value in Programming Mode.
4
Max Button - Display the highest
5
and lowest process values while the
6
meter is in Run Mode. Tap the button once
to display the high value and again to display
7
the low value. Also used to increment the
8
selected digit while inputting a numeric value
8
in Programming Mode.
Acknowledge Button - Use this but-
ton to acknowledge an alarm state
while in Run Mode or to access or accept a
menu item while in Programming Mode.
Hopkinton MA 01748-2208 USA
Tel. (508) 655-7300 www.predig.com
233 South Street
