PD6830 Explosion-Proof Pulse Input Rate/Totalizer
Instruction Manual
• Fully-Approved Explosion-Proof Pulse Input Rate/Totalizer
• Pulse, Open Collector, NPN, PNP, TTL, Switch Contact, Sine Wave (Coil), Square Wave, Isolated Inputs
• 0.7" (17.8 mm) 5 Digits Upper Display for Rate or Total
• 0.4" (10.2 mm) 7 Alphanumeric Characters Lower Display for Rate, Total, Grand Total, Units, and Tag
• Display Mountable at 0°, 90°, 180°, & 270°
• SafeTouch Through-Glass Button Programming
• 13-Digit Totalizer with Total Overflow Feature
• Gate Function for Rate Display of Slow Pulse Rates
• K-Factor, Scaling, or Live Input Calibration with 32-Point Linearization
• Automatic Rate, Total, and Grand Total Unit Conversions
• Backlight Standard on All Models
• Isolated 4-20 mA Output for Rate, Total, or Grand Total
• Two Isolated Open Collector Pulse Outputs, Up to 5 kHz
• Battery, DC, or Output Loop-Powered Models
• Operating Temperature Range: -40 to 75°C (-40 to 167°F)
• FM Approved as Explosion-Proof / Dust-Ignition Proof / Flame-Proof
• CSA Certified as Explosion-Proof / Dust-Ignition Proof / Flame-Proof
• ATEX and IECEx Certified as Flame-Proof and Protection by Enclosure
• Conformal Coated PCBs for Dust and Humidity Protection
• Password Protection
• On-Board Data Logging of up to 1024 points
• Free Meterview EX Programming Software
• Modbus Communications Isolated RS-485 Option
• Wide Viewing Angle
• Flanges for Wall or Pipe Mounting
• Explosion-Proof, IP68, NEMA 4X Die-Cast Aluminum Enclosure
• Three 3/4" NPT Threaded Conduit Openings (One Plug Installed)
• 2" U-Bolt Kits Available
• Stainless Steel Tag Available
• 3-Year Warranty
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
www.predig.com
