ROBOT CAR KIT
Robot03
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product.
In following, we will introduce you to what to observe while starting up
and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
The Robot Car Kit (article no.: Robot03) is a kit that can be used as a basic
framework for a car / robot. You have to add further components your-
self, such as a power supply (accumulator, batteries) and a controller,
e.g. an Arduino with motor controller. We recommend the use of JOY-iT
accessories.
The base plate already contains the holes for mounting an Arduino.
The motors are designed for a voltage of 3-9 V DC (4.5V recommended).
NOTE: All illustrations are exemplary and do not have to be identical
with the items delivered.
Voltage DC V
Idle current mA
Idle rpm +- 10%
Torque gf/cm min.
4,5
190
90
800
www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
6
7,2
9
160
180
200
190
230
300
800
1000
1200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROBOT CAR KIT and is the answer not in the manual?

Questions and answers

Summary of Contents for Joy-it ROBOT CAR KIT

  • Page 1 Should you encounter any unexpected problems during use, please do not hesitate to contact us. The Robot Car Kit (article no.: Robot03) is a kit that can be used as a basic framework for a car / robot. You have to add further components your- self, such as a power supply (accumulator, batteries) and a controller, e.g.
  • Page 2 2. OVERVIEW Base plate (2x) Spacer (6x) Engine Mounting (8x) Screw 3x30 (6x) Screw 3x8 (6x) DC Motor (4x) Tyres (4x) M4 Nut (8x) Perforated disc (4x) www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 3 The axle hole of the perforated wheel has a wide and a narrow side. The wide side should point towards the engine. Place the perforated disc on the motor and position the motors on the base plate (the connections/cables must point outwards). www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 4 Fasten the motors with the 3x30 screws and nuts. Press the tyres onto the axles, holding them against the engine. Now mount the spacers and screw the se- cond base plate with the 3x8 screws. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 5 EMC directive when operated with the specified voltage. By adding your own components, you yourself become the manufacturer and must therefore also ensure that the resulting device complies with the regulations. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
  • Page 6 SIMAC Electronics GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germa- Possibility of return in your area: We will send you a parcel stamp with which you can return the device to us free of charge. Please contact us by email at Service@joy-it.net or by telephone. Information on packaging: If you do not have suitable packaging material or do not wish to use your own, please contact us and we will send you suitable packaging.
