Robot car kit for raspberry pi & arduino

Advertisement

ROBOT04
Robot car kit for Raspberry Pi & Arduino
1. INTRODUCTION & OVERVIEW
Dear customer,
thank you for choosing our product. In the following, we will show what
you should note at the commissioning and during the usage.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The Robot Car Kit 04 is a construction set which can function as the basic
structure for a car / robot. You must add yourself further components like an
energy source (batteries) and a control like for example an Arduino with a
motor controller. We recommend using Joy-IT appurtenances.
motor voltage
dimensions
3 - 9V DC
chassis: 170 x 90 x 30mm
wheels: 65 x 15mm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROBOT04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Joy-it ROBOT04

  • Page 1 / robot. You must add yourself further components like an energy source (batteries) and a control like for example an Arduino with a motor controller. We recommend using Joy-IT appurtenances. motor voltage 3 - 9V DC...
  • Page 2 Included materials: 1x base plate 1x mounting plate 1x mounting plate kit 4x screws (M3x30) 4x nuts (M3) 2x screws (M3x10) 1x front axle 2x motors 2x wheels...
  • Page 3 First, take the mounting plate and screw them onto the base plate with the help of the enclosed mounting plate kit. The holes according to the base pla- te of the Robot04 are marked on the mounting plate as R3.
  • Page 4 Now mount the motors from the inside of the base plate (M3x30 screws & M3 nuts).
  • Page 5 Now mount the front axle on the base plate (M3x10 screws). Finally, the wheels can be pressed on the axels. While doing this, counter by holding the motor. The assembly is now finished. You can equip the robot with the microcontroller of your choice.
  • Page 6 We send you a parcel stamp with which you can send us your old appliance free of charge. For this possibility, you must contact us via e-mail at service@joy-it.net or via telephone. information about packaging: Please package your old appliance safe during transport. Should you not have a suitable packaging material or you do not want to use your own material, you can contact us and we will send you an appropriate package.
