SMC 3000 Series Master Clock Programming Manual
User Password
_____________(default is 1111)
GETTING STARTED
Getting Started.........................................................................................
SETTING THE TIME
Setting the Time of Day..............................................................................
SETTING THE DATE
Setting the Date........................................................................................
EVENTS
Programming Events................................................................................
Editing Events..........................................................................................
Adding Schedule Changes............................................................................
Edit Schedule Changes................................................................................
Activate Manually......................................................................................
ADVANCED OPTIONS
Advanced Options......................................................................................
Technician Modes and Addresses...............................................................
Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com
Table of Contents
(V3)
Page 2
Page 3
Page 4
Page 6
Page 7
Page 8
Page 8
Page 9
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sapling SMC 3000 Series
Summary of Contents for Sapling SMC 3000 Series
-
Page 1: Table Of Contents
ACTIVATE MANUALLY Activate Manually..…...…………………………………………………………………… Page 8 ADVANCED OPTIONS Advanced Options……………………………………………………………………...….. Page 9 TECHNICIAN MODE Technician Modes and Addresses……………………………………………………… Pages 9 - 12 Page 1 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 2: Getting Started
The master clock has four (4) zones as a standard, with up to twelve (12) optional. User programming features All user programming is to be done by using the 16-button keypad located on the front of the Sapling master clock. The keypad is shown below: ↓... -
Page 3: Setting The Time Of Day
Press the <YES/ENTER> key. Then the prompt will go back to: Time OK? hh:mm:ss Press the <YES/ENTER> button to advance to the next option. Page 3 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 4: Setting The Date
<NO/CANCEL> button and it will advance to the next option. If you selected to add programming the display will read: Sch 000 00:00:00 s,m,t,w,t,f,sa,mf,ed Page 4 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 5: Programming Events
If you wish to enter more events, the master clock will keep the information for the durations and days of the week selected until the master clock goes back to the main screen. Page 5 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 6: Editing Events
If you wish to delete the event, go to the schedule number and type 000. This will erase the event. Then go down to accept the changes. Page 6 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 7: Schedule Changes
Enter the date you wish the schedule change to occur. The display will then read: Sch ### mm.dd.yy Press the YES/ENTER button to accept the schedule change. Page 7 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 8: Edit Schedule Changes
Press the <NO/CANCEL> button when the user is done selecting their preference. The display will read: Are You Sure? Press the <YES/ENTER> button to confirm. Page 8 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com... -
Page 9: Advanced Options
“Send Numeric Message?” - Only for use with a digital clock system. When used with Sapling SBD Series digi- tal clocks, the master can send numeric messages to individual clocks, or groups of clocks, which have been as- signed individual “addresses”... - Page 10 (2) saved durations. The user can enter a number from 0001 to 3600 (seconds) to denote the duration of the closure. Page 10 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com...
- Page 11 If the Real Time Clock passes the test, at the end of test, the display will read: “RT-Clock OK. Press any key.” Press any key to advance to the next option. Page 11 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com...
- Page 12 Address 080: This address will clear out the programming and will reset to the manufac- turer’s preset parameters. The default value is 255. Any different values will prompt for the user to clear the programming. Page 12 Sapling, Inc. 1633 Republic Road Huntingdon Valley, PA 19006 Phone: (215) 322-6063 Fax: (215) 322-8498 www.Sapling-Inc.com...
