Hampton Bay Lifetime Limited Warranty
The retailer warrants the fan motor to be free from defects in workmanship and material present at time
of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The
retailer also warrants that all other fan parts, excluding any glass or plexiglass blades, to be free from
defects in workmanship and material at the time of shipment from the factory for a period of one year
after the date of purchase by the original purchaser. We agree to correct such defects without charge or
at our option replace with a comparable or superior model if the product is returned to the retailer. To
obtain warranty service, you must present a copy of the receipt as proof of purchase. All costs of
removing and reinstalling the product are your responsibility. Damage to any part such as by accident
or misuse or improper installation or by affixing any accessories, is not covered by this warranty.
Because of varying climatic conditions in the United States this warranty does not cover any changes
in brass finish, including rusting, pitting, corroding, tarnishing or peeling. Brass finishes of this type
give their longest useful life when protected from varying weather conditions. A certain amount of
wobble is normal and should not be considered a defect. Servicing performed by unauthorized persons
shall render the warranty invalid. There is no other express warranty. The retailer hereby
disclaims any and all warranties, including but not limited to. Those of merchantability and
fitness for a particular purpose to the extent permitted by law. The duration of any implied
warranty which cannot be disclaimed is limited to the time period as specified in the express warranty.
Some states do not allow limitation on how long an implied warranty lasts, so the above limitation may
not apply to you. The retailer shall not be liable for incidental, consequential, or special damages
arising out of or in connection with product use or performance except as may otherwise be
accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so
the above exclusion or limitation may not apply to you. This warranty gives specific legal rights, and
you may also have other rights which vary from state to state. This warranty supersedes all prior
warranties.
Lifetime Limited Warranty
Date Purchased
Store Purchased
Model No.
Serial No.
Vendor No.
792145353294
UPC
529-751
219032

Advertisement

loading

Summary of Contents for HAMPTON BAY 529-751

  • Page 1 Hampton Bay Lifetime Limited Warranty The retailer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The...
  • Page 2: Table Of Contents

    Safety Rules............................Unpacking Your Fan........................Installing Your Fan.......................... Installing the Light Kit........................Operating Your Transmitter......................Care of Your Fan........................... Troubleshooting..........................Specifications..........................Table of Contents...
  • Page 3: Safety Rules

    1. To reduce the risk of electric shock, insure electricity has been turned 10. Do not use water or detergents when cleaning the fan or fan blades. A off at the circuit breaker or fuse box before beginning. dry dust cloth or lightly dampened cloth will be suitable for most cleaning.
  • Page 4: Unpacking Your Fan 2

    Unpack your fan and check the contents. You should have the following items: 13. Loose parts bag containing: 1. Juego de aspas (3) 7. Light plate 2. Canopy assembly 8. Glass shade a. Blade attachment hardware 3. Ball/downrod assembly (1) & extra 9.
  • Page 5: Installing Your Fan

    Figure 4 Figure 2 To hang your fan where there is an existing fixture but no ceiling joist, you may need an installation hanger bar as shown in Figure 4 (available at your Hampton Bay Retailer). 3. Installing Your Fan...
  • Page 6 Hanging the Fan Step 7. Align the holes at the bottom of the UL Listed electrical downrod with the holes in the collar on top of the motor housing (Fig.7). Carefully insert the hanger REMEMBER to turn off the power. Follow the pin through the holes in the collar and downrod.
  • Page 7 Step 3. (Fig. 10) Receiver to House Supply Wires Changing The Downrod Make the Electrical Electrical Connections: Connect the black (hot) Connections wire from the ceiling to the black wire marked (Optional) "AC in L" from the receiver. Connect the white NOTE: Your fan comes with a 4"...
  • Page 8 SUPPLY CIRCUIT Finishing the Installation Code switch Step 1. Tuck connections neatly into ceiling outlet Ground Conductor box. BLACK Outlet Box Step 2. Slide the canopy up to ceiling and over the 2 screws on hanger bracket. Rotate canopy Green WHITE clockwise.
  • Page 9 Attaching the Fan Blades Installing the Mounting Plate Insert the blade through the slots in the bottom band. Align the holes from the blade to the holes Step 1. Remove 1 of the 3 screws from the from the motor and secure in place with screws mounting ring and loosen the other 2 screws.
  • Page 10: Installing The Light Kit 8

    NOTE: Before starting installation, disconnect NOTE: Light bulbs have no warranty, can be the power by turning off the circuit breaker or purchased at local light bulb specialty store or removing the fuse at fuse box. Turning power from our service center. off using the fan switch is not sufficient to prevent electric shock.
  • Page 11: Operating Your Transmitter

    Restore power to the ceiling fan and test for 4. The " " button is used to set the fan forward Installing the battery: or reverse, press the button forward (for warm proper operation. weather) or reverse (for cool weather): Install 12V MN21/A23 battery (not included), to 1.
  • Page 12: Care Of Your Fan 10

    Here are some suggestions to help you maintain IMPORTANT your fan. MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX 1. Because of the fan's natural movement, some BEFORE YOU ATTEMPT ANY REPAIRS. connections may become loose. Check the REFER TO THE SECTION support connections, brackets, and blade "MAKING ELECTRICAL CONNECTIONS"...
  • Page 13: Troubleshooting

    Problem Solution Fan will not start. 1.Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency. Fan sounds noisy.
  • Page 14: Specifications 12

    Fan Size Speed Volts Amps Watts N.W. G.W. C.F. 0.36 2800 52" 10.7 kgs 2.25' 9.5 kgs Medium 0.41 3700 (20.96 lbs) (23.60 lbs) (132 cm) 0.42 5100 High These are approximate measures. They do not include Amps and Wattage used by the light kit. Distributed by Your Other Warehouse, LLC 12100 Little Cayman Dr.
